INSTRUCTION MANUAL
CM-840D/CM-1040D
Thank you for choosing this product.
Please read this instruction manual carefully before
operating this product.
8.4"/ 10.4" TFT LCD DIGITAL MONITOR
MODE MENU DOWN UP POWER
DIGITALTFT LCD COLOR MONITOR
Printed in KOREA
POWER TV/AV
RECALL SLEEP
MUTE AUTO
PIC
PICTURE SETUP SOUND
A.MEMO. CH.SET
123
456
789
0
CH
CH
VOL VOL
MENU
Contents
1. Safety Rules
2.
3.
4. Terms of part
5. Remote Control
6. Functions
7. Connections
8.
9.
Before Use
Special Features of the product
Changing Remote Control Battery
Specifications
3
8
10
11
12
14
23
25
26
1. Safety Rules
Please read the Safety Rules carefully before using this product. Following of the safety rules prevents users from any damage
related with the misuse of this product.
It is very important that users follow these safety rules. We state Caution and Warning to clarify any potential for damage
associated with misuse of the product.
“”
“”“ ”
About signs
“Do not”
Warning May cause bodily harm or even death if users ignore
warnings in the safety rules.
May cause bodily harm or even death if users ignore
cautions in the safety rules.
Caution
“Precautions”
“Follow directions carefully”
Warning
Place the product where it doesn’t prevent the driver from driving.
--- The driver’s view of sight should not be blocked.
Do not watch or operate the product while driving.
--- This may cause a major accident.
Do not place the product near the passenger-side airbag.
--- Airbags may not operate properly or may cause personal damage
and accident when accidentally opening.
Do not get product wet and operate with wet hands.
--- This may cause electric shock. 3
Caution
Keep electric cord properly positioned.
An improperly positioned electric cord may cause fire or electric shock when metal material is in contact with the power source.---
Clean electric socket area often.
Dust in the area may cause fire.---
Always clean the cigarette lighter socket before using product.
Bad connection may cause fire.---
Do not press or drop LCD panel.
You should not give any shock on LCD panel because it may cause damage.---
Do not place electric cord near a heating product.
The cord surface may melt and cause fire and/or electric shock.---
Do not put the product in an unstable place where the product may be exposed to shock and/or impact.
The product may fall and be damaged.---
Do not place the product where high temperature and/or the direct ray of the sun occurs.
--- This may cause fire, electric shock and/or malfunction.
Do not put the product in a place where sudden temperature increase occurs such as the vehicle’s dashboard.
This may cause electric shock and/or malfunction. You should request an authorized service dealer for any inspection and
repair of the product.
Do not attempt to open, disassemble or repair the product by any person except an authorized service dealer.
---
Do not use non-specified double socket and extended car battery cord.
Thismaycauseexcessheatand/orfire.---
Be careful when thunder and lighting occurs.
There is a danger of electric shock.---
Stop using the product immediately when you drop it or damage the outside shell.
Continuous use may cause fire, electric shock and/or malfunction.---
Do not place any containers with water or any small metal objects on top of the product or nearby it.
Unplug the product when water or metal comes in contact with the product. Continuous use may cause fire,
electric shock and/or malfunction.
---
Donotputpinsorneedlesintotheproductorelectriccordofproduct.
If this happens, stop the product operation immediately. Continuous use may cause fire, electric shock and/or malfunction.---
This may cause fire and/or electric shock.
Do not use damaged electric cord.
---
Do not damage or bend electric cord. Do not place heavy objects on electric cord.
This may cause fire from electric sparks.---
Do not use unapproved Cigarette Lighter Adapter.
This may cause fire ,electric shock and/or malfunction.---
This may cause fire or electric shock.
Do not use unapproved power voltage.
---
Do not use in bathtub. Do not pull the plug with wet hands.
This may cause electric shock.---
45
Do not place volatile materials such as insecticides on the product. The product should not come in contact with rubber
orvinylforalongperiodoftime.
The surface of the product may change and paint may peel off.---
When you transport the product, remove all cords and do not give any shock.
This may cause a malfunction.---
Do not watch Monitor for a long period of time.
This may damage your eyesight.---
Unplug the product when you clean or care for it.
Not unplugging product may cause electric shock.---
Unplugtheproductwhenyoudon'tuseitforalongperiodoftime.
Insulation may cause electric shock, electric leak and/or fire.---
Hold the plug when you unplug the product. Put a battery in the remote control properly with +, - signs as directed
in this manual.
Improper use of batteries may cause fire and/or damage.---
Do not pull the cord line when you unplug it.
Damaged cords may cause fire and/or electric shock.---
The car engine should be running when you use the product in a car.
Without the engine running, you may have excessive discharge of the car battery.---
Unplug the product and remove cords when moving.
--- It may damage cords and cause fire and/or electric shock.
If you find any strange occurrences or malfunction in the product or any foreign
substance gets into the product, please contact the authorized retailer where you
purchased the product.
---
Do not use the product in the following locations.
This may cause malfunction.
In direct rays of the sun and near heating products
High in humidity and with bad ventilation
Dusty or oily locations
Low temperatures
Unstable environment
=
=
=
=
=
=
67
2. Before Use
To safely use the product, please read the user’s manual carefully before use.=
=Any liquid leaking into product may cause malfunction.
=When you install the product in a car and watch TV, the car engine should be running as there might occur excessive
discharge of the car battery.
=When you install the product in a car, do not set a volume level too loud for others to hear outside.
=Do not disassemble and modify the product in any way. This may cause fire and/or electric shock.
=Screen may be a little dark when the product is operated in low temperature areas. Screen will be shown normal
luminosity after a few minutes.
=Use the product at the temperature range of 0 C ~ 50 C .
OO
=Do not touch the LCD panel.
=Connect all lines as directed in the product connection map in the manual.
=Cover the product when exposed to direct rays of the sun for a long period of time.
(You should keep the product at a temperature range of -20 ~ 60 .)℃℃
=The product should not be placed on the dashboard or near engine
=Be cautious of humidity and shock when you use the product in a car.
=Follow traffic laws when you use the Navigation Route System.
=Quality of pictures on screen may vary depending on the radio field strength in different locations.
You should use video equipment where you experience weak radio field strength.
=The driver should not use the product while he/she is driving.
Precautions (when you use the product in a car)
89
3. Special Features of the Product
=
=
=
=
=
=
=
=
=
=
=
=
=
Applied high resolution and low reflection DIGITAL TFT LCD (800 x 600)
All electronic control functions
Convenient Graphic OSD
System auto recognition function (PAL/ NTSC/ AUTO)
PC(RGB) auto adjustment
7 Languages display
(English, French, German, Spanish, Italian, Japanese, Korean)
PC(RGB )/ AV / S-VIDEO selection function
W speaker built-in
STAND BY Function
function
All functions are displayed on screen (OSD function)
One-touch Dimmer (Remote control)
0.5
Low Power consumption
Audio mute (Remote control)
4. Terms of part
10 11
MODE MENU DOWN UP POWER
DIGITALTFT LCD COLOR MONITOR
①
②
③
④
⑤
⑥
①MODE
AV/S-VIDEO/PC(RGB) selection function. Press the mode
button to be appeared source select OSD box and press
the DOWN, UP button or mode button repeatedly th press
the menu button or wait 3 second to select highlighted source.
●
∼
If PC cture size does not match with full horizontal or vertical screen size,
press the mode button continuously(2 3 second) and wait for a little while
then you can see the most appropriate screen.
②MENU
Button to Setup Screen and Function.Press the menu button to be
appeared Menu OSD box and press the mode button repeatedly
to select the main menu(Picture menu, Setup menu, Audio menu),
then press the DOWN or UP button to enter to sub menu, press the
mode button repeatedly to highlight icon that user wants, press the
DOWN, UP button to increase, decrease or change the function.
Push the Menu button once to return to the main menu to select
another function or press twice to exit from the OSD.
③DOWN Select the sub menu, decrease the selected function, hot key
for volume down
④UP Select the sub menu, increase the selected function, hot key
for volume up
⑤POWER ON/OFF button.
⑥Remote Sensor Window
Sensor for receiving signal from the remote control.
5. Remote Control
POWER TV/AV
RECALL SLEEP
MUTE AUTO
PIC
PICTURE SETUP SOUND
A.MEMO. CH.SET
123
456
789
0
CH
CH
VOL VOL
MENU
①②
③④
⑥
⑤
⑦
⑧
⑨
⑪
⑩
⑫
⑬
⑮
⑭
The key does not use (only TV MODE)
DSUB analog, external video, s-video
Setup selection button
The key does not use (only TV MODE)
Sound selection button
The key does not use (only TV MODE)
The key does not use (only TV MODE)
①POWER Power ON/OFF Key
②TV/AV
③RECALL
④SLEEP
⑤MENU
⑥◀▶VOL
⑦▼▲CH
⑧AUTO PIC
⑨MUTE
⑩SETUP
⑪PICTURE
Displays present status and volume level
Selects menu and changes function
Controls Volume and changes MENU level
Selects channel and moves to MENU
Selects DYNAMIC, NORMAL, MILD, USER for PICTURE
For muting sound
Returns to the previous sound level when you push again
⑫SOUND
⑬0~9KEY
⑭A.MEMO.
⑮CH.SET
Picture selection button
12 13
6. Functions
POWER (POWER)
※( ), it means a remote control button.
①
②
Push POWER(POWER) button POWER is on..
Push POWER (POWER) button again. POWER is OFF.
MODE(TV/AV)
=DSUBIt is function to change external video signals to ANALOG/ VIDEO/ S-VIDEO
AV/ S-VIDEODSUB ANALOG/
2
1
=POWER ON/OFF KEY
MENU (MENU)
3
DSUB ANALOG
AV
S-VIDEO
BRIGHTNESS
CONTRAST
SHARPNESS
COLOR TINT
COLOR TONE
SYSTEM AUTO NTSC PAL
PICTURE(PICTURE)
①BRIGHTNESS Adjust the brightness of video without affecting RGB’s brightness.
※Press MENU button to go to the Main menu.
MENU
②CONTRAST Adjust the contrast of video without affecting RGB’s contrast.
③SHARPNESS Adjust the sharpness of video image.
④COLOR TINT Change the richness of color.
⑤COLOR TONE Change the tone of color.
Change broadcast system NTSC, PAL, AUTO
⑥SYSTEM
AV1/ AV2DSUB ANALOG/ DVI DIGITAL/
AV/ S-VIDEO
55
40
14
60
15
14
DSUB ANALOG
AV1
AV2
※ ▲▼)Adjust it with CH (
CM-840D/ 1040DCM-
※▶,With ( VOL ) go to SUB MENU. After adjusting in SUB MENU,
pressMENUtoexit.
※,With MODE go to SUB MENU. After adjusting in SUB MENU,
pressMENUtoexit.
※Adjust it with Mode (key button)
CM-840D/ 1040DCM-
SETUP(SETUP)
LANGUAGE
OSD TIME
OSD H POS.
OSD V POS.
FACTORY RESET
▶ENGLISH
OFF
①LANGUAGE Change language English, German , Italian, Japanese, Korean., , SpanishFrench
②OSD TIME The number of seconds that the OSD will remain visible before disappearing.
③TRANSLUCENT Change the opaqueness of the background of the OSD.
④OSD H POS. Move the OSD Window to the horizontal direction.
⑤OSD V POS. Move the OSD Window to the vertical direction.
⑥FACTORY RESET A factory default reset will clear all of OSD information.
TRANSLUCENT
※Press MENU button to go to the Main menu.
MENU
MUTE OFF
VOLUME
SOUND(SOUND)
Mute the sound temporarily. Mute is released when you change channel and adjust volume.
Adjust the sound volume.
①MUTE
②VOLUME
TREBLE
BASS
50
50
Emphasize high frequency audio.
Emphasize low frequency audio.
③TREBLE
④BASS
※Press MENU button to go to the Main menu.
MENU
10
14
10
※ ▶),With (VOL go to SUB MENU.After adjusting in SUB MENU,
press MENU to exit.
※ ▶),With (VOL go to SUB MENU.After adjusting in SUB MENU,
press MENU to exit.
17
16
19
18
BRIGHTNESS
CONTRAST
H POSITION
V POSITION
PHASE
PIXEL FREQ.
Adjust the brightness of video without affecting RGB s brightness.
①BRIGHTNESS
Adjust the contrast of video without affecting RGB s contrast.
②CONTRAST
Adjust the horizontal position of the image.
③H POSITION
Adjust the vertical position of the image.
④V POSITION
Remove the noises. When phase value is wrong, the image has vertical lines especially in 1 dot on and off.
⑤PHASE
Adjust the sampling frequency of DSUB analog signal.
⑥PIXEL FREQ.
※Press MENU button to go to the Main menu.
MENU
PC (ANALOG)
75
50
14
100
※ ▶),With (VOL go to SUB MENU.After adjusting in SUB MENU,
pressMENUtoexit.
RED
GREEN
BLUE
The tone of color can be changed from red-dish white to bluish white.
The individual color components are also user customizable.
COLOR
①9300K Change color temperature : Red 42 Green 52 Blue 50
②7300K Change color temperature : Red 51 Green 46 Blue 46
③6500K Change color temperature : Red 40 Green 54 Blue 54
④USER User customizable. (RED, GREEN, BLUE)
※Press MENU button to go to the Main menu.
MENU
USER
※ ▶),With (VOL go to SUB MENU.After adjusting in SUB MENU,
pressMENUtoexit.
Altri manuali per CM-840D
1
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali Camos Monitor
Camos
Camos CM-562 Manuale utente
Camos
Camos CM-709M2 Manuale utente
Camos
Camos MM-1510D Manuale utente
Camos
Camos MM-1750H Manuale utente
Camos
Camos CWM-500 Manuale utente
Camos
Camos CM-840D Manuale utente
Camos
Camos MM-800 Manuale utente
Camos
Camos CM-709M2 Manuale utente
Camos
Camos CM-708R Manuale utente
Camos
Camos CM-1710D Manuale utente
