Starter Guide

Please read this guide before operating this equipment.

After you finish reading this guide, store it in a safe place for future reference.

Series

Set Up the Machine

Unless otherwise mentioned, illustrations used in this manual are those taken from the imageCLASS MF3240,

and also the menus described in this manual are based on the model MF3240.

Depending on the model of your machine, some settings may not be available and the number on the top of each

menu may vary.

Unpacking the Machine Before Setting Up the Machine

●Remove all shipping tapes

on the machine.

●When moving the machine, grip the handles on

both left and right sides of the machine and lift it

carefully, as shown in the illustration right.

●The machine illustration may differ slightly from

your machine.

1 2

Do You Have Everything?

Manuals for the Machine

●Starter Guide (This Document): Machine set-up and software installation

●Basic Guide: Basic features, maintenance, machine settings, and specifications

●Advanced Guide (in User Software CD): Advanced features, system monitor, and reports and lists

●Software Guide (in User Software CD): Printer, scanner, and PC faxing settings from a computer

●Machine ●Cassette Extension ●Extension Cover ●Toner Cartridge ●Output Tray

●Power Cord ●Telephone Cable ●Destination Labels

●Starter Guide (This Document)

●Basic Guide

●User Software CD

●Limited Warranty Notice

●Registration Card

Install Toner Cartridge

Remove the toner cartridge from the bag.

Keep the bag for future use.

Gently rock the toner cartridge five or six times to

distribute toner inside.

Place the toner cartridge on a flat and stable

surface. Fold the tab (A) on the sealing tape, and

pull it out straight (B) while supporting the toner

cartridge.

NOTE

– Make sure that the tab itself is detached from the toner

cartridge.

– Do not pull out the sealing tape at an angle.

Open the front cover.

Hold the toner cartridge and align the protrusions

(A) on both sides of the toner cartridge to the

guides (B) in the machine, then gently slide the

toner cartridge into the machine as far as it will go.

Be sure to position the arrow mark (C) on the toner

cartridge toward the inside of the machine.

Close the front cover.

CAUTION

Be careful not to get your fingers caught.

Set Up the Paper Cassette and Load Paper

Insert the output tray into the front slot on the

machine.

Pull out the paper cassette completely.

CAUTION

Pull the paper cassette straight/forward. Pulling it at an

angle may damage the paper sensing lever inside the

machine.

Attach the cassette extension to the paper

cassette. The slots (A) are keyed and must be

inserted at a 90° angle. Once inserted, fold the

extension (B).

Pinch and slide the rear paper guide (A) to match

the size of paper (B).

NOTE

Confirm that the rear paper guide is fitted in the paper

size slit correctly.

NOTE

To load Legal-size paper, pull the blue tab (A) and extend the paper cassette (B) as far as it will go. Keep the rear paper guide

to LGL-size mark.

Fan the paper stack and even the edges.

Load the paper into the paper cassette with the

print side down. Make sure the paper stack sits

below the hooks (A) on the rear paper guide.

Pinch and slide the lock release lever so that the

side paper guides match the side of paper. NOTE

Make sure the paper stack does not exceed the load limit

mark (A) and it is loaded under the hooks (B) on the side

paper guides.

Gently insert the paper cassette as far as it will go.

CAUTION

Do not push in the paper cassette at an angle. Doing so

may damage the paper sensing lever inside the

machine.

NOTE

If you do not completely insert the paper cassette into

the machine, paper jams may occur.

Insert the tabs on the extension cover into the slots

(A) on the back of the machine, and carefully lower

the cover (B) until it sits on the cassette extension

beneath it.

CAUTION

Do not load paper from the back of the machine. Doing

so may damage the paper feeding assembly inside the

machine.

NOTE

– The default paper size/type setting is <LTR> and

<PLAIN PAPER>. When you load other size and/or

type of paper, change the paper size/type setting. For

details, see Chapter 3, “Setting Paper Size and Type,”

in the Basic Guide.

– For loading paper in the multi-purpose feeder, see

Chapter 3, “Print Media,” in the Basic Guide.

Connect Telephone Cables

Connect the supplied telephone cable to the line jack (A) and the wall jack.

Connect your external telephone to the external device jack (B) if required.

Connect the Power Cord Set the Date and Time

12 ●Entering Information

– Numeric keys: Enters letters and

numbers.

– [ ] or [ ]: Move the cursor

position.

– [Clear]: Deletes the character at

the cursor position, or the entire

entry if held for more than one

second.

Connect the power cord into the rear socket and the wall

outlet.

The machine enters standby mode. 1Press [Additional

Functions].

se [ ] or [ ] to

select <3 TIMER

SETTINGS>, then press

[OK].

Use [ ] or [ ] to

select <2 DATE&TIME

SETTING>, then press

[OK].

What if...

●<CLOSE COVER/FRONT COVER> is displayed:

Make sure that the front cover is closed properly.

(See “Install Toner Cartridge,” on p. 5.)

●<TONER IS NOT SET/INSERT THE TONER> is displayed:

Make sure that the toner cartridge is installed properly.

(See “Install Toner Cartridge,” on p. 5.)

●<LOAD PAPER> is displayed:

Make sure that paper is loaded in the machine. (See “Set Up the Paper Cassette and Load Paper,” on p. 7.)

4Use the numeric keys to

enter the time (in 24-hour

format) and date (year/

month/day), then press

[OK].

5Press [Stop/Reset] to

return to standby mode.

TEXT 1

100% LTR

Ex.

[OK] Numeric Keys

[][] [Additional

Functions]

[Clear][FAX]

[Stop/Reset]

NOTE

There is no power switch.

Ex.

DATE&TIME SETTING

11:19 12 31 ´05

Set the Machine for Sending Faxes

Guidelines for Enterirng Information

The sender information you register in the machine appears in the header of each page received by your

recipient.

NOTE

Before sending a fax, you MUST register your fax number, user name, and the current date and time in the machine.

Entering Information

Use the following keys to enter information in the machine.

You can enter the following characters in each input mode:

●Use the numeric keys to enter characters.

Press the numeric key repeatedly until the

required character appears.

●Press [#] to enter symbols.

●Press [ ] to switch input modes:

– [A]: Letter mode

– [1]: Number mode

●Press [ ] or [ ] to move the cursor.

●Press [Clear] to delete the character at the

cursor position. Hold [Clear] for more than

one second to delete the entire entry.

●Press [OK] to confirm the entry.

Date and time

Fax/telephone

number

Unit name Page number/

Number of pages

Job Number [1]

[A]

[1] 1

[2] ABCabc 2

[3] DEFdef 3

[4] GHIghi 4

[5] JKLjkl 5

[6] MNOmno 6

[7] PQRSpqrs 7

[8] TUVtuv 8

[9] WXYZwxyz 9

[0] 0 0

[ ]

[#] (space) – . # ! " , ; : ^ _ = / | ’ ? $ @ % & + ( ) [ ] { } < > #

[A] [1]

[] [#]

[OK] [Clear] Numeric Keys

[]

[] [Stop/Reset][Additional

Functions]

1Press [Additional

Functions].

2Use [ ] or [ ] to

select <4 FAX

SETTINGS>, then press

[OK].

3Confirm that

<1 COMMON

SETTINGS>

is displayed

then press [OK].

4Confirm that <1 UNIT

TELEPHONE #>

displayed

, then press

[OK].

5Use the numeric keys to

enter your fax/telephone

number (max. 20 digits,

including spaces), then

press [OK].

6Confirm that

<1 COMMON

SETTINGS>

is displayed

then press [OK].

Use [ ] or [ ] to

select <2 UNIT NAME>,

then press [OK].

8Use the numeric keys to

enter the unit name (up to

32 characters), then press

[OK].

9Press [Stop/Reset] to

return to standby mode.

Set the Telephone Line Type

1Press [Additional

Functions].

2Use [ ] or [ ] to

select <4 FAX

SETTINGS>, then press

[OK].

3Use [ ] or [ ] to

select

<4 COMMUNICATIONS>,

then press [OK].

4Confirm that <1 TEL LINE

TYPE> is displayed, then

press [OK].

5Use [ ] or [ ] to

select the telephone line

type, then press [OK].

<TOUCH TONE>: Tone dialing

(default)

<ROTARY PULSE>: Pulse dialing

6Press [Stop/Reset] to

return to standby mode.

Ex.

UNIT TELEPHONE #

Ex.

UNIT NAME [A]

Altri manuali per ImageCLASS MF3240 Series

Indice

Altri manuali Canon Stampante tutto in uno

Canon

Canon MX450 series Guida all'installazione

Canon

Canon PIXMA MP620 series Manuale utente

Canon

Canon imageRUNNER ADVANCE C7270 Istruzioni per l'installazione

Canon

Canon G4000 series Guida all'installazione

Canon

Canon imageRUNNER 5065 series Manuale utente

Canon

Canon LBP251 Manuale utente

Canon

Canon ImageCLASS MF4690 Manuale di installazione e funzionamento

Canon

Canon MP540 Manuale utente

Canon

Canon imageRunner С1028i Manuale utente

Canon

Canon imageCLASS D880 Istruzioni di installazione e manutenzione

Canon

Canon imageCLASS D550 Istruzioni per il montaggio

Canon

Canon imageCLASS D480 Istruzioni per il montaggio

Canon

Canon PIXMA TS6000 Series Guida all'installazione

Canon

Canon PIXMA MG6420 Manuale utente

Canon

Canon LASER CLASS 710 Manuale utente

Canon

Canon imageRunner 2022 Manuale utente

Canon

Canon imageRUNNER ADVANCE C5500 Series Manuale tecnico

Canon

Canon PIXMA MX882 Series Manuale

Canon

Canon ImageCLASS MF3240 Series Guida all'installazione

Canon

Canon imageRUNNER 1435P+ Manuale utente

Canon

Canon PIXMA MP530 Manuale utente

Canon

Canon PIXMA MP610 Series Manuale utente

Canon

Canon imageRUNNER 3530 Manuale utente

Canon

Canon MF8100 Series Manuale utente

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Brother

Brother MFC-J430w Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Brother

Brother MFC-9760 Manuale utente

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Ricoh

Ricoh Pro C900 Manuale utente

Lexmark

Lexmark X925 Manuale utente

Brother

Brother Business Smart MFC-J4510dw Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente

Oce

Oce VarioLink 5022 Manuale utente
