Canon PIXMA MX892 Manuale utente

Setting Up Your MX892 In

Default Mode (Tel Priority Mode)

Without An Answering Machine

Next

Fax Easy Setup

NextPrevious

Click Next to step through this image-friendly version of Fax Easy Setup.

If you started Fax Easy Setup, on the fax machine’s operation panel, and

prefer to go through this image-friendly version…

Step 1

Press the FAX button at any screen

to go to fax standby mode.

Step 2

Click Next to proceed

through the setup.

Connecting The Phone Lines

NextPrevious

(Existing Phone Cord)

Wall Jack Hand Set

(Phone)

Fax to Phone Line Connection

NextPrevious 4

Before

After

Wall Jack

(Existing Phone Cord)

(Phone Cord included with Canon printer)

Hand Set

(Phone)

Fax to Phone Line Connection

NextPrevious 5

•Plug the provided phone cord into the wall jack

(Phone Cord included with Canon printer)

Wall Jack

(Existing Phone Cord)

Hand Set

(Phone)

Fax to Phone Line Connection

NextPrevious 6

•Plug the provided phone cord into the “LINE” jack located on the

rear of the multifunction

Wall Jack

(Existing Phone Cord)

(Phone Cord included with Canon printer)

Hand Set

(Phone)

Fax to Phone Line Connection

NextPrevious 7

•Remove the white plug from the upper jack labeled “EXT.”

Wall Jack

(Existing Phone Cord)

(Phone Cord included with Canon printer)

Hand Set

(Phone)

Fax to Phone Line Connection

NextPrevious 8

•Plug the second phone cord into the “EXT.” jack located on the rear

of the multifunction

Wall Jack

(Existing Phone Cord)

(Phone Cord included with Canon printer)

Hand Set

(Phone)

Fax to Phone Line Connection

NextPrevious 9

•Plug the second phone cord into the phone

Wall Jack

(Existing Phone Cord)

(Phone Cord included with Canon printer)

Hand Set

(Phone)

Setting Up The Receive Mode

NextPrevious
