Owner’s Manual

MiniTT1™/FlexTT5™for Canon

340 – 354 MHz, US FCC/Canada IC

Please pay attention to the following safety warnings:

• Operating temperature: above -15° C (5° F) and below 50° C (120° F)

• Storage temperature, without batteries: above -30° C (-22° F) and below 85° C (185° F)

-- Remove batteries during storage.

• Battery Requirements: Qty. 2 AA (IEC:LR6) for FlexTT5

CR2450 or CR2354 for MiniTT1

• Do not remove instrument covers during operation.

• Do not operate the device in the presence of ammable gases or fumes. Operation of any

electrical instrument in such an environment constitutes a denite safety hazard.

• There are no user serviceable parts inside the MiniTT1 or FlexTT5. Do not install substitute parts

or perform any unauthorized modication of the instrument. Refer servicing only to qualied and

authorized personnel.

• Red LED’s are used for dim light application and do not indicate a hazardous status.

• The MiniTT1 or FlexTT5 are accessory devices for cameras and ashes. Do not use this product

in a manner not specied in documentation.

WARNING – To avoid battery leakage, follow these guidelines:

• Always remove the batteries when the unit is not in use for extended periods of time, or

during shipping or long distance travel.

• Never mix old and new batteries. Always use a fresh pair of matched batteries.

• Always change batteries promptly at the rst indication of low battery operation.

• Do not use or leave the unit in extreme temperature or humid environments.

Safety Warnings

Congratulations on your purchase of the PocketWizard MiniTT1™/ FlexTT5™System for

Canon DSLR E-TTL II cameras and ﬂashes. Canon owners can use the MiniTT1 Transmitter and

FlexTT5 Transceiver to control single or multiple off-camera Canon E-TTL II ashes at speeds up to

8fps. The PocketWizard ControlTL™ System takes the complex E-TTL II data being sent through

the camera’s hot shoe and digitally interprets and transmits it as a reliable radio signal. You can now

place E-TTL II (or manual) ash units anywhere to illuminate the scene: Around corners, out-of-sight

and in bright sunlight. The MiniTT1 and FlexTT5 are compatible with any PocketWizard for triggering

manual ash or remote cameras.

This US FCC/Canada IC frequency PocketWizard radio slave is compatible with all US frequency

PocketWizard products. It is not frequency compatible with CE or JAPAN PocketWizard products. Verify

frequency compatibility before purchasing. The MiniTT1 and FlexTT5 are protected by various patents

and other patents pending.

Congratulations

Table of Contents

Safety Warnings 2

Congratulations 3

Batteries 6

MiniTT1 and FlexTT5 Key Features 7

MiniTT1 Feature Call-outs 8

FlexTT5 Feature Call-outs 9

READ ME FIRST 10

Powering On 11

Basic Wireless E-TTL II: MiniTT1 OO FlexTT5 12

No Flash on Camera 12

Flash on Camera 13

Ratio Wireless E-TTL II: MiniTT1 OO FlexTT5 14

Flash on Camera 14

General E-TTL II Considerations 15

Manual Flash 16

Remote Speedlites 16

Other Manual Flashes 17

Table of Contents (cont’d)

HyperSync®& High Speed Sync (FP Flash) 18

Advanced Features via PocketWizard Utility 20

Channels 22

Channel Tables 23

LEARN Mode 24

Remote Camera Triggering 26

Auto-Relay Mode 27

Reset 28

Status LED 29

Mounting 30

Long Range Performance 31

Troubleshooting 32

Canon Compatibility 35

Speciﬁcations 36

FCC Warning 39

FlexTT5 Battery Polarity

MiniTT1 Battery Polarity

CR2450 & CR2354 batteries

Batteries

CAUTION

Turn OFF your equipment (PocketWizard units, electronic

ﬂash units, cameras, etc.) before making connections or

changing batteries.

FlexTT5:

Install 2 fresh AA (IEC:LR6) batteries into the FlexTT5

Transceiver. Make sure to note proper polarity. Alkaline batteries

are recommended. Rechargeable or other chemistry batteries

will also work, though life expectancy may vary.

Life expectancy = ~60 hours with alkaline batteries

MiniTT1:

Install a fresh CR2450 or CR2354 coin cell battery into the

MiniTT1 Transmitter. Make sure to note proper polarity.

The CR2450 is recommended for longer battery life. The MiniTT1

saves batteries by automatically entering an extremely low power

state when the camera enters sleep mode, or if not on a camera

and TEST is not pressed for 10 seconds.

Life expectancy = 100’s of hours/thousands of triggers and varies

based on usage prole

MiniTT1 and FlexTT5:

Look at the normal LED blink to determine battery level,

or use the PocketWizard Utility.

LED Blink:

Green Good battery

Amber Warning – battery low

Red Very low battery – change immediately

What’s in the Box?

- MiniTT1 or FlexTT5

- Batteries

- USB Cord

- QuickGuide

MiniTT1 and FlexTT5 Key Features

ControlTL: PocketWizard’s newest rmware platform taps into the camera’s digital communications

to enable an entirely new level of remote ash capabilities through our proven radio system, beginning

with remote TTL for Canon E-TTL II ash systems with Slide-n-Shoot Simplicity.

HyperSync - Achieve better than X-sync with many

cameras and ashes – up to 1/500th second.

FP/High-Speed Sync: Need more speed? Push

beyond 1/500th and go into FP/High-Speed sync mode

automatically. No buttons to press or settings to change

other than your shutter speed will give you ash sync

all the way to 1/8000th.

Power Tracking: When working in E-TTL II, you can

change any of your control settings on your ash or

camera and the system adjusts for those changes.

Eight Frames per second: Never before have you

been able to shoot remote E-TTL II at this speed.

Nothing else comes close.

Low Proﬁle Design: The FlexTT5 lies at to stay out of

the way and uses a ip-up antenna for additional range

when needed. The MiniTT1, with an internal antenna,

weighs in at 2.3 oz. and is the smallest PocketWizard

ever.

Locking Ring

(on bottom foot)

page 12

Conﬁguration/Channel 1

Conﬁguration/Channel 2

Power Off

page 11, 22

Internal Antenna

page 31

TEST/LEARN Button

page 24

Battery Compartment

(on bottom)

page 6

USB Connector

(under rubber cover)

page 20

Status LED

page 29

Canon-style Hot Shoe

with Pass Through

page 12

MiniTT1™

Adjustable Antenna

page 31

USB Connector (behind antenna)

page 20

Locking Ring

(on bottom foot)

page 30

Conﬁguration/Channel 1

Conﬁguration/Channel 2

Power Off

page 11, 22

TEST/LEARN Button

page 24

Zone Selector

page 14

Lanyard Loop

page 30

1/4-20 mount

(on bottom)

page 30

Battery Compartment

(2 AA [IEC:LR6])

page 6

Canon-style

Hot Shoe with

Pass Through

page 12

Remote Studio or other

ﬂash Triggering Port

page 17

Remote Camera Triggering Port

page 26

Status LED

page 29

FlexTT5™

READ ME FIRST

If this is the first time you are using a remote E-TTL II flash system, we recommend you

consult your camera and flash manuals for your camera for the basics of positioning your

flash units.

Review the owner’s manuals for your camera and flash system. For most basic functions

when using Canon’s system or PocketWizard’s, operation is identical. Important exceptions

will be noted in this manual.

All equipment should be turned OFF when making connections, otherwise unwanted

triggering may occur when inserting or removing a flash or camera cable.

The first exposure after making initial connections or powering on may not be properly

exposed. The first shot is a camera calibration shot. Always test fire at least twice!

You may use a FlexTT5 as a transmitter instead of a MiniTT1 in all scenarios.

Make sure all PocketWizard radios are set to the same PocketWizard channel. The

PocketWizard channel is used instead of Canon’s E-TTL II communication channel.

See the LEARN Modeand channels sectionfor more information.

IMPORTANT: Canon flashes set to <SLAVE> and connected to FlexTT5 radios will have

slave mode automatically turned off, but will still function as slaves correctly. Set the

Canon slave group via the FlexTT5 Zone Switch.

Only compatible Canon Speedlites can be used in the MiniTT1 or FlexTT5 hot shoe.

Other brands of hot shoe flashes, E-TTL compatible or manual, will not trigger.
