Instructions

ENG

ENG-1

Thank you for purchasing a Canon product.

Canon RF85mm F1.2 L USM is a large

aperture medium telephoto lens for use with

EOS R series cameras.

z“USM” stands for Ultrasonic Motor.

Camera Firmware

Please use the latest version of firmware with the

camera in use. For details on whether the firmware is

the latest version or not, and for details on updating the

firmware, please check the Canon website.

Conventions used in these instructions

Warning to prevent lens or camera malfunction

or damage.

Supplementary notes on using the lens and

taking pictures.

ENG-2

Precautions to ensure that the camera is used

safely. Read these precautions thoroughly. Make

sure all details are observed in order to prevent

risks and injury to the user and other people.

Warning Details pertaining to risks that may

result in death or serious injury.

zDo not look directly at the sun or other strong

light sources through a lens. This may result in

loss of sight.

zDo not leave a lens in the sun without the lens

cap attached. The lens may concentrate entering

sunlight and cause a malfunction or fire.

Caution Details pertaining to risks that may

result in injury or damage to other

objects.

zDo not leave the product in places exposed to

extremely high or low temperatures. The product

may cause burns or injury when touched.

Safety Precautions

ENG-3

Handling Precautions

zDo not leave the product in excessive heat such as

in a car in direct sunlight. High temperatures can

cause the product to malfunction.

zIf the lens is taken from a cold environment into a

warm one, condensation may develop on the lens

surface and internal parts. To prevent condensation

in this case, first put the lens into an airtight

plastic bag before taking it from a cold to warm

environment. Then take out the lens after it has

warmed gradually. Do the same when taking the

lens from a warm environment into a cold one.

zPlease also read any lens related handling

precautions listed in your camera’s instruction

manual.

General Precautions

ENG-4

This device complies with Part

15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this

device must accept any interference received, including

interference that may cause undesired operation.

Do not make any changes or modifications to the equipment

unless otherwise specified in the instructions. If such

changes or modifications should be made, you could be

required to stop operation of the equipment.

This equipment has been tested and found to comply with

the limits for a class B digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference

by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician

for help.

CAN ICES-3 (B) / NMB-3 (B)

ENG-5

Filter mounting

thread (→ 10)

Control ring (→ 8)

Focusing distance range selector switch (→ 8)

Lens mount (→ 6)Lens mount index (→ 6)

Hood mount (→ 9)

Focus mode switch (→ 7)

Focusing ring (→ 7)

Rubber ring (→ 6)

Contacts (→ 6)

z For detailed information, reference page numbers are provided in parentheses (→ **).

Nomenclature

ENG-6

Lens mount index

Lens release button Dust cap

Attaching the Lens

Align the lens mount indexes of the lens and

camera, and turn the lens clockwise until you

hear a click.

Detaching the Lens

Turn the lens counterclockwise while pressing

the camera’s lens release button. Detach the

lens once it has stopped turning.

Please refer to the camera's instructions for

details.

zSet the camera’s power switch to OFF when

attaching or detaching the lens.

zAttach the lens cap before detaching the lens

from the camera.

zAfter detaching the lens, place the lens with the

rear end up and attach the dust cap to prevent

the lens surface and contacts from getting

scratched. Make sure the lens and dust cap

mount indexes are aligned when attaching the

dust cap.

zContacts that are scratched, soiled, or have

fingerprints on them may result in faulty

connections or corrosion, which may lead to

malfunctions. If the contacts get soiled, clean

them with a soft cloth.

zThe lens mount has a rubber ring to improve

dust-resistance and water-resistance

performance. This rubber ring may cause

friction marks to appear around the camera’s

lens mount, although this will have no effect on

usage.

zRubber rings can be replaced at Canon Service

Center. (chargeable)

1. Attaching and Detaching the Lens

ENG-7

Focus mode switch

Focusing ring

To shoot in autofocus (AF) mode, set the focus

mode switch to AF.

To use only manual focusing (MF), set the focus

mode switch to MF, and focus by turning the

focusing ring.

2. Setting the Focus Mode

zQuickly turning the focusing ring may result in

delayed focus.

zThe lens’ focusing ring is electronic.

zWhen AF operation is set to [ONE SHOT],

manual focus is possible after autofocusing

has been completed by continuing to press the

shutter button halfway. (Full-time manual focus)

However, the camera settings need to be

changed.

ENG-8

The control ring can be assigned the functions

that are commonly used with cameras, such as

shutter speed and aperture settings.

Control ring

The click action of the control ring allows you to

have a sense of how much it is being turned.

Please refer to the camera's instructions for

details on how to use the control ring.

zThere are cases in which the sound of control

ring operations may be recorded when shooting

movies.

zThe clicking sensation of the control ring can

be removed by the Canon Service Center.

(chargeable)

4. Control Ring

3. Setting the Focusing

Distance Range

Focusing distance range selector switch

You can set the focusing distance range with a

switch. By setting a suitable focusing distance

range, the actual autofocusing time will be

shorter.

Focusing distance range

1. FULL (0.85 m/2.79 ft. - ∞)

2. 1.5 m/4.92 ft. - ∞

ENG-9

The custom lens hood cuts out unwanted light and protects the front of the lens from rain, snow, and

dust.

5. Hood

Attachment position mark

Stop position markAttachment position mark

Red dot

●Attaching the Hood

Align the red attachment position mark on the

hood with the red dot on the front of the lens,

and then turn the hood in the direction of the

arrow until you hear a click.

Button

●Detaching the Hood

Keep your finger pressed down on the button

located on the side of the hood, and then turn

the hood in the direction of the arrow until the

attachment position mark on the hood is aligned

with the red dot on the front of the lens to detach

it.

The hood can be reverse-mounted on the lens

for storage.

zIf the hood is not attached properly, vignetting (darkening of the perimeter of the picture) may occur.

zGrasp and turn the base of the hood when attaching and detaching it. There are cases in which it may

become deformed if the hood is turned with it grasped near to the rim.
