Canon IRC 4570 Manuale utente

R 3

3 3

3025

025025

025

Special Features User Guide

Special Features User GuideSpecial Features User Guide

Special Features User Guide

Page

HOW TO COPY

1. Press <COPY> on the iRC 3570/4570.

2. Place originals face- p in the a tomatic doc ment reader or face down on

the glass.

3. Using the key pad, enter the desired n mber of copies.

4. If other f nctions are desired press <SPECIAL FEATURES> or <FINISHER> on the

LCD panel

5. Press <START> to begin making copies.

*A to paper selection is the standard mode setting. To man ally select paper size,

press <PAPER SELECT> and choose the appropriate size.

1. 3.

Page

BOOKLET

Booklet allows sers to copy a single-sided or do ble-sided original in s ch a way

that a booklet is created when a copy is folded in half.

Examples:

1. Men s, broch res, programs, invitations

2. Company newsletters, training man als, ser g ides

DIVIDED BOOKLET

Enables yo to copy a doc ment with many pages and create m ltiple s b-

booklets (with each s b-booklet sing p to 15 sheets of paper).

Since the Saddle Finisher can only fold a maxim m of 15 sheets of paper, this

mode will allow all of the o tp t for a large doc ment to be folded, which wo ld

not be possible with the booklet mode mentioned above.

Page

COVER SHEET/INSERTION

Cover Sheet/Insertion is sed to add covers, chapter pages, or insertion sheets

between specified pages.

Examples:

1. Cover Page

a. Specialty paper for the cover of yo r doc ment (Colored

paper, heavier paper stock, etc.)

Front Cover

Adds a front cover sheet to each set of copies. The cover sheet can also be

copied. Printed front cover selected in the Cover/Sheet Insertion mode.

Page

Back Cover

Adds a back cover sheet to each set of copies. The cover sheet can also be

copied.

Printed front cover selected in the Cover/Sheet Insertion mode.

2. Insertion Sheet

a. Chapter page, to indicate separate sections of a doc ment.

b. Sheet insertion, to highlight a page within a doc ment by

sing a different colored paper or heavier card stock.

Chapter Pa e

Adds chapter pages between the pages of copy sets. Since the chapter page

is always copied on one side, it is sef l when yo want to divide the copy by

chapter.

Printed sheet insertions selected in Cover/Sheet insertion mode.

Sheet Insertion

Adds sheet insertion between the pages of copy sets. It is sef l when yo want

to divide yo r copy sets into different sections with a blank sheet. The cover

sheet can also be copied.

Printed sheet insertions selected in the Cover/Sheet insertion mode.

DIFFERENT-SIZED ORIGINALS

Different-sized originals can be placed together, provided that the leading edge

of each page is the same length.

Examples:

1. Use all doc ments in the same job, rather than r nning to different

paper sizes as separate jobs.

2. Packets of information, s ch as HR new-hire doc ments may have

some legal-sized doc ments.

Page

FRAME ERASE

Frame Erase eliminates shadows and dark lines to create clean copies of odd-

size originals, bo nd doc ments, originals with ragged edges, hole p nches, or

notes in the margin. Fo r erase modes are accessible within Frame Erase.

Ori inal Frame Erase

Eliminates dark borders and lines that appear on the copies when the original is

smaller than the selected paper size.

Examples:

1. Pages from a book, note pad

2. Faxes images, skewed faxes

Page

Book Frame Erase

Erases the gray shadow that appears when copying from a book.

Bindin Erase

Erases the shadows that appear in copies from binding holes in originals.

Page

IMAGE COMBINATION

Image combination enables yo to a tomatically red ce two, fo r or eight

originals to fit on a single-sided or two-sided copy sheet.

Examples:

1. For presentation hando ts, create th mbnails of each image in yo r

presentation.

2. Save paper and storage space by storing p to 16 doc ments on

one page (8 on each side)

2 on 1

Red ces two 1-sided originals or one 2-sided original to fit on one side or both

sides of the sheet.

4 on 1

Red ces fo r 1-sided or two 2-sided originals to fit on one side or both sides of a

sheet.

8 on 1

Red ces eight 1-sided or fo r 2 sided originals to fit on one side or both sides of

the sheet.

Page

IMAGE REPEAT

Image Repeat repeatedly copies the image of an original in either a length-wise

or width-wise direction.

Examples:

1. B siness cards

2. Labels

Automatic Settin

The original image is copied so that the minimal possible n mber of copies fit on

the selected paper size.

Manual Settin

The original image is copied for the specified n mber of times

Examples:

When <3 times> is specified, images overlap when copied.

JOB BUILD

Job B ild enables yo to scan originals that are too many to set at once, by

dividing them into m ltiple batches. Yo can se the feeder and the platen

glass for scanning. The originals are copied as one doc ment after all the

b nches have been scanned.

Examples:

1. Doc ments with more pages than the feeder can hold

2. Combine images or pages from separate doc ments

Page

MARGIN

Margin enables yo to make copies with an entire image shifted to the left, right,

top or bottom of a sheet.

Examples:

1. Eliminate the top lines of a fax

2. When binding or sing a three hole p nch, yo r printed data will not

be c t off.
