Canon PowerShot N Manuale del proprietario

PRINTED IN JAPAN

CDE-S571-010 ©CANON INC. 2013 IMPRESO EN JAPÓN

Supplement

Suplemento

Please refer to the complete user guide included

on the CD-ROM for more detailed information.

Para información más detallada, consulte la guía

del usuario completa que se incluye en el CD-ROM.

Español

English

GS_ES_Cover14_CDE-S571.indd 1 2013/07/01 14:23:33

EC338A_GS-EN.indb 2 2013/07/01 14:28:32

• To ensure correct use, also refer to the Camera

User Guide on the included CD-ROM. In particular,

be sure to read “Safety Precautions” (=6 – 8) in

the Camera User Guide initially.

• For instructions on viewing the Camera User Guide

on the CD-ROM, refer to Getting Started.

English

Table of Contents

Introduction ....................................4

Inapplicable Information in Other

Manuals .........................................5

Connecting to Facebook and

Sending Images.............................6

Connecting to a Smartphone .......15

EC338A_GS-EN.indb 3 2013/07/01 14:28:32

Introduction

This special PowerShot N model simpliﬁes

sharing photos on Facebook.

Once you complete the connection settings

in these preliminary steps, you can connect

to Facebook simply by pressing the < >

button.

Install the software on your computer.

camera.

Connect to an access point.

For detailed instructions, see “Connecting to

Facebook and Sending Images”.

• If you press the < > button before completing the settings, a message will

be displayed. Touch [OK] to clear the message, and then follow the steps in

“Connecting to Facebook and Sending Images” to complete the settings.

< > (Facebook Connect)

Button

EC338A_GS-EN.indb 4 2013/07/01 14:28:32

Inapplicable Information in Other

Manuals

The following information in the included Getting Started guide and the

Camera User Guide on the CD-ROM does not apply to this model.

• Information about the < (mobile device connect)> button

-Getting Started: =6, 40, 42, 47 – 51, 80

- Camera User Guide: =3, 81, 82, 85 – 87, 104

This model does not include a < > button. (The < > button on the side

of the camera is the Facebook connect button.)

• Information about [Mobile Device Connect Button] in the [3] menu

-Getting Started: =50

- Camera User Guide: =87, 109, 128

The menu for this model does not include [Mobile Device Connect

Button].

Also note that illustrations and screenshots may differ slightly from their

actual appearance for this model.

EC338A_GS-EN.indb 5 2013/07/01 14:28:33

Connecting to Facebook and Sending

Images

Installing the Software on Your Computer

Install the software on the included DIGITAL CAMERA Solution Disk (CD-

ROM) as follows.

For system requirements and detailed installation instructions, refer to the

Camera User Guide.

1Insert the CD-ROM in the

computer’s CD-ROM drive.

 Insert the included CD-ROM in the

computer’s CD-ROM drive.

 On a Macintosh computer, after inserting

the disc, double-click the desktop disc icon

to open it, and then double-click the [ ]

icon displayed.

2Begin the installation.

 Click [Easy Installation] and follow the

on-screen instructions to complete the

installation process.

EC338A_GS-EN.indb 6 2013/07/01 14:28:33

Connecting to Facebook and Sending Images

3When a message is displayed

prompting you to connect

the camera, connect it to a

computer.

 With the camera turned off, open the

cover ( ). With the smaller plug of the

included interface cable in the orientation

shown, insert the plug fully into the

camera terminal ( ).

 Insert the larger plug of the interface

cable in the computer’s USB port. For

details about USB connections on the

computer, refer to the computer user

manual.

EC338A_GS-EN.indb 7 2013/07/01 14:28:33

Connecting to Facebook and Sending Images

4Install the ﬁles.

 Turn the camera on, and follow the

on-screen instructions to complete the

installation process.

 The software will connect to the Internet

to update to the latest version and

download new functions. Installation may

take some time, depending on computer

performance and the Internet connection.

 Click [Finish] or [Restart] on the screen

after installation and remove the CD-

ROM when the desktop is displayed.

 Turn the camera off and disconnect the

cable.

Registering Your Facebook Account on the

Camera

Follow these steps to join CANON iMAGE GATEWAY, prepare for Facebook

connections, and then add your Facebook account to the camera. For

information on countries and regions where CANON iMAGE GATEWAY is

available, visit the Canon website (http://canon.com/cig).

Note that if you do not have a Facebook account, you will need to create

one. For details, visit the Facebook website.

1Register as a CANON iMAGE

GATEWAY member.

 From a computer or other device

connected to the Internet, access http://

canon.com/cig and visit the CANON

iMAGE GATEWAY site for your region.

 Follow the instructions displayed to

complete member registration (free of

charge).

EC338A_GS-EN.indb 8 2013/07/01 14:28:33

Connecting to Facebook and Sending Images

2Connect the camera to a

computer with the interface

cable.

 Connect the camera to a computer with

the interface cable, referring to step

3 of “Installing the Software on Your

Computer”.

3Turn the camera on to access

CameraWindow.

 Press the <1> button to turn the camera

on.

 On a Macintosh computer,

CameraWindow is displayed when a

connection is established between the

camera and computer.

 In Windows, change the program by

clicking the [ ] link on the screen

displayed. Select [Downloads Images

From Canon Camera], click [OK], and

then double-click [ ].

4Access the CANON iMAGE

GATEWAY login screen.

 Click [Camera Settings], and then click

[Set Up Web Services].

EC338A_GS-EN.indb 9 2013/07/01 14:28:33

Connecting to Facebook and Sending Images

5Login to CANON iMAGE

GATEWAY.

 Enter your CANON iMAGE GATEWAY

[Login].

6Set up your Facebook account.

 Follow the instructions displayed to

complete the Facebook settings.

 Multiple groups can be speciﬁed.

 Once the settings are complete, click

[Finish] at the bottom of the window to

close it.

7Apply your Facebook account

information to the camera.

 Select your Facebook account and click [ ] in

the middle to add it to the list under “Camera”.

 Close the screen.

 Your Facebook account is now registered

on the camera.

EC338A_GS-EN.indb 10 2013/07/01 14:28:33
