CANON

FAX – L360

SIMPLIFIED

GUIDE

CONTENTS

PAGE

FAX-L360

I To Register Sender’s Identification 3

II Sending Documents 4

III Setting Up Speed Dialing

A One-touch Speed Dial 5

B Coded Speed Dial 6

C Group Dial 7

IV To Erase Auto-Dialing Numbers

A One-touch Speed Dial 8

B Coded Speed Dial 8

C Group Dial 8

V Sending To More Than One Location 9

(Sequential Broadcasting)

VI Sending At A Preset Time 10

(Delayed Transmission)

VII To Print Documents Received In The Memory 11

VIII To Re-send Documents Received In Memory 12

To A Different Destination

(If No. VII method above is not possible)

IX To Print Reports & Lists

A Speed Dial Lists 13

B Activity Management Report 13

C Document Memory List 13

X To Make A Photocopy 14

XI Setting Up Transmission (TX) Report

For Every Document Sent Out 15

XII Erasing A Document That Is Queuing To Be Sent

FromTheMemory 16

TO REGISTER SENDER IDENTIFICATION

I. INPUT YOUR FAX NUMBER AND COMPANY NAME

1. Open One-Touch Speed Dial panel

2. Press Data Registration

3. Press Set to display “1. USER SETTINGS”

4. Press Set to display “1. DATE & TIME”

5. Press ∨

∨∨

∨to display “2. UNIT TELEPHONE #”

6. Press Set

7. Enter your fax number

8. Press Set to display “3. UNIT NAME”

9. Press Set

10. Enter your company or personal name

CODE NUMBERS FOR ALPHABETS AND SYMBOLS

NUMERIC KEY ALPHABETS NUMERIC KEY ALPHABETS

2 A,B,C 6 M,N,O

3 D,E,F 7 P,Q,R,S

4 G,H,I 8 T,U,V

5 J,K,L 9 W,X,Y,Z

#symbols

Press >

>to enter next alphabet

Press SPACE to enter a space

Press * to enter a digit

11. Press Set to save the name

12. To end, press Stop 





II SENDING A DOCUMENT

A. DIRECT / MANUAL SENDING

1. Place documents face down on the feeder

2. Press Hook 





3. Enter fax number

4. Press Start/Copy 





N.B. The fax number dialed will not appear in the TX and activity report

in the above method.

B. MEMORY SENDING

1. Place documents face down on the feeder

2. Enter fax number

4. Press Start/Copy 





5. Take note of “ TX / RX ” number

C. ONE-TOUCH / CODED DIAL SENDING

1. Place documents face down on the feeder

2. Press the appropriate one-touch key OR

Press CODED DIAL and a two-digit code

3. Take note of “ TX / RX ” number

N.B. If direct sending is required, activate HOOK sign before step No. 2

TO STOP SENDING

A. During a DIRECT TX sending, press Stop 





B./C. During a memory sending, press Stop 



then *to confirm the stop

sending function.

III TO STORE FAX NUMBERS

A. ONE-TOUCH SPEED DIAL ( 01-KEY TO 32-KEY )

1. Open One-Touch Speed Dial panel

2. Press Data Registration

3. Press ∨

∨∨

∨to display “2. TEL REGISTRATION”

4. Press Set twice

5. Press ∨

∨∨

∨(if necessary) until an empty space appears

6. Press Set twice

7. Enter fax number

8. Press Set twice

9. Enter name

CODE NUMBERS FOR ALPHABETS AND SYMBOLS

NUMERIC KEY ALPHABETS NUMERIC KEY ALPHABETS

2 A,B,C 6 M,N,O

3 D,E,F 7 P,Q,R,S

4 G,H,I 8 T,U,V

5 J,K,L 9 W,X,Y,Z

#symbols

Press >

>to enter next alphabet

Press SPACE to enter a space

Press * to enter a digit

10. Press Set

11. To continue, press Data Registration

12. Repeat steps No. 5 to No. 10

13. To end, press Stop 





B. CODED SPEED DIAL (*00 TO *99 )

1. Open One-Touch Speed Dial panel

2. Press Data Registration

3. Press ∨

∨∨

∨to display “2. TEL REGISTRATION”

4. Press Set

5. Press ∨

∨∨

∨to display “2. CODED SPD DIAL”

6. Press Set

7. Press ∨

∨∨

∨(if necessary) until an empty space appears

8. Press Set twice

9. Enter fax number

10. Press Set twice

11. Enter name (refer to A.9. on III : TO STORE FAX NUMBERS)

12. Press Set

13. To continue, press Data Registration

14. Repeat steps No. 7 to No. 12

15. To end, press Stop 





C. TO PROGRAM GROUP DIAL

1. Open One-Touch Speed Dial panel

2. Press Data Registration

3. Press ∨

∨∨

∨to display “2. TEL REGISTRATION”

4. Press Set

5. Press ∨

∨∨

∨to display “3. GROUP DIAL”

6. Press Set

7. Press ∨

∨∨

∨(if necessary) until an empty space appears

8. Press Set twice

9. Close panel cover & press desired one-touch keys

& / or the coded speed dial numbers

10. Press Set twice

11. Enter name for the above group dialer (refer to A.9. on III : TO

STORE FAX NUMBERS)

12. Press Set

13. To continue, press Data Registration

14. Repeat steps No. 7 to No. 12

15. To end, press Stop 





IV TO ERASE A SPEED DIAL

A TO CANCEL A NUMBER IN THE ONE-TOUCH SPEED DIAL

1. Follow steps A.1. to A.4. (Refer to III : TO STORE FAX NUMBERS :

ONE-TOUCH SPEED DIAL)

2. Close panel cover & press desired one-touch key

3. Press

Set twice

4. Press

Clear

5. Press

Set

6. Press

Stop 





B TO CANCEL A NUMBER IN THE CODED SPEED DIAL

1. Follow steps B.1. to B.6. (Refer to III : TO STORE FAX NUMBERS :

CODED SPEED DIAL)

2. Press

CODED DIAL followed by the relevant two-digit code

3. Press

Set twice

4. Press

Clear

5. Press

Set

6. Press

Stop 





C TO CANCEL A GROUP DIALER

1. Follow steps C.1. to C.6. (Refer to III : TO STORE FAX NUMBERS

: GROUP DIAL)

2. Close panel cover & press the desired group dialer using one-touch key OR

CODED DIAL & the relevant two-digit code

3. Press

Set twice

4. Press

Clear for each of the speed dialers that are to be deleted

5. To confirm, press Set

6. Press

Set again if the name of the group dialer remains unchanged

7. Press

Stop 





V SENDING TO MORE THAN ONE LOCATION

(SEQUENTIAL BROADCASTING)

A. USING ONE-TOUCH / CODED SPEED DIAL

1. Place documents face down on the feeder

2. Press all the relevant one-touch / coded-dial numbers one right after

another

3. If there is one more destination to be dialed manually, enter the number

using the numeric 10-key pad

4. Press Start/Copy 





5. Take note of “ TX / RX ” number

N.B. Please check on the MULTI TRANSACTION REPORT which

will be generated out after the broadcast is completed to ensure that

the broadcast is successful.

VI TO SEND DOCUMENTS AT A LATER TIME

(DELAYED TRANSMISSION)

1. Open One-Touch Speed Dial panel

2. Press Delayed Transmission

3. Press Set

4. Enter the desired time (time set must be within 24 hours from the

time on the display)

5. Press Set

6. Enter the fax number

7. Press Start/Copy 





8. Place documents face down on the machine

9. Take note of “ TX / RX ” number

Machine will now scan documents into the memory.
