Canon PIXMA iX6820 Manuale di istruzioni
<< Previous Next >>
Getting Your Printer
Back On Your Network
After A Router Or Network Change
PIXMA iX6820
Windows and Mac OS
1
If any of the following situations exist
•You have replaced your Router or Access Point
•You want to use a different wireless network
•Router settings have been changed.
Please complete the following steps to apply the new
configuration settings to your printer.
2
<< Previous Next >>
Preparing to Connect My Printer
To My Network << Previous Next >>
Network Requirements
Before connecting the machine to the network, make sure that configuration of the computer and access point or router is
complete, and that the computer is connected to the network.
Wireless Connection
Before connecting the machine to the network, the computer needs to be connected to the network. Make sure that
configuration of the computer and access point or router is complete.
3
Connect the PIXMA iX6820 to Your Wireless Network
To re-establish communication on the network after changing the router / Access Point or when connecting to a different network, the settings
on the printer need to be changed
Simply insert the Setup CD-ROM that came with your printer into your CD-ROM drive and proceed through the easy to follow instructions On the
following screen, select the Start Setup Again option
Connecting to the Network
4
<< Previous Next >>
Connecting to the Network
5
<< Previous
5
On the Connection Method
Selection screen, be sure to
select Wireless Connection.
Next >>
When the Printer Setup screen appears, click
Connect to the Network. You will be setting up
the printer the same way as a first-time setup.
When the Preparation for Connection screen appears, make sure the printer is turned on, then
click Next.
Installing the Drivers & Software
- Connecting to the wireless network
66
Select Cableless setup on Setup Procedure Selection screen (3-1).
Installing the Drivers & Software
- Connecting to the wireless network
77
As instructed, press and hold the Wi-Fi button (A) until the white power lamp flashes 2 times and then release. Once that is done, select
the Next button.
Connecting to the Network
8
<< Previous
8
If you can’t find your CD-ROM, you may download the iX6820 series Mini Master Setup, which includes the same step-by-step installation as the
CD-ROM, by following the instructions below:
1. Click here to access the iX6820 Drivers & Software page.
2. Select the operating system and version of your computer (see example below).
3. Expand the ‘Drivers’ section, if necessary, by clicking the red triangle.
4. Click on ‘iX6800 series Mini Master Setup…’ .
5. After reading the details and disclaimer, click ‘I Agree – Begin Download’ and save the file to your computer.
6. Once the download is complete, double-click the file from its download location to begin the installation.
7. Follow the same instructions as when using the Setup CD-ROM. See the previous page
