Canon CANOSCAN FB1210U Manuale utente

APR. 2000 JY8-1316-00Z

REVISION 0

SERVICE

MANUAL

Printed in Japan

Imprimè au Japon

Use of this manual should be strictly supervised

to avoid disclosure of confidential information.

CanoScan FB1210U F91-4411 AZG000000-

F91-4431 CZG000000-

F91-4441 DZG000000-

F91-4451 EZG000000-

F91-4461 FZG000000-

F91-4471 LZG000000-

F91-4421 MZG000000-

F91-4491 JZG000000-

LIST OF SERIAL NUMBER

2000 CANON INC. CANOSCAN FB1210U REV.0 APR. 2000 PRINTED IN JAPAN (IMPRIME AU JAPON)

CONTENTS

I. SPECIFICATIONS....................... 1-1

II. PARTS CONFIGURATION ........... 1-2

A. Front View .......................... 1-2

B. Rear View ............................ 1-2

III. SETTING UP THE SCANNER ...... 1-3

A. Precautions ......................... 1-3

CHAPTER 2 : OPERATION AND TIMING

CHAPTER 1 : GENERAL DESCRIPTIONS

I. BASIC OPERATION .................... 2-1

A. Functions ............................ 2-1

B. Electrical System ................ 2-2

C. Main PCB Input and Output. 2-4

D. Basic Sequences of Operations

........................................... 2-5

II. OPTICAL SYSTEM ..................... 2-7

A. Scanning Lamp .................... 2-8

B. Motor Control ..................... 2-9

III. IMAGE PROCESSING ............... 2-10

A. Outline .............................. 2-10

B. Image Processing............... 2-11

C. Calibration ........................ 2-13

D. Filter Processing ............... 2-14

E. Interpolation Processing.... 2-15

F. Averaging .......................... 2-16

G. Binary Processing .............. 2-17

H. Image Inversion

(negative/positive) ............ 2-18

IV. CONTROL SYSTEM .................. 2-19

A. Control System Diagram.... 2-19

B. Main PCB .......................... 2-19

V. INTERFACE ............................. 2-20

A. Overview of the USB Standard

......................................... 2-20

B. Benefits of the USB Scanner

......................................... 2-20

C. Signal Definitions .............. 2-21

D. Interface Connection ......... 2-21

VI. POWER SUPPLY ....................... 2-22

B. Unlocking the Scanning Unit 1-4

C. Connecting the Cables......... 1-5

D. Scanning a Document.......... 1-6

IV. CUSTOMER’S DAILY MAINTENANCE

........................................... 1-7

2000 CANON INC. CANOSCAN FB1210U REV.0 APR. 2000 PRINTED IN JAPAN (IMPRIME AU JAPON)

I. INTRODUCTION......................... 5-1

A. Initial Check ....................... 5-1

B. Others ................................. 5-1

II. TROUBLESHOOTING FLOWCHART

........................................... 5-2

A. Power ON Failure

Troubleshooting Flowchart .. 5-2

B. Communication Failure

Troubleshooting Flowchart .. 5-3

III. PROBLEM, CAUSE AND

CORRECTIVE ACTION ............... 5-4

A. Power LED Not Lighting....... 5-4

B. Communication Failure ....... 5-4

C. Carriage Movement Failure.. 5-5

D. Poor Image Quality .............. 5-5

E. Noise Generated .................. 5-5

IV. CANON SCANNER TEST ............. 5-6

A. Outline ................................ 5-6

B. Operating Environment ....... 5-6

C. Functions ............................ 5-6

D. Functions Descriptions ....... 5-7

E. Error Message ................... 5-15

CHAPTER 5 : TROUBLESHOOTING

CHAPTER 4 : MAINTENANCE AND SERVICING

I. PERIODICAL REPLACEMENT

PARTS ....................................... 4-1

II. CONSUMABLE PARTS

DURABILITY.............................. 4-1

III. PERIODICAL SERVICING ........... 4-1

IV. SPECIAL TOOLS ........................ 4-1

V. SOLVENTS AND LUBRICANTS .... 4-1

CHAPTER 3 : MECHANICAL SYSTEM

I. PARTS REPLACEMENT .............. 3-1

A. Precautions ......................... 3-1

II. EXTERNALS .............................. 3-2

A. Removing the Document Cover

........................................... 3-2

B. Removing the Top Cover and

Document Glass Assembly ... 3-3

III. PCBs ......................................... 3-4

A. Removing the Main PCB ...... 3-4

B. Removing the Button PCB ... 3-6

IV. OPTICAL SYSTEM ..................... 3-8

A. Removing the Carriage Assembly

........................................... 3-8

B. Removing the Motor Assembly

......................................... 3-14

CHAPTER 6 : PARTS CATALOG

FIGURE 001 .............................. 6-2 FIGURE 100 .............................. 6-4

2000 CANON INC. CANOSCAN FB1210U REV.0 APR. 2000 PRINTED IN JAPAN (IMPRIME AU JAPON)

APPENDIX

I. GENERAL CIRCUIT DIAGRAM .... A-1 II. MAIN PCB CIRCUIT DIAGRAM ... A-2

2000 CANON INC. CANOSCAN FB1210U REV.0 APR. 2000 PRINTED IN JAPAN (IMPRIME AU JAPON)

CHAPTER 1

GENERAL DESCRIPTIONS

I. SPECIFICATIONS....................... 1-1

II. PARTS CONFIGURATION ........... 1-2

A. Front View .......................... 1-2

B. Rear View ............................ 1-2

III. SETTING UP THE SCANNER ...... 1-3

A. Precautions ......................... 1-3

B. Unlocking the Scanning Unit 1-4

C. Connecting the Cables......... 1-5

D. Scanning a Document.......... 1-6

IV. CUSTOMER’S DAILY MAINTENANCE

........................................... 1-7

CHAPTER 1

1 - 1

2000 CANON INC. CANOSCAN FB1210U REV.0 APR. 2000 PRINTED IN JAPAN (IMPRIME AU JAPON)

I. SPECIFICATIONS

Main Unit

Type : Flatbed image scanner

Reading Unit

Image sensor : 10,550-pixel 3-line CCD

Light source : Cold cathode fluorescent lamp

Document type : Sheet, Book

Document alignment position : Right-end corner

Max. document size : A4/Letter size (216 x 297mm)

Image output mode : Color 14-bit for RGB each

Grayscale (256 gradations)

Binary (black and white)

Optical resolution : 1200 dpi x 2400 dpi

Scanning time : 7 min. and 10 sec. (color, A4, 1200 dpi)

3 min. (grayscale, A4, 1200 dpi)

7 sec. (binary, A4, 1200 dpi)

Cropping of scan area : One rectangular area only

Interface

Interface : USB (Universal Serial Bus) 1.1

Others

Operating environment : Temperature : 10 to 35 degrees

Relative humidity : 20 to 80%RH

Air pressure : 608 to 1013 hPa

Power consumption : 15 W or less (during operation)

8 W (during standby)

Dimensions : 286.0 (Width) x 461.0 (Depth) x 92.5 (Height) mm

Weight : Approx. 3.8 kg

Option : Film Adapter Unit FAU-S11

Specifications are subject to change without prior notice.
