Canon CanoScan LiDE 35 Manuale utente

English

Quick Start Guide

Setup and Scanning

Try the Additional Features

Check the Package Contents

Install the Software

Windows

Macintosh

Unlock the Scanning Unit

Connect the Scanner

Try Scanning

Using the Scanner Buttons

Using the USB 2.0 Interface

expansion cards (Windows Only)

Be sure to install the software programs before connecting the scanner

to the computer!

Please read this guide before operating this scanner. After you finish reading this guide, store it in

a safe place for future reference.

Guide to the Manuals

• CanoScan and ScanGear are trademarks of Canon Inc.

• Adobe® and Acrobat®are trademarks of Adobe Systems Incorporated.

• Microsoft and Windows are registered trademarks of Microsoft Corporation in the U.S. and other countries.

• Macintosh, Power Macintosh and Mac OS are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.

• ScanSoft and OmniPage are trademarks of ScanSoft, Inc.

• Other names and products not mentioned above may be trademarks or registered trademarks of their respective companies.

In this guide, Windows XP screen shots are used to illustrate explanations common to all operating systems.

Open the Package

Quick Start Guide (this guide)

This guide describes a series of processes, from opening the package to using the

scanner.

READ THIS GUIDE FIRST!

Scanning Guide (HTML format manual)

Refer to this guide when you have finished setting up the scanner according to the procedures

in the Quick Start Guide. It describes how to utilize the scanner with the bundled software,

and how to solve problems when they occur. You can install this manual onto the hard disk

together with the software programs. When you install it, the Scanning Guide icon will appear

on the desktop. Double-click the icon to view it with a browser program, such as Internet

Explorer.

User’s Guides for Application Programs (PDF format manuals)

• ArcSoft PhotoStudio

• ScanSoft OmniPage SE

Select the “View the Electronic Manuals” menu on the CanoScan Setup Utility CD-ROM. To

read these manuals, Adobe Acrobat Reader should be installed on your computer.

The socket-outlet shall be installed near the equipment and shall be easily accessible.

Use of a shielded cable with the ferrite core(s) provided with the scanner is necessary to comply with the technical

requirements of the EMC Directive.

Warning

When you use this product, you should pay attention to the following legal issues:

• Scanning of certain documents, such as bank notes (bank bills), government bonds and public certificates, may be

prohibited by law and may result in criminal and/or civil liability.

• You may be required under law to obtain authorization from a person possessing copyrights or other legal rights to

the item being scanned.

If you are uncertain of the legality of scanning any particular item, you should consult your legal adviser in advance.

HTML

PDF

Check the Package Contents

English

Check the Package Contents

Scanner and Accessories

Documents and Software Programs

• Quick Start Guide (this guide)

• Additional Documents

• CanoScan Setup Utility CD-ROM

• The two figures in the brackets below indicate the respective sizes of the Windows/

Macintosh versions of the software.

• Approximately 200 MB/ 160 MB (for Windows/Macintosh) of hard disk space on your

computer is required to install all the programs. Additional free hard disk space is

required to operate the programs.

ScanGear CS (25 MB / 10 MB) - Scanner Driver

It allows you to scan and load images from the scanner.

CanoScan Toolbox (15 MB / 10 MB) - Scanning Utility Program

It enables you to scan images and copy (print), attach images to e-mail messages or save images with

simple steps. It also works with the scanner buttons.

ArcSoft PhotoStudio (35 MB / 20 MB) - Image Editing Program

It allows you to load images from the scanner, edit and retouch them, and apply special effects and

enhancements.

ScanSoft OmniPage SE (90 MB / 80 MB) - OCR (Optical Character Recognition) Program

It converts characters scanned from a book, magazine or newspaper into text data for editing or

digital transmission.

Adobe Acrobat Reader (25 MB / 30 MB) - PDF File Reader Program

Electronic manuals for the above software programs (HTML (10 MB) and PDF manuals)

CanoScan LiDE 35 USB Interface Cable Stand (P. 7)

Install the Software (Windows)

1Turn the computer on.

2Place the CanoScan Setup Utility CD-ROM in the drive.

After you select your language, the CanoScan Setup Utility main

menu will display.

3Click [Install the Software].

Read the SOFTWARE USER LICENSE AGREEMENT. Click [Yes] if

you accept the terms.

The [Install] window will display.

4Click [Start Installation].

You will install five software programs and the Scanning Guide

(HTML format manual).

5The installation procedure will start.

Follow the on-screen message prompts and click [Next] or [Yes]

to continue the installation.

6When the installation is complete, click [Yes].

The computer will restart.

7After Windows restarts, remove the CD-ROM from

the drive and store it in a safe place.

Continue on P. 6.

• With Windows XP/2000, you should log on with

an administrator user name when you install or

uninstall software programs.

• If you are using a computer which does not

equip USB 2.0 interface by standard, refer to

P. 12.

If the "Found New Hardware Wizard" or

"Add New Hardware Wizard" appears, click [Cancel].

• In few cases, your operating system may

require a restart. Follow the on-screen

messages to restart and resume installation.

Windows

Install the Software (Macintosh)

English

Install the Software (Macintosh)

1Turn the computer on.

Make sure to log in with the first created administrator to install the software. You cannot install the

software when logged in using added administrator accounts.

2Place the CanoScan Setup Utility CD-ROM in the

drive.

3Double-click the CD-ROM icon.

4Double-click the [SetUp] icon.

After you select your language, the CanoScan Setup Utility

main menu will display.

5Click [Install the Software].

Read the SOFTWARE USER LICENSE AGREEMENT. Click [Yes] if

you accept the terms.

The [Install] window will display.

6Click [Start Installation].

You will install five software programs and the Scanning Guide

(HTML format manual)

7The installation procedure will start.

Follow the on-screen message prompts and click [Next], [Yes]

or [Install] to continue the installation.

If a verification dialog appears, input the Administrator’s name

and password.

8When the installation is complete, click [Yes].

The computer will restart.

9After restarting, remove the CD-ROM from the drive

and store it in a safe place.

Macintosh

Unlock the Scanning Unit

1Peel the seals off the scanner.

2Gently turn the scanner over.

3Push the lock switch toward the unlock mark ( ).

4Return the scanner to a horizontal position.

• Unlock the scanning unit before connecting the scanner to the computer. If it is left

locked, a malfunction or other problem may occur.

• Do not tilt the scanner more than 90 degrees from horizontal when releasing the lock.

• When locking the scanner, do not lift up the back and tilt the front (scanner button

location) downward. You may be unable to set the lock.

• When carrying or transporting the scanner, always lock the scanning unit by pushing the

lock switch toward the lock mark ( ).

Lock Switch

Unlock Mark

Connect the Scanner

English

Connect the Scanner

1Peel the caution seal from the back of the scanner.

2Connect the scanner to the computer with the supplied USB interface cable.

Using the Scanner in the Upright Position

Installing the Stand Removing the Stand

Positioning an item

• Make sure that the scanning unit is unlocked. (P. 6)

• Only use the USB interface cable provided with the scanner. Use of other cables may

lead to a malfunction.

• The scanner does not have a power switch. The power is activated as soon as the

computer is turned on.

• When the scanner is connected to the USB 1.1 port on Windows XP, do not worry if the

"HI-SPEED USB Device Plugged into non-HI-SPEED USB Hub" message appears. You can

operate the scanner in this condition without problems.

USB Interface Cable

Wide Flat Connector Small Square Connector

USB Connector

Removing the stand.

Press the hook.

Try Scanning

The following steps explain how to scan with ArcSoft PhotoStudio.

1Place a photo or a picture on the glass

by aligning its top edge with the

alignment mark, and close the

document cover.

Alignment

Mark

Bottom

Top

2Select [Start], [Programs] or [All

Programs], [ArcSoft PhotoStudio 5.5]

and [PhotoStudio 5.5].

PhotoStudio will start.

Windows

2Double-click the [Applications] folder

followed by the [PhotoStudio] folder

and the [PhotoStudio] icon.

PhotoStudio will start.

Macintosh

Try Scanning

English

3Click the [File] menu and choose [Select Source].

Select your scanner model name and click the [Select] button

for Windows or the [OK] button for Macintosh.

4Click the Acquire icon or click the [File] menu

and select [Acquire].

ScanGear CS will start.

5Select the [Select Source].

You can select from the following options.

Photo (Color)/Magazine (Color)/Newspaper (B&W)/Document

(Grayscale).

6Click [Preview].

After calibration, the preview scan will start and gradually

display the image.

The image is automatically cropped at its original size.

If you want to trim the image further, drag the mouse

diagonally to select the area.

7Select the [Destination].

You can select [Print] or [Image display].

When [Print] is selected, the output resolution is set to 300 dpi.

When [Image display] is selected, it is set to 150 dpi.

[Print] is selected in this example.

• After you set this setting the first time, you

do not need to set it from the second time

onward with the same scanner.

• You will need to reset this setting if you

select a different scanner or a digital

camera.

• Do not open the document cover while a

scan is in progress.

Try Scanning

8Select the [Output Size].

You can select from the following options.

• If you selected [Print] in Step 7:

Flexible / 4"x6" / A4 / Letter / Custom Settings

• If you selected [Image display] in Step 7:

Flexible / 640 x 480 / 800 x 600 / 1024 x 768 / 1600 x 1200 /

2048 x 1536 / Custom Settings

With the [Flexible] option, the scan area enclosed by the

dotted line (cropping frame) will be scanned at the same scale

as the original. You can change the cropping frame.

If you selected [Print] in Step 7, you can select the 4" x 6", A4,

Letter, and Custom Settings options. Expand or decrease the

cropping frame to correspond to the size of the paper for

printing.

If you selected [Image Display] in Step 7, you can select an

output size in pixels to match the sizes used by computer monitors and digital cameras.

9Click [Scan].

The final scan will start.

10Click close box (Windows) or (Macintosh) in

the ScanGear CS window to close it.

The scanned image will appear in the PhotoStudio window.

11Save the scanned image.

Click the [File] menu and select [Save As]. Select the folder

where you wish to store the image file, enter a file name,

select a file type (JPEG format is recommended) and click

[Save].

12Click close box (Windows) or (Macintosh) in

the PhotoStudio window to close it.

• If the scanner does not perform as described above, read the "Troubleshooting" section

of the Scanning Guide (HTML format manual).

• For details about the bundled software programs, read the Scanning Guide or the User’s

Guide (PDF format manual) for each software program on the CanoScan Setup Utility

CD-ROM.

Altri manuali per CanoScan LiDE 35

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Canon Scanner

Canon

Canon DR 7090C - imageFORMULA - Document Scanner Manuale utente

Canon

Canon DR-2020U - imageFORMULA - Document Scanner Manuale utente

Canon

Canon DR 2010C - imageFORMULA - Document Scanner Manuale utente

Canon

Canon CR-180 Manuale utente

Canon

Canon CanoScan LiDE 30 Manuale utente

Canon

Canon 5600F - CanoScan - Flatbed Scanner Manuale utente

Canon

Canon IMAGE FORMULA DR-6010C Manuale utente

Canon

Canon DR-S130 Manuale utente

Canon

Canon FB620U - CanoScan - Flatbed Scanner Istruzioni per l'installazione

Canon

Canon ImageFormula DR-7080C Manuale utente

Canon

Canon MS-500 Manuale utente

Canon

Canon DR 5010C - imageFORMULA - Document Scanner Manuale utente

Canon

Canon 5600F - CanoScan - Flatbed Scanner Istruzioni per l'uso e l'installazione

Canon

Canon imageFORMULA DR-G1100 Production Document... Manuale utente

Canon

Canon DR-X10C - imageFORMULA - Document Scanner Manuale utente

Canon

Canon imageFormula DR-C225 Manuale utente

Canon

Canon CANOSCAN N650U Manuale utente

Canon

Canon Microfilm Scanner 400 Manuale utente

Canon

Canon imageFORMULA DR-S150 Manuale utente

Canon

Canon 8600F - CanoScan Manuale utente

Canon

Canon DR-4010C - imageFORMULA - Document Scanner Manuale utente

Canon

Canon 4400F - CanoScan - Flatbed Scanner Manuale utente

Canon

Canon ScanFront 300e Manuale utente

Canon

Canon DR 7090C - imageFORMULA - Document Scanner Manuale utente

Manuali Scanner popolari di altre marche

Plustek

Plustek Scanner Manuale utente

Z/I Imaging

Z/I Imaging PhotoScan 2001 Manuale utente

Renkforce

Renkforce DS100-5M Manuale utente

Image Access

Image Access WideTEK A2 Manuale utente

Fujitsu

Fujitsu FI-4860C2 Manuale utente

GeoSlam

GeoSlam ZEB Horizon Istruzioni per l'installazione

Kodak

Kodak i5800 Scanner Manuale utente

Kodak

Kodak i7300 Manuale utente

Revopoint

Revopoint POP Manuale utente

Fujitsu

Fujitsu fi-4860C Manuale utente

Eddyfi Technologies

Eddyfi Technologies Floormap X Manuale utente

Faselase

Faselase F6 Manuale utente

Fujitsu

Fujitsu CardMinder Manuale utente

Uniden

Uniden BC340CRS Manuale utente

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Manuale utente

Mustek

Mustek PageExpress 4800 Pro Manuale utente

Optex

Optex 750830 Manuale utente

Innova

Innova 5210 Manuale utente
