UNIVERSAL DOCUMENT SCANNER
PRECAUTIONS
1
The DR-7080C is a universal scanner that offers high-speed scanning in black and
white, grayscale, and color. To ensure optimum performance, please follow the
recommendations below.
●Make sure that your documents are within the acceptable scanning sizes.
Width: 5.5 to 12 inches (139.7 to 304.8 mm)
Length: 5 to 17 inches (128 to 432 mm)
Long Document Mode: document length can be up to 24 inches (630 mm)
Long Document Mode/Color 600 dpi Mode: length up to 21 inches (540 mm)
Document thickness:
Black and white documents: 0.06 to 0.15 mm (Simplex), 0.07 to 0.15 mm (Duplex)
Mixed batches (black and white, color documents): 0.07 to 0.15 mm
Color documents: 0.08 to 0.15 mm
Document weight:
Black and white documents (Simplex): 11 to 32 lb. bond (42 to 128 g/m2)
Black and white documents (Duplex): 13 to 32 lb. bond (50 to 128 g/m2)
Mixed batches (black and white, color documents): 13 to 32 lb. bond (50 to 128 g/m2)
Color documents: 17 to 32 lb. bond (64 to 128 g/m2)
●Turn on the Long Document Mode to scan long documents. (See p.9)
●If there is any wet ink or paste on the document, wait until the ink or paste has thoroughly
dried before scanning the document.
●Always clean the scanning rollers after scanning a document that has pencil writing on it.
●If you scan thin paper in Duplex mode, the ink printed on the back side may appear in your
image data. Adjust scanning density to avoid this.
●Scanning documents with a rough surface may cause a paper jam. To avoid this, select
[Flatbed] and scan the documents one page at a time.
●When you scan a batch of NCR documents, make sure they are not stuck together. If a
jam occurs, select [Flatbed] and scan the documents one page at a time.
Refer to Chapter 4.1 of the DR-7080C Instructions manual for further details on acceptable document types.
■ DOCUMENT TYPES TO AVOID
Feeding such documents may result in paper jams, damage to documents, or scanner malfunction. To scan these
documents, use the flatbed (platen glass) instead.
Wrinkled or
creased paper
Curled paper
Torn paper
Paper with clips
or staples
Carbon-backed paper
Coated paper or fax
recording paper
Onion skin or
other thin paper
Paper with binding
holes
SCANNING BASICS
GETTING STARTED
This section explains the basic steps involved in scanning a
document. Batches are assumed to contain papers all of the same
size and thickness. When turning ON the power, be sure to turn ON
the scanner before you turn ON the connected computer.
2
The purpose of this Quick Reference is to provide a
concise overview of the DR-7080C. It is designed to
supplement—not replace—the Instructions manual
included with the scanner. Please review the DR-
7080C Instructions manual for key information on
safety precautions, installation procedures, and
maintenance guidelines.
▲
Load Limitation Mark
Do not exceed this mark.
Overloading the feeder may
cause jamming.
1
FEEDER To prepare the feeder for scanning, adjust the slide guides to the
appropriate document size. Also, align the edges of your documents
to ensure smooth feeding. Documents are loaded into the feeder with
the scanning side face up.
If you are scanning large-sized NCR paper or thin paper, place some paper in the
document eject tray before scanning. For details, refer to Chapter 4.2 of the DR-7080C
Instructions manual.
▲
Slide Guides
FLATBED
▲
■ How to use the flatbed
First, raise the feeder. Documents are to be placed on the platen glass
with the scanning side face down. The corner of the document should be
aligned with the upper left corner of the platen glass. When you lower the
feeder, do this slowly and carefully.
■ Scanning a book or thick document
When scanning thick documents or books, either leave the feeder raised
or operate the feeder as shown below.
A. Raise the feeder. While pressing on the bottom of the feeder (1), pull
the feeder down and forward (2).
B. Set the thick document or book on the platen glass and hold the feeder
lightly while scanning.
C. To return the feeder to its original position, raise it all the way (1) and
then close it slowly and carefully (2).
3
SCANNING BASICS
1
(2)
(1)
(1)
(2)
AB C
Book or Thick Document
1.96"(50 mm)
SCAN SETTINGS The DR-7080C is operated via the bundled ISIS/TWAIN driver, which
is compatible with a wide range of application software. Prior to
scanning, use the ISIS/TWAIN driver to select the scanning side,
feeding option, and any other setting you require.
▲
4
SCANNING BASICS
1
■ Standard:
Select this mode when you wish to use your application software to
start or stop scanning.
■ Panel:
Select this mode if you need to continuously scan multiple batches or
scan a book page by page. In this mode, scanning starts by pressing
the scanner’s built-in [Start] key.
■ Automatic:
For feeder use only. Select this mode to scan batches of documents
with the feeder. The scanner will start automatically when it detects a
document in the document feeder tray.
Feeding Option
Scanning Side
SCANNING SIDE
▲
FEEDING OPTION
▲
■ For feeder scanning: Select [Simplex] or [Duplex].
■ For flatbed scanning: Select [Flatbed].
5
SCANNING BASICS
1
To finish scanning, execute the required command from the application.
STEP 1Set [Scanning Side] and [Feeding Option] in the ISIS/TWAIN driver.
▲
STANDARD FEEDING
STEP 2Place the document on the scanner.
▲
STEP 3From the application you are using, execute the required command to
start scanning.
▲
STEP 4When scanning of the document is complete, the application goes into
Ready Mode. If you wish to scan another document, repeat steps 2
and 3.
▲
6
PANEL FEEDING
SCANNING BASICS
1
STEP 1Set [Scanning Side] and [Feeding Option] in the ISIS/TWAIN driver.
▲
STEP 2From the application you are using, execute the required command to
start scanning. The [Start] key lamp will turn green.
▲
STEP 3Place the document on the scanner.
▲
STEP 4Press the [Start] key.
▲
STEP 5When scanning of the document is complete, the scanner goes into
Ready Mode. If you wish to scan another document, repeat steps 3
and 4.
To finish scanning, press the [Stop] key.
▲
7
SCANNING BASICS
1
STEP 1Set [Scanning Side] and [Feeding Option] in the ISIS/TWAIN driver.
▲
AUTOMATIC FEEDING
STEP 2From the application you are using, execute the required command to
start scanning. The [Start] key lamp will turn green.
▲
STEP 3Load the document into the document feeder tray. Scanning will start
automatically when the sensor on the document feeder tray detects
the document.
▲
STEP 4When scanning of the document is complete, the scanner goes into
Ready Mode. If you wish to scan another document, repeat step 3.
To finish scanning, press the [Stop] key.
▲
8
SCANNING BASICS
1
USING THE JOB MODE
Job functions provide an easy way to scan documents to specific
folders, printers, and e-mail addresses.
For further details on the Job function, refer to Chapter 4.4 of the DR-7080C
Instructions manual.
STEP 2Use the Job [▲] and [▼] keys to select the number of the job (01
through 99) you want.
▲
STEP 3Place the document on the scanner.
▲
STEP 4Press the [Start] key.
When scanning of the document is complete, press the [Stop] key to exit the Job Mode.
▲
STEP 1Press the Job [▲] key to enter the Job Mode.
▲
