Caple CM465 Manuale utente
Sense Coffee Machine
Instruction manual
CM465, CM465SS
& CM465GM
Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk
Instruction manual CM465 / CM465SS / CM465GM2Please keep this instruction manual for future reference
CONTENTS
Introduction 3
Product Overview 9
Control Panel 10
Preparation 11
Operation 13
Using Menu Options 23
Water Hardness 24
Setting The Coffee Temperature 25
Setting The Switch-Off Time 25
Carrying Out The Descaling 26
Statistics 28
Resetting Settings 28
Setting The Clock 29
Cleaning 31
Messages 36
Troubleshooting 38
Installation Instructions 40
Caple Contact Details 44
3
Please keep this instruction manual for future reference Instruction manual CM465 / CM465SS / CM465GM
INTRODUCTION
This coffee machine will make delicious cups of coffee, espresso and cappuccino. You can
customise the settings of the machine to suit your personal preferences and tastes.
Coffee has been used in the factory to test the appliance and it is therefore completely normal
that there are traces of coffee in the mill. This appliance is however guaranteed to be new. First
read the user instructions carefully and completely before starting to use the appliance, and keep
them carefully for future reference.
PREVENTATIVE MAINTENANCE
Your coffee machine requires preventative maintenance. To guarantee that the coffee machine
works well and reliably, we recommend having the machine serviced once every 2 to 3 years
(after a maximum 8,000 cups).
Servicing of your coffee machine is chargeable, and can be booked via email service@caple.co.uk
or telephone 0117 938 7420.
WARNING:
-Designated use: this appliance is designed and made
to prepare coffee and milk based beverages and hot
water. Any other use is considered improper and thus
dangerous. The manufacturer is not liable for damage
deriving from improper use of the appliance.
-The surface of the heating element remains hot after use
and the outside of the appliance may retain the heat for
several minutes depending on use.
-CAUTION: To prevent damage to the appliance do not
use alkaline cleaning agents when cleaning, use a soft
cloth and a mild detergent
Instruction manual CM465 / CM465SS / CM465GM4Please keep this instruction manual for future reference
-WARNING: Models with glass surfaces: do not use the
appliance if the surface is cracked.
-The appliance and its accessible parts become hot during
use. Care should be taken to avoid touching heating
elements.
-The appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
-Children should be supervised to ensure that they do not
play with the appliance.
-Cleaning and user maintenance shall not be made by
children without supervision.
-Never clean by immersing the appliance in water.
-This appliance is intended to be used in household and
similar applications such as:
-Staff kitchen areas in shops, offices and other working
environments.
-Farm Houses.
-Appliances with removable cord: avoid splashes of water
on the power cord connector or socket at the back of the
appliance.
-Clean all the components thoroughly, taking particular
care with parts in contact with the coffee and milk.
5
Please keep this instruction manual for future reference Instruction manual CM465 / CM465SS / CM465GM
-By clients in hotels, motels and other residential type
environments.
-Bed and breakfast type environments.
-If the plug or power cable is damaged, it must be
replaced by customer services only to avoid all risk.
-This appliance can be used by children aged from 8
years and above if they have been given supervision or
instruction concerning use of the appliance in a safe way
and if they understand the hazard involved. Cleaning
and user maintenance shall not be made by children
unless they are older than 8 and supervised. Keep the
appliance and its cord out of the reach of children aged
less than 8 years.
-Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
-Children shall not play with the appliance.
-When not in use and before cleaning, always unplug the
appliance.
-This appliance is intended for domestic use only (around
3000 cups a year). Any other use is considered improper
and in that case no guarantee will be given.
-Use it with care to avoid scalds from the water and
steam jets or through incorrect use.
Instruction manual CM465 / CM465SS / CM465GM6Please keep this instruction manual for future reference
-Do not lean or hang on the machine when it has come
out of the cabinet and do not place heavy or unstable
objects on the machine.
-Surfaces marked with this symbol become hot during
use.
-This appliance can be installed over a built-in oven if the
latter is fitted with a cooling fan at the rear (maximum
microwave power: 3kW).
-The manufacturer is not liable for damage caused by
improper, incorrect or unreasonable use of the appliance.
-When using the appliance, do not touch the hot surfaces.
Use the knobs or handles.
-In case of failures, make sure the appliance is not
connected to the mains power supply. Turn the main
power switch on the right side (behind the front panel)
to 0. Refer to our service department for repairs.
-Only ask for original spare parts to be used. Failure
to respect the above could reduce the safety of the
appliance.
-Do not put objects containing liquids, inflammable or
corrosive materials on the machine.
-Use the accessories holder to contain coffee accessories
(for example coffee beans).
-Never touch the appliance with damp hands.
-Unplug directly from the plug only.
7
Please keep this instruction manual for future reference Instruction manual CM465 / CM465SS / CM465GM
-Never pull the power cable as you could damage it.
-To disconnect the appliance completely, place the
main switch on the side of the appliance in the 0 (off)
position.
-Your appliance is produced in accordance with all
applicable local and international standards and
regulations.
-Maintenance and repair work must be made only
by authorised Caple service technicians. Installation
and repair work that is carried out by unauthorised
technicians may endanger you.
-It is dangerous to alter or modify the specifications of
the appliance in any way.
-Prior to installation, ensure that the local distribution
conditions (electricity voltage and frequency) and the
requirements of the appliance are compatible.
The requirements for this appliance are stated on the
rating label.
-This appliance is designed only for cooking food and is
intended for indoor use.minimum temperature of 120°C.
Instruction manual CM465 / CM465SS / CM465GM8Please keep this instruction manual for future reference
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
This appliance is marked according to the European directive on Waste Electrical and Electronic
Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health, which could otherwise
be caused by inappropriate waste handling of this product. The symbol on the product indicates
that this product may not be treated as household waste. Instead, it shall be handed over to the
applicable collection point for the recycling of electrical and electronic equipment. Disposal must
be carried out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all applicable
legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
This appliance also conforms to all applicable UK & EU legislation relating to Materials and articles
intending to come into contact with food.
UKCA DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all
applicable legislation.
WARRANTY
Your new appliance is covered by warranty. The warranty card is enclosed - if it is missing, you
must provide the following information to your retailer in order to receive a replacement: date
of purchase, model and serial number (placed on the inside of the appliance storage drawer).
Registration can also be completed online by visiting www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service together
withproof of purchase.If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.
9
Please keep this instruction manual for future reference Instruction manual CM465 / CM465SS / CM465GM
EN 5
Product overview
A. Main switch
(Aa) - On / Off button
B. Handles
C. Nozzle
D. Water tank (removable)
E. Cup tray
F. Drip tray grill (removable)
G. Service door
H. Height adjustable coffee dispenser
I. Control panel
J. Coffee bean holder cover
K. Ground coffee chute cover
L. Brewing unit
M. Power cable
N. Milk container:
N1. Cover (removable)
N2. Slider CAFFELATTE/CAPPUCCINO
(removable)
N3. CLEAN button
N4. Milk dispenser pipe (removable)
N5. Suction pipe (removable)
O. Hot water nozzle (removable)
P. Measuring spoon for preground coffee
Q. Waste coffee container (can be taken out)
R. Knob for setting the grind level
S. Coffee bean container
T. Place for the measuring spoon
U. Filling chute for preground coffee
V. Coffee guide
W. Place for accessories (left and right)
X. IEC Connector B Aa
Aa
B
V
LQ
E
G
F H D
CY
P
I
1CAPPUCCINO
2CAFFELA TTE
N
N1
O
N2
N3
N4
N5
x
EN 5
Product overview
A. Main switch
(Aa) - On / Off button
B. Handles
C. Nozzle
D. Water tank (removable)
E. Cup tray
F. Drip tray grill (removable)
G. Service door
H. Height adjustable coffee dispenser
I. Control panel
J. Coffee bean holder cover
K. Ground coffee chute cover
L. Brewing unit
M. Power cable
N. Milk container:
N1. Cover (removable)
N2. Slider CAFFELATTE/CAPPUCCINO
(removable)
N3. CLEAN button
N4. Milk dispenser pipe (removable)
N5. Suction pipe (removable)
O. Hot water nozzle (removable)
P. Measuring spoon for preground coffee
Q. Waste coffee container (can be taken out)
R. Knob for setting the grind level
S. Coffee bean container
T. Place for the measuring spoon
U. Filling chute for preground coffee
V. Coffee guide
W. Place for accessories (left and right)
X. IEC Connector B Aa
Aa
B
V
LQ
E
G
F H D
CY
P
I
1CAPPUCCINO
2CAFFELA TTE
N
N1
O
N2
N3
N4
N5
x
A. Main switch
(Aa) - On / Off button
B. Handles
C. Nozzle
D. Water tank (removable)
E. Cup tray
F. Drip tray grill (removable)
G. Service door
H. Height adjustable coffee dispenser
I. Control panel
J. Coffee bean holder cover
K. Ground coffee chute cover
L. Brewing unit
M. Power cable
N. Milk container:
N1. Cover (removable)
N2. Slider CAFFELATTE/CAPPUCCINO
(removable)
N3. CLEAN button
N4. Milk dispenser pipe (removable)
N5. Suction pipe (removable)
O. Hot water nozzle (removable)
P. Measuring spoon for preground coffee
Q. Waste coffee container
(can be taken out)
R. Knob for setting the grind level
S. Coffee bean container
T. Place for the measuring spoon
U. Filling chute for preground coffee
V. Coffee guide
W. Place for accessories (left and right)
X. IEC Connector
Y. LED
PRODUCT OVERVIEW
Instruction manual CM465 / CM465SS / CM465GM10 Please keep this instruction manual for future reference
MENU
EXIT OK
CONTROL PANEL
1. ‘MENU’ to activate or deactivate menu
2. ‘RETURN’ to exit the selected mode
3. ‘Rinse’
4. ‘SCROLL’ to scroll forwards through the menu and display
5. ‘COFFEE STRENGTH’ to select strength or preground
6. ‘SCROLL’ to scroll backwards through the menu and display
7. Touch key to select the type/quantity of coffee (espresso, smallcup,
medium cup, large cup, mug)
8. ‘OK’ to confirm the selected function
9. Touch key ‘One cup of coffee’
10. Touch key ‘Two cups of coffee’
11. Touch key ‘Cappuccino’
12. Touch key ‘Hot water deliver’
1
2
3
4
5
6
7
8
910 11 12
Altri manuali per CM465
2
Questo manuale è adatto per i seguenti modelli
2
Indice
Altri manuali Caple Macchina per il caffè
