Car-Interface CI-RL4-UCON8-20 Manuale utente

Version 14.03.2023 HW CAN(V100)/GW2A(V20) CI- RL4-UCON8-20

Video-inserter

CI-RL4-UCON8-20

Compatible with

Jeep vehicles

with Uconnect Multimediassystem

with 8.4“ monitor

Video-inserter for front- and rear-view camera

and two additional video sources

Product features

Video-inserter for factory-infotainment systems

1 CVBS Input for rear-view camera

1 CVBS Input for front camera

2 CVBS video-inputs for after-market devices (e.g. USB-Player, DVB-T2 tuner)

Automatic switching to rear-view camera input on engagement of the reverse gear

Automatic front camera switching after reverse gear for 10 seconds

Video-in-motion (ONLY for connected video-sources)

Video-inputs NTSC compatible

Version 14.03.2023 HW CAN(V100)/GW2A(V20) CI-RL4-UCON8-20

Page2

Contents

1. Prior to installation

1.1. Delivery contents

1.2. Checking the interface compatibility of vehicle and accessories

1.3. Connectors

1.3.1. Connectors –video interface

1.3.2. Connectors - daughter PCB

1.4. Dip-switch settings

1.4.1. 8 dip –black

1.4.1.1. Activating the front camera input (dip 1)

1.4.1.2. Enabling the interface’s video inputs (dip 2-3)

1.4.1.3. Rear-view camera setting (dip 5)

1.4.1.4. Monitor adjustment (dip 6, 7 and 8)

1.4.2. 4 dip - red

2. Installation

2.1. Place of connection

2.2. Connection scheme

2.3. Installation –daughter PCB

2.3.1. Warning notes, concerning the installation of ribbon cables

2.4. Connection - picture signal cable

2.5. Connection –10pin Power / CAN cable with PNP harness

2.6. Connection –10pin Power / CAN cable without PNP section

2.7. Power supply

2.8. Power supply output

2.9. Connection –video inputs

2.9.1. Audio insertion

2.9.2. After-market front camera

2.9.3. After-market rear-view camera

2.9.3.1. Case 1: Video-interface receives the reverse gear signal

2.9.3.2. Case 2: Video interface does not receive the reverse gear signal

2.10. Connection –external keypad

3. Interface operation by external keypad

4. Picture settings

5. Specifications

6. Frequently asked questions

Version 14.03.2023 HW CAN(V100)/GW2A(V20) CI-RL4-UCON8-20

Page3

Legal Information

By law, watching moving pictures while driving is prohibited, the driver must not be

distracted. We do not accept any liability for material damage or personal injury resulting,

directly or indirectly, from installation or operation of this product. This product should only

be used while standing or to display fixed menus or rear-view-camera video when the

vehicle is moving, for example the MP3 menu for DVD upgrades.

Changes/updates of the vehicle’s software can cause malfunctions of the interface. We

offer free software-updates for our interfaces for one year after purchase. To receive a free

update, the interface must be sent in at own cost. Labour cost for and other expenses

involved with the software-updates will not be refunded.

1. Prior to installation

Read the manual prior to installation.

Technical knowledge is necessary for installation. The place of installation must be free of

moisture and away from heat sources.

1.1. Delivery contents

Version 14.03.2023 HW CAN(V100)/GW2A(V20) CI-RL4-UCON8-20

Page4

Requirements

Brand

Compatible vehicles

Compatible systems

Jeep

Compass model year 2020

Renegade Facelift model year 2020

Uconnect 4C VP2RFP (Fiat 520) with 8.4 Zoll monitor,

All-in-one (danger to confuse with 4C NAV UAQ)

Limitations

Video only The interface inserts ONLY video signals into the infotainment.

For inserting Audio signals either the possibly existing factory audio-AUX-input

or a FM-modulator can be used.

In case that 2 AV sources shall be connected, a desired audio switching will

require additional electronic.

Factory rear-view camera Automatically switching-back from inserted video to factory rear-view camera is

only possible while the reverse gear is engaged. To delay the switch-back an

additional electronic part is required.

After market front camera The front camera will automatically be switched for 10 seconds after

disengaging the reverse gear. A manually front camera switching is possible by

external keypad.

Video input signal NTSC video sources compatible only.

1.2. Checking the compatibility of vehicle and accessories

1.3. Connectors

1.3.1. Connectors - video-interface

The video-interface converts the video signals of connected after-market sources in a factory

monitor compatible picture signal which is inserted in the factory monitor, by using separate

trigger options.

Version 14.03.2023 HW CAN(V100)/GW2A(V20) CI-RL4-UCON8-20

Page5

1.3.2. connectors –daughter PCB

Version 14.03.2023 HW CAN(V100)/GW2A(V20) CI-RL4-UCON8-20

Page6

1.4. Dip-switch settings

1.4.1. 8 dip - black

Some settings have to be selected by the dip-switches on the

video interface.

Dip position down is ON and position up is OFF.

In case of a non-optimal displayed picture with the mentioned dip settings of dips 6, 7 and

8, we recommend to try each other possible dip switch combination.

*The front camera will automatically be switched for 10 seconds after disengaging the

reverse gear.

See the following chapters for detailed information.

Dip

Function

ON (down)

OFF (up)

Front camera

enabled*

disabled

Power supply

output

(red wire)

+12V (max. 3A) when reverse gear

is engaged incl. 10 seconds delay

and +12V by manual switching to

front camera by keypad

+12V (max. 3A) ACC

CVBS AV1-input

enabled

disabled

CVBS AV2-input

enabled

disabled

No function

Set to OFF

Rear-view cam type

after-market

factory or none

Monitor adjustment

Set to OFF

Set to ON

Set to OFF

Version 14.03.2023 HW CAN(V100)/GW2A(V20) CI-RL4-UCON8-20

Page7

1.4.1.1. Activating the front camera input (dip 1)

If set to ON, the interface switches for 10 seconds from the rear-view camera to the front

camera input after having disengaged the reverse gear. In addition, a manual switch-over to

the front camera input is possible via keypad (short press) from any image mode.

Description of the power supply output: see chapter “Power supply output”.

1.4.1.2. Enabling the interface’s video inputs (dip 2-3)

Only the enabled video inputs can be accessed when switching through the interface’s video

sources. It is recommended to enable only the required inputs, disabled inputs

will be skipped when switching through the video-interfaces inputs.

1.4.1.3. Rear-view camera setting (dip 5)

If set to OFF, the interface switches to factory picture while the reverse gear is engaged to

display factory rear-view camera.

If set to ON, the interface switches to its rear-view camera input „Camera-IN“ while the

reverse gear is engaged.

1.4.1.4. Monitor setting (Dip 6, 7 und 8)

Dip6 and dip8 must be set to OFF.

Dip7 must be set to ON

Note: In case of a non-optimal displayed picture with the mentioned dip settings of dip6, 7

and 8, we recommend to try all other dip switch combinations.

Note: Dip4 is out of function and have to be set to OFF.

After each Dip-switch-change a power-reset of the Video Interface has to be performed!

1.4.2. 4 dip - red

By using the Dip-switches, the factory Head-unit or vehicle can be

chosen which the interface will be connected to.

Dip position down is ON and position up is OFF.

Set all dip switches to off

Vehicle/Navigation

Dip 1

Dip 2

Dip 3

Dip 4

All vehicles

OFF

Version 14.03.2023 HW CAN(V100)/GW2A(V20) CI-RL4-UCON8-20

Page8

2. Installation

To install the interface, first switch off the ignition and disconnect the vehicle’s battery.

Please read the owner`s manual of the car, regarding the battery`s disconnection! If

required, enable the car`s Sleep-mode (hibernation mode)

In case the sleep-mode does not succeed, the disconnection of the battery can be done

with a resistor lead.

As with any installation of retrofit equipment, a stand-by test is neccessary after the

installation of the video interface, to ensure that the unit also switches off after reaching

the vehicle‘s sleep mode.

Before the final installation, we recommend a test-run of the interface. Due to changes in

the production of the vehicle manufacturer, there’s always the possibility of

incompatibility.

2.1. Place of connection

The daughter PCB has to be installed and connected inside the factory head unit behind the

monitor panel.

The video Interface has to be connected at the daughter PCB inside and at the rear-side of

the head-unit.

Version 14.03.2023 HW CAN(V100)/GW2A(V20) CI-RL4-UCON8-20

Page9

2.2. Connection Scheme

Version 14.03.2023 HW CAN(V100)/GW2A(V20) CI-RL4-UCON8-20

Page10

2.3. Installation –daughter PCB

Remove the factory head-unit. The enclosed daughter PCB has to be installed into the optical lead

between the monitor panel and mainboard of the head-unit.
