Video Interface for Nissan Juke

User Manual

www.car-solutions.com

[email protected]

Car Solutions

1. Before installation

1.1 Specification

1.2 Features 4

1.3 System diagram 5

1.4 Components 6

1.5 Exterior 7

2. User interface

2.1 Dip switch

2.2 Keypad 9

2.3 Factory mode 10

2.4 Rear parking guide line 11

2.5 OSD(On Screen Display) 13

3 Troubleshooting 14

www.car-solutions.com

[email protected]

Car Solutions

INDEX CONTENTS

Input Spec.

(video interface)

- 3 x A/V Input (Rear video source)

- 1 x CVBS(Rear camera) Input (Rear camera source)

- 1 x Analog RGB Input (Navigation System output)

- 1 x LCD Input (Car system Input)

Output Spec.

- 1 x LCD Output (LCD operation)

- 4 x Audio Select (12V power comes out from 4 wires of cable by video, Navigation mode)

Power Spec.

- Input power : 10VDC ~ 16VDC

- Power consumption : 6WATT in maximum level

Switching mode

- Skip function of input video : Able to skip each input source via adjusting DIP switch.

- Able to change a mode to another by using the mode switch.

- Able to change modes and get back to the OEM screen through the genuine buttons.

www.car-solutions.com

[email protected]

Car Solutions

– Clear high definition screen

– NTSC, PAL system support

– Mode exchange via the original buttons

– Control over the position of NAVI, AV screen

– Additional function of adjusting the screen size of NAVI

www.car-solutions.com

[email protected]

Car Solutions

Keypad Switch for source toggle

OEM Navi Button (NAV)

NAVIGATION Input

(Analog RGB)

MCU

A/V 1

A/V 2

A/V 3

VIDEO

CIRCUIT

VIDEO MUX

DISPLAY Car Installation

OEM LCD

CVBS

(Rear camera)

Car Screen Input

(CAR MAIN BOARD) POWER

CIRCUIT

A/V OUT

HEADREST

MONITOR

Power Input

(+10VDC ~ +16VDC) Dip S/W

www.car-solutions.com

[email protected]

Car Solutions

AV cable *

1ea

Black wire * 1ea

I/O board * 1ea

Power cable * 1ea

Touch cable * 1ea

Mode switch * 1ea

OSD keypad with Relay * 1ea

FPC cable * 3ea

Main board * 1ea

Sub-board * 1ea

RGB cable * 1ea

LVDS cable * 1ea

Ground cable * 1ea

www.car-solutions.com

[email protected]

Car Solutions

1.5 Exterior

⑤⑥⑦⑧

⑧⑦⑥

Product dimension

⑤155mm (Horizontal length)

93mm (Vertical length)

20mm (Height)

①POWER

②MODE

③RGB (IN)

④AV(IN/OUT)

⑤LCD OUT

⑥KEYPAD

①②③④⑦DIP S/W

⑧LED

①②③④

www.car-solutions.com

[email protected]

Car Solutions

#PIN Function Usage

RGB INPUT skip

ON : RGB Mode X

OFF : RGB Display

A/V 1 skip

ON : A/V 1 X

OFF : A/V1 Display

A/V 2 skip

ON : A/V 2 X

OFF : A/V2 Display

A/V 3 skip

ON : A/V 3 X

OFF : A/V3 Display

5N.C

6N.C

Rear mode

ON : CVBS4

OFF : MAIN

Selecting original NAVI

ON : Changing mode ; Main-

Main-NAVI-AV1~3 (This is for

original Navi)

OFF : Changing mode ; Main-

NAVI-AV1~3

2.1 DIP switch

※ON : DOWN, OFF : UP default : all OFF

※DIP S/W usage example

- Input mode use : A/V2, A/V3

- Use original navigation

▷DIP S/W : 1,2



ON (INPUT MODE SKIP)

▷DIP S/W : 3



OFF (enableA/V2)

▷DIP S/W : 4



OFF (enableA/V3)

▷DIP S/W : 5, 6, 7



OFF

▷DIP S/W : 8



www.car-solutions.com

[email protected]

Car Solutions

2.2 Keypad

※FACTORY MODE (Interface setting)

: Press “UP” button about 2 seconds long and you will approach FACTORY mode. Also you can get there in pressing these

keys in this sequence; “UP” →“DOWN” →“UP” →“MENU”

Key Function

MENU/EXIT

Implement OSD screen

SEL/INPUT

Selection

Move upward, if you press about 2 seconds long, you are able to approach the FACTORY mode.

DOWN

Move downward, if you press about 2 seconds long, you are able to reset the factory mode.

www.car-solutions.com

[email protected]

Car Solutions

2.3 Factory mode

※FACTORY mode – Press “UP” button on the keypad long about 2 seconds or press these buttons in this sequence;

“UP”→”DOWN”→”UP”→”MENU”


- H-POSITION : control over the horizontal position of the screen

- V-POSITION : control over the vertical position of the screen

- H-SIZE : control over the size of NAVI screen

PARK

- PARK ENABLE : able to choose whether the rear guide line is displayed or not with rear

gear. (default-ON)

- PARK SETUP : able to adjust the position of the rear guide line with the keypad.

- SAFE ENABLE : The function that forbids drivers to change the LCD to DVD or A/V

while driving. User returns to the main screen by this function. (Default : off)

( Refer to the page#11 )

UTIL

- NAVI SELECT (N.C)

- AVOUT SELECT : making a choice of AVOUT output in the OEM & NAVI screen

(Default – AV3)

- FACTORY RESET : reset
