Carlton LQ1000 Manuale utente
safety first specifications
●Always remove the mains plug from the socket when you have
finished using the liquidizer, before you clean the liquidizer, before
you put on or remove the container or if any faults occur.
●Wait until the blades have stopped
rotating before you remove the jug.
●Never use this liquidizer without a lid.
●Do not put your hands or any utensils such as forks or spoons into
the jug while the blades are rotating.
●Do not immerse in water.
●Children should never be allowed to use this liquidizer.
●Never leave the appliance plugged in when there are young
children around.
●Keep the mains lead away from heat.
●Do not use the liquidizer if the mains lead or the housing are visibly
damaged.
●Repairs must only be carried out by qualified electricians.
●This liquidizer has been designed for domestic quantities only and is
not suitable for commercial use.
●This appliance complies with the appropriate EMC safety directives.
Do not operate the liquidizer with a damaged
cord or plug or if the liquidizer malfunctions or
has been dropped or damaged in any way.
Mains supply: 230V ~ 50Hz
Power consumption: 350W
Because we continually strive to improve our products we may
change specifications and designs without prior notice.
If the power cord becomes damaged, it must be
replaced by your service agent or qualified
person to prevent a hazard. Please contact the
store where you bought your liquidizer.
Always place the liquidizer on a firm and level surface.
plug wiring
Warning. This liquidizer must NOT be earthed.
P
0
l
2
liquidizer
LQ1000
for the sake of the
environment
Do not simply throw the packaging away. Cardboard packaging can be
taken to your local waste paper collection point. Deposit plastic bags
made of polyethylene (PE) at PE collection points. Please ask your local
authority for the address of your nearest recycling depot.
cleaning
Disconnect from the mains before cleaning the liquidizer.
Make sure no water enters the inside of the appliance!
Never immerse the liquidizer or base in water and keep the
electrical contacts dry!
Clean the liquidizer exterior with a soft damp cloth.
Do not use abrasive cleaners or scouring pads which may
damage the finish of the liquidizer.
Rinse the jar under running water.
Should there be a need, the blade assembly can be cleaned
separately. Turn the blade anti-clockwise and the part holding
the blade in place clockwise.
Only use water and dishwashing liquid to clean the liquidizer.
Never put any parts in the dishwasher.
The wires in your liquidizer mains lead are coloured in accordance
with figure 2.
The wire which is coloured blue must be connected to the terminal in
the plug which is marked with the letter Nor coloured black.
The wire which is coloured brown must be connected to the terminal
in the plug which is marked with the letter Lor coloured red.
You must use a 13 amp plug (BS 1363), with a 3 amp fuse (BS
1362). If any other type of plug is used a 3 amp fuse must be
fitted, either in the plug, adaptor or at the distribution board.
Carlton LQ1000.qxd 10/06/2003 10:44 Page 1
using your liquidizer
Assembling the liquidizer
Place the base on a dry, stable surface.
Turn the power dial to 0-position.
Attach the jug to the base (fig. 3) turning the jug anti-clockwise
until it clicks into position.
Operating the liquidizer
Place the liquidizer on stable surface.
Remove the lid (fig. 4) and fill the jug with the ingredients you
want to mix.
Note: The liquidizer can be used for mixing liquids, crushed ice,
grinding and grating of fruits and vegetables, whipping
cream, etc.
Important: Do not exceed the maximum
capacity!
Replace the lid (fig.5) back onto the jug turning it anti-clockwise
until it slides into place.
Connect the plug to the mains socket.
Switch on by turning the power dial (fig. 6) to either of the
positions (I, 2 or P).
Note: You can add extra ingredients during the mixing process
by turning the refill lid anti-clockwise and lifting it out.
Put the new ingredients into the refill lid and pour through the
hole in the jug lid (fig. 7).
Place the refill lid back into the hole in the lid and turn it
clockwise until it clicks into position.
When the blending is finished switch the power dial (fig. 6) back
to the stop-position.
Turn the jug clockwise and lift it off the base.
Important: Do not operate the liquidizer longer than 2
minutes. After each 2 minute session the liquidizer must be
allowed to cool down for at least 10 minutes.
getting to know your liquidizer
Caution.
Never use the liquidizer without a lid.
P
0
l
2
A
D
C
E
B
Description of the Appliance
A Handle
BJug
CPower dial
DBlades
EBase
Fig. 1
P
0
l
l
l
Fig.3
Brown (Live)
Blue (Neutral)
3 amp fuse
Cord grip
N
L
E
Fig.2
Fig.4 Fig.5
P
0
l
2
P = Manual operation
O = Stop
I = Slow
2 = Fast
Fig.6
If the liquidizer doesn’t work please check:
the power is switched on and the liquidizer switch is on either
settings P, I or 2.
the fuse in the plug.
troubleshooting
Fig.7
Carlton LQ1000.qxd 10/06/2003 10:45 Page 2
