USING A MEMORY CARD
107
USING A MEMORY CARD
You can expand the storage
capabilities of your camera by using
a commercially available memory
card (SD memory card or
MultiMedia Card). You can also
copy files from built-in flash
memory to a memory card and from
a memory card to flash memory.
• Normally, files are stored in built-in flash memory. When
you insert a memory card, however, the camera
automatically stores files to the card.
• Note that you cannot save files to built-in memory while a
memory card is installed in the camera.
IMPORTANT!
• Make sure you turn off the camera before inserting or
removing a memory card.
• Be sure to orient the card correctly when inserting it.
Never try to force a memory card into the slot when
you feel resistance.
• See the instructions that come with the memory card
for information about how to use it.
• Certain types of cards can slow down processing
speeds.
• SD memory cards have a write protect switch, which
you can use to protect against accidental deletion of
image data. Note, however, if you write protect an
SD memory card, you must remove write protection
whenever you want to record to it, format it, or delete
any of its files.
USING A MEMORY CARD
108
Using a Memory Card
To insert a memory card into the camera
1.
Making sure that the
contacts of the memory
card are facing towards
the top of the camera,
carefully insert the card
into the slot as far as it
will go.
To remove a memory card from the
camera
1.
Press the memory card
into the camera and then
release it. This will cause
the card to come part way
out of the camera.
2.
Pull the memory card out
of the slot.
IMPORTANT!
• Never insert any other object besides a memory card
into the camera’s card slot. Doing so creates the risk
of damage to the camera and card.
• If you are not using a memory card, be sure to insert
the dummy card into this slot to protect against dust
and damage.
• The dummy card is intended for use with this camera
only. Never insert it into the card slot of any other
type of device.
• Should water or any foreign object ever get into the
card slot, immediately turn off the camera, remove
the battery, and contact your dealer or nearest
CASIO authorized service center.
• Never remove a card from the camera while the
operation/flash charge lamp is flashing. Doing so can
cause the file save operation to fail, and even
damage the memory card.
Contacts
USING A MEMORY CARD
109
Formatting a Memory Card
Formatting a memory card deletes any data already stored
on it.
IMPORTANT!
• Be sure to use the camera to format a memory card.
Formatting a memory card on a computer and then
using it in the camera can slow down data
processing by the camera. In the case of an SD card,
formatting on a computer can result in non-
conformity with the SD format, causing problems with
compatibility, operation, etc.
• Note that data deleted by a memory card format
operation cannot be recovered. Check to make sure
you do not need any of the data on the memory card
before you format it.
• Formatting a memory card that contains files deletes
all the files, even those that are protected (page 86).
1.
Load the memory card into the camera.
2.
Turn on the camera. Next, enter the REC
mode or PLAY mode and press [MENU].
3.
Select the “Set Up” tab, select “Format”, and
then press [왘].
4.
Use [왖] and [왔] to select “Format”, and then
press [SET].
• To exit the format operation without formatting,
select “Cancel”.
USING A MEMORY CARD
110
Memory Card Precautions
• Use only an SD memory card or a MultiMediaCard with
this camera. Proper operation is not guaranteed when
any other type of card is used.
• Electrostatic charge, electrical noise, and other
phenomena can cause data to become corrupted or even
lost. Always make sure that you always back up important
data on other media (MO disc, computer hard disk, etc.)
• If a memory card starts to behave abnormally, you can
restore normal operation by reformatting it. However, we
recommend that you always take along more than one
memory card whenever using the camera far away from
the home or office.
• We recommend that you format a memory card before
using it for the first time after purchasing it, or whenever
the card you are using seems to be the cause of
abnormal images.
• Before starting a format operation, check to make sure
that the battery is fully charged. Power interruption during
the format operation can result in improper formatting,
and even damage the memory card and make it
unusable.
Copying Files
Use the procedures below to copy files between built-in
memory and a memory card.
IMPORTANT!
• Only snapshot and movie files recorded with this
camera can be copied. Other files cannot be copied.
To copy all the files in built-in memory to
a memory card
1.
Load the memory card into the camera.
2.
Turn on the camera. Next, enter the PLAY
mode and press [MENU].
3.
Select the “PLAY” tab,
select “Copy”, and
then press [왘].
USING A MEMORY CARD
111
To copy a file from a memory card to
built-in memory
With this procedure you can copy one file at a time.
1.
Perform steps 1 through 3 of the procedure
under “To copy all the files in built-in memory
to a memory card”.
2.
Use [왖] and [왔] to select “Card Built-in”,
and then press [SET].
3.
Use [왗] and [왘] to select the file you want to
copy.
4.
Use [왖] and [왔] to select “Built-in Card”,
and then press [SET].
• This starts the copy operation and displays the
message “Busy... Please wait..”.
• After the copy operation is complete, the monitor
screen shows the last file in the folder.
4.
Use [왖] and [왔] to select “Copy”, and then
press [SET].
• This starts the copy operation and displays the
message “Busy... Please wait..”.
• The file reappears on the monitor screen after the
copy operation is complete.
• Repeat steps 3 through 4 to copy other images, if
you want.
5.
Press [MENU] to exit the copy operation.
NOTE
• Files are copied to the folder in built-in memory
whose name has the largest number.
VIEWING IMAGES ON A COMPUTER
112
VIEWING IMAGES ON A COMPUTER
After using the USB cradle to establish a USB connection
between the camera and your computer, you can use your
computer to view images in file memory and copy images
to your computer’s hard disk or other storage media. In
order to do this, you first need to install the USB driver
located on the CD-ROM that comes bundled with the
camera onto your computer.
Note that the procedure you need to perform depends on
whether you are using computer running under Windows
(see below) or a Macintosh (see page 117).
Using the Camera with a Windows
Computer
The following are the general steps for viewing and copying
files from a computer running under Windows. You can find
details about each operation in the procedures that follow
below. Note that you should also refer to the
documentation that comes with your computer for other
information about USB connections, etc.
1. If you are running Windows 98, Me, or 2000, install
the USB driver onto your computer.
•You need to perform this step only once, the first
time you connect to your computer.
•If you are running Windows XP, you do not need to
install the USB driver.
2. Use the USB cradle to establish a connection between
the camera and computer.
3. View and copy the images you want.
VIEWING IMAGES ON A COMPUTER
113
1.
What you should do first depends on whether
your computer is running under Windows 98/
Me/2000 or Windows XP.
■Windows 98/Me/2000 Users
•Start from step 2 to install the USB driver.
•Note that the example installation presented here
uses Windows 98.
■Windows XP Users
•Installation of the USB driver is not required, so jump
directly to step 6.
2.
Set the bundled CD-ROM into the CD-ROM
drive of your computer.
3.
On the menu screen
that appears, click the
language button in the
upper left corner of the
display, and then
select a language from
the list that appears.
4.
Click [USB driver] and then [Install].
•This starts installation.
•The following steps show installation under the
English version of Windows.
5.
On the screen that appears after installation
is complete, select the “Yes, I want to restart
my computer now.”check box and then click
[Finish] to restart your computer.
IMPORTANT!
•Do not try to establish a connection between the
camera and computer before installing the USB
driver onto the computer.
•If you want to transfer files from the camera’s built-in
memory to a computer, make sure there is no
memory card loaded in the camera before you place
it onto the USB cradle.
VIEWING IMAGES ON A COMPUTER
114
6.
Connect the bundled AC adaptor to the [DC IN
5.3V] connector of the USB cradle, and then
plug it in to a household power outlet.
•Note that the shape of the AC adaptor depends on
the area where you purchased the camera.
7.
Connect the USB cable that comes bundled
with the camera to the USB cradle and your
computer’s USB port.
•Take care when connecting the USB cable to the
USB cradle or your computer. USB ports and cable
plugs are shaped for proper positioning.
•Plug the USB cable plugs into the ports securely, as
far as they will go. Proper operation is not possible if
connections are not correct.
○○○○○○○○○○○○○○○○○○○○○○○○○○○
USB port
Connector A
USB cable
(bundled)
[USB]
Connector B
VIEWING IMAGES ON A COMPUTER
115
PHOTOCHARGEUSB
REC
PLAY
MENU
SET
DISP
8.
After making sure the camera is turned off,
place the camera onto the USB cradle.
•Do not place the camera onto the USB cradle while it
is turned on.
9.
Press the USB cradle’s [USB] button.
•This will cause the “Add New Hardware...”dialog box
to appear on the computer screen as the computer
automatically detects the camera’s file memory. After
you install the USB driver, “Add New Hardware...”
dialog box will no longer appear when you perform
the above steps to establish a USB connection.
•Pressing the [USB] button enters the USB mode,
which causes the USB cradle’s [USB] lamp to light
green (page 146).
•At this point, some operating systems will display a
“Removable Disk”dialog box. If your operating
system does, close the dialog box.
PHOTOCHARGEUSB
RECPLAY
MENU
SET
DISP
[USB] button
[USB] lamp
VIEWING IMAGES ON A COMPUTER
116
10.
On your computer, double-click “My
Computer”.
11.
Double-click “Removable Disk”.
•Your computer sees the camera’s file memory as a
removable disk.
12.
Double-click the “Dcim”folder.
13.
Double-click the folder that contains the
image you want.
14.
Double-click the file that contains the image
you want to view.
•For information about file names, see “Memory
Directory Structure”on page 124.
15.
To copy all the files in file memory to your
computer’s hard disk, drag the “Dcim”folder
from “Removable Disk”to the “My
Documents”folder on your computer.
16.
Depending on the version of Windows you are
running, use one of the following procedures
to terminate the USB connection.
■WindowsMe/98 Users
•After pressing the USB cradle [USB] button and
making sure that the [USB] lamp is not lit, remove
the camera from the USB cradle.
■Windows2000/XP Users
•Click card services in the task tray on your computer
screen, and disable the drive number assigned to the
camera. After pressing the USB cradle [USB] button
and making sure that the [USB] lamp is not lit,
remove the camera from the USB cradle.
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali Casio Macchina fotografica digitale
Casio
Casio Exilim EX-S770 Manuale utente
Casio
Casio EX-S2 - Exilim 2MP Digital Camera Manuale utente
Casio
Casio Exilim EX-ZR3500 Manuale utente
Casio
Casio Exilim EX-FR100 Manuale utente
Casio
Casio EX-Z100BE - EXILIM ZOOM Digital Camera Manuale utente
Casio
Casio EX-S2 - Exilim 2MP Digital Camera Manuale utente
Casio
Casio Exilim EX-Z750 Manuale utente
Casio
Casio Exilim EX-ZS160 Manuale utente
Casio
Casio Exilim EX-Z57 Guida alla risoluzione dei problemi
Casio
Casio EX-FC150 - EXILIM Digital Camera Manuale utente
Casio
Casio EXILIM EX-Z19 Manuale utente
Casio
Casio EXILIM EX-Z690 Manuale utente
Casio
Casio Exilim EX-Z100 Manuale utente
Casio
Casio EXILIM EX-Z33 Manuale utente
Casio
Casio D'Z IMAGE DERMOCAMERA DZ-D100 Manuale utente
Casio
Casio QV-4000 Manuale utente
Casio
Casio QV-3500EX Manuale utente
Casio
Casio QV-5500SX Manuale utente
Casio
Casio EX-G1 - Exilim 12.1 MP Endurance Digital... Manuale utente
Casio
Casio Exilim EX-ZR1200 Manuale utente
