Casio IT-800 Series Manuale utente

CASIO

IT-800 Series

Quick Start Guide

(US Version 1.03)

CASIO Computer Co., Ltd.

May 2010

Table of the Contents

Editorial Record 4

Preface 5

Chapter 1. Product Overview 6

1.1 Features at a Glance 6

1.2 Library 8

1.3 Development Manuals 9

Chapter 2. Prerequisites 10

2.1 Skills Required 10

2.2 Hardware Required 11

2.3 Software Required 13

Chapter 3. Installing BDK to PC 14

3.1 Application Development 14

3.2 Installing CASIO BDK Files 15

3.3 Installing Library 17

3.4 Installing Online Help 18

Chapter 4. Connecting Power Supply to Cradle 19

4.1 HA-H60IO 19

4.2 HA-H62IO 21

Chapter 5. Connecting the IT-800 to PC 23

5.1 Connection via USB Cradle 24

5.1.1 ActiveSync via USB 25

5.1.2 Windows Mobile Device Center via USB 25

5.2 Connection via IrDA 26

5.3 Connection via WLAN 27

5.4 Connection via Ethernet Cradle 32

5.5 Accessing Shared Network Drive on Your LAN 33

5.6 Direct TCP/IP Connection from Visual Studio 34

Chapter 6. Setting Up the Development Environment 36

6.1 Installing CAB Files 36

6.2 Visual Studio 2005 37

Chapter 7. Device Emulator 38

7.1 Software Required 38

7.2 Starting Up the Device Emulator 40

7.3 Using the Device Emulator 41

7.3.1 IT-800WM Device Emulator 41

7.3.2 I/O Simulator 42

7.3.3 Connecting via ActiveSync 47

7.4 Debugging Applications 49

Chapter 8. Visual Studio 51

8.1 Developing in C++ 52

8.2 Developing in VB 56

8.3 Developing in C# 58

Chapter 9. Resources 61

No part of this document may be produced or transmitted in any form or by any means, electronic

or mechanical, for any purpose, without the express written permission of CASIO Computer Co.,

Ltd. in Tokyo Japan. Information in this document is subject to change without advance notice.

CASIO Computer Co., Ltd. makes no representations or warranties with respect to the contents or

use of this manual and specifically disclaims any express or implied warranties of merchantability

or fitness for any particular purpose.

Editorial Record

Manual

Version

no.

Date edited Page Content

1.00 August 2009 all Original version

7 Chinese Sensible Code (HanXin Code) is added.1.01 October 2009

8, 9, 36 Bluetooth library is deleted.

1.02 December 2009 36 CAB File Name is modified.

Note is added at case of using Device Emulator after Windows

Vista OS

1.03 May 2010

13, 23 Supported OS is added. ( Windows 7 / Windows 2008 Server )

Preface

This guide clearly and concisely sets out the information developers need to know to get started with

the CASIO IT-800 series handheld terminals with the integrated Windows Mobile®Version 6.5 OS.

The best methods of connecting to your development system are covered and step by step

instructions for installing and testing the CASIO Basic Development Kit (BDK) are included.

The purpose of this guide is to get you to the point where you can start development; you should

refer to the library manuals for detailed information on the specific APIs.

The words, "the terminal", "the IT-800", "the IT-800 series", and "IT-800 device", used in this

reference manual mean IT-800 series handheld terminal with the integrated Windows Mobile®as its

OS unless otherwise noted.

1. Product Overview

1.1 Features at a Glance

The IT-800 has been designed using the new concept of the Human-centered Design Processes and

is capable of performing a wide variety of powerful functions.

The following is a brief overview of the features available on the IT-800 series handheld terminals.

For further detail on the hardware specifications, refer to IT-800 Series Hardware Manual.

Outstanding development environment

• Microsoft®Windows Mobile®6.5 English Version as the built-in OS

• Visual Studio 2008

• Visual Studio 2005

Various communication systems

• Built-in WWAN module combines GSM, GPRS and EDGE modules with GPS receiver

designed for use in transportation and logistics.

• High speed infrared communication with IrDA Version. 1.3

• Bluetooth® Version 2.0

• Serial interface with USB version 1.1 (Host/Client)

Small size, light weight

• Dimensions : Approx. 78 (W) x 159.5 (D) x 25 (H) mm

• Weight : Approx. 267g (model dependant)

Improved durability

• Impact resistance : 1.5 m in height *

• Dust/Water-splash proof : IP54 level (compliant with IEC60529 International Standard)

* The drop durability height is a measured value resulting from actual testing. It does not necessarily guarantee the

product from damage.

Scanning industrial standard bar code symbologies

• Readable bar code symbologies with laser scanner:

EAN8, EAN13, UPC-A/E, Codabar (NW-7), CODE39, CODE93, CODE128/EAN128, ITF,

MSI, IATA, Industrial 2of5, GS1 DataBar Omnidirectional (RSS-14), GS1 DataBar Limited

(RSS Limited), GS1 DataBar Expanded (RSS Expanded), GS1 DatBar Stacked (RSS-14

Stacked), GS1 DataBar Expanded Stacked(RSS Expanded Stacked)

• Readable bar code symbologies with C-MOS imager:

1D:

EAN8, EAN13, UPC-A/E, Codabar (NW-7), CODE11, CODE32, CODE39, CODE93,

CODE128/EAN128, ITF, MSI, IATA, Industrial 2of5, GS1 DataBar Omnidirectional (RSS-14),

GS1 DataBar Limited (RSS Limited), GS1 DataBar Expanded (RSS Expanded)

2D Stacked:

PDF417, Micro PDF, CODE49, Composite, Codablock F, TLC39, GS1 DataBar Stacked

Omnidirectional (RSS-14 Stacked), GS1 DataBar Expanded Stacked (RSS Expanded Stacked),

GS1 DatBar Stacked (RSS-14 Stacked)

2D Matrix:

Aztec, DataMatrix, Maxicode, QR Code, Micro QR, Chinese Sensible Code (HanXin Code)

CPU, Memory

• High-performance CPU

Marvell®PXA320 Application Processor (runs at maximum 624 MHz)

• Large-capacity memory

RAM : 128 MB

F-ROM : 256 MB

1.2 Library

The IT-800WM Basic Development Kit ("BDK") provides various libraries including those listed in

the table.

Table 1.1

Library Description C++ VB

System Library Library that is used to control the system. Yes Yes

Laser Scanner Library Library that is used to control the built-in laser scan engine. Yes Yes

Imager Library Library that is used to control the built-in CMOS Imager. Yes Yes

Camera Library Library that is used to control the built-in CAMERA module. Yes Yes

NFC Library Library that is used to control to communicate with IC card. Yes Yes

WANGPRS Library Library that is used to control the built-in WANGPRS

module.

Yes Yes

JPEG Library Library that is used to handle and manipulate JPEG image

functions.

Yes -

FLINK Library Library that is used to control and carry out

transmission/reception of files between PC and other device.

Yes Yes

Note:

The abbreviations used in the table are;

C++ : Visual C++

VB : Visual Basic .NET

C# : Visual C# .NET

Table 1.2 shows each file name of the Dynamic Link Library and Dynamic Link Class Library.

Table 1.2

Library Dynamic Link Library Dynamic Link Library

(Class Library)

System Library SystemLib.dll SystemLibNet.dll

Laser Scanner Library OBReadLib.dll OBReadLibNet.dll

Imager Library ImagerLib.dll ImagerLibNet.dll

Camera Library CameraLib.dll CameraLibNet.dll

NFC Library NFCLib.dll NFCLibNet.dll

WANGPRS Library WangprsLib.dll WangprsLibNet.dll

JPEG Library JpegCe.dll None

FLINK Library FlinkLib.dll MoFlinkLib.dll

1.3 Development Manuals

The IT-800WM Basic Development Kit ("BDK") provides various development reference manuals

as described in the table below.

Table 1.3

Development Manual Description

Quick Start Guide This reference manual.

Software Manual Reference manual that describes software specifications in detail for all

the software integrated in IT-800 handheld terminal.

Hardware Manual Reference manual that describes hardware specifications in detail on

each dedicated option and IT-800 handheld terminal

System Library Manual Reference manual that describes individual functions in detail for System

Library.

Laser Scanner Library Manual Reference manual that describes individual functions in detail for Laser

Scanner Library.

Imager Library Manual Reference manual that describes individual functions in detail for Imager

Library.

Camera Library Manual Reference manual that describes individual functions in detail for

Camera Library.

NFC Library Manual Reference manual that describes individual functions in detail for NFC

Library.

WANGPRS Library Manual Reference manual that describes individual functions in detail for

WANGPRS Library.

JPEG Library Manual Reference manual that describes individual functions in detail for JPEG

Library.

FLINK Library Manual Reference manual that describes individual functions in detail for FLINK

Library.

2. Prerequisites

2.1 Skills Required

The following skills are required by developers aiming to develop application software for the

IT-800 terminal.

• Windows programming

• A good knowledge of one or more of the following.

- Visual C++

- Visual Basic .NET

- Visual C#

- Browser based applications (not covered in this guide)

The following skills or experience are also desirable.

• Windows CE devices

• ActiveSync

• Some networking experience
