Casio PV-250X Manuale utente

121

Data communications capabilities let you transfer data between two CASIO

PV Units, between a PV Unit and a BN-10/BN-20 Unit, or between a PV

Unit and a BN-10A/BN-20A/BN-40AUnit. You can also receive data from a

CASIO SF, CSF, or NX Series Unit, and communicate with a personal

computer using PC sync for Windows.

• See the manual that comes with PC sync for Windows for details on

connecting to a computer and setting up for communication.

Chapter

10 Data Communication

Using the Cradle............................................................................ 122

To connect the PV Unit to the cradle........................................................ 122

To detach the PV Unit from the cradle ..................................................... 123

Data Communications Between Two PV Units .......................... 123

To connect two PV Units .......................................................................... 123

To send data from the host unit to the terminal unit ................................. 124

To receive data from the terminal unit on the host unit ............................ 126

Data Communications Between a PV Unit and a BN Unit ....... 129

To connect a PV Unit to a BN Unit .......................................................... 129

To send data from the PV Unit to the BN Unit ........................................ 130

To receive data from the BN Unit on the PV Unit.................................... 132

Receiving Data From an SF/CSF/NX Series Unit...................... 134

To connect a PV Unit and an SF/CSF/NX Series Unit............................. 134

To make communication parameter settings ............................................ 135

To receive data from an SF/CSF/NX Series Unit ..................................... 137

122

Using the Cradle

The PV Unit comes with a cradle that helps to make data communications quicker

and easier. The following procedures describe how to attach the PV Unit to and

detach it from the cradle.

To connect the PV Unit to the cradle

1. Turn off PV Unit power.

2. Place the PV Unit onto the cradle.

• Gently but firmly press down on the PV Unit to ensure that it is inserted

into the cradle as far as it will go.

123

Chapter 10 Data Communication

To detach the PV Unit from the cradle

1. Turn off PV Unit power.

2. Lift up on the PV Unit while holding down the cradle’s Release button.

Data Communications Between Two PV Units

This section describes how to set up and communicate between two PV Units.

To connect two PV Units

1. Make sure that the power of both units is turned off.

2. Place the PV Units onto their cradles.

• Gently but firmly press down on the PV Units to ensure that they are

inserted into the cradles as far as they will go.

Release button

124

3. Use an optional SB-90 9-9 pin connector to connect the two cradles to

each other.

• All data communication settings must be made on only one of the PV

Units only. This unit is called the host unit, while the other unit is called

the terminal unit.

To send data from the host unit to the terminal unit

1. After connecting the two PV Units, turn on the host unit.

• Terminal unit power should still be off at this time.

2. Display the list view in a mode whose data can be sent with this setup.

• This configuration supports transfer of Contacts (Business, Personal,

Untitled 1-5), Memo (Untitled 1-5), Schedule, To Do, Reminder, Expense

Manager, and Quick-Memo data.

Start button

Cradles

SB-90 9-9 pin connector

Host unit Terminal unit

125

Chapter 10 Data Communication

3. Tap the Menu Bar icon to display the menu bar, and then tapSystem –

Data communication.

4. Tap the button next to Pocket Viewer to specify the data communication

configuration.

5. Tap the button next to Send.

6. Tap Set.

7. Tap the check boxes to specify the data you want to send (checked) and

the data you do not want to send (unchecked).

126

8. After everything is the way you want it, tap Set.

9. Turn on the power of the terminal unit and then press the Start button

on its cradle to start the data transfer operation.

To receive data from the terminal unit on the host unit

1. Perform steps 1 through 4 under “To send data from the host unit to the

terminal unit”.

2. Tap the button next to Receive.

127

Chapter 10 Data Communication

3. Tap Set.

4. Tap the check boxes to specify the data you want to receive (checked)

and the data you do not want to receive (unchecked).

5. After everything is the way you want it, tap Set.

6. Turn on the power of the terminal unit and then press the Start button

on its cradle to start the data transfer operation.

128

Notes

• The above procedures can be used to send or receive all data in specific

modes only. You cannot send or receive individual data items.

• Data communication can be interrupted at any time by pressing Esc.

This causes the message Stopped! to appear on the displays of both

units.

• The message Communication error! appears on the displays of both

units whenever data communication is interrupted due to cable

disconnection, line noise, or other abnormal condition.

• If the secret memory area is accessed on a unit receiving data, the received

data is stored in the secret memory area, regardless of the memory area

the data is in on the sending unit.

• Transferring data from the PV-200A/PV-250X/PV-400A/PV-450X to a

PV-100 or PV-200 causes all euro symbols to be replaced by spaces.

• The size of the PV-200A/PV-250X/PV-400A/PV-450X screen is 160 ·

160 dots. Transferring PV-200A/PV-250X/PV-400A/PV-450X Quick-

Memo data to a PV-100 or PV-200, which both have 98(V) ·124(H)-

dot screens, causes the right side and bottom part of the Quick-Memo

image to be cut off in order to fit the PV-100/PV-200 screen.

129

Chapter 10 Data Communication

Data Communications Between a PV Unit and

a BN Unit

This section describes how to set up and communicate between a PV Unit and a

BN Unit (BN-10/BN-20 or BN-10A/BN-20A/BN-40A).

To connect a PV Unit to a BN Unit

1. Make sure that the power of both units is turned off.

2. Open the cover of the Mini Cradle port of the BN Unit, and connect its

Mini Cradle to the port.

3. Place the PV Unit onto its cradle.

• Gently but firmly press down on the PV Unit to ensure that it is inserted

into the cradle as far as it will go.

4. Use an optional SB-90 9-9 pin connector to connect the PV Unit cradle

to the BN Unit Mini Cradle.

• All data communication settings must be made on the PV Unit, which is

the host unit. The BN Unit is the terminal unit.

START button

Mini Cradle

Cradle

SB-90 9-9 pin connector

Host unit (PV Unit) Terminal unit (BN Unit)

130

To send data from the PV Unit to the BN Unit

1. After connecting the two units, turn on the PV Unit.

• BN Unit power should still be off at this time.

2. Display the list view in a mode whose data can be sent with this setup.

• This configuration supports transfer of Contacts (Business, Personal),

Memo, Schedule, To Do, and Reminder data.

• Calendar and Expense Manager data cannot be transferred.

• Contacts Untitled 1-5 data is transferred as Personal data.

• Memo Untitled 1-5 data is transferred as Memo data (no category).

3. Tap the Menu Bar icon to display the menu bar, and then tap System –

Data communication.

4. Tap the button next to BUSINESS NAVIGATOR to specify the data

communication configuration.

5. Tap the button next to Send.
