CATEYE PADRONE+
CC-PA110W
Quick Start
START
Thank you for purchasing our cyclocomputer CATEYE PADRONE+.
This Quick Start Manual explains how to set up the computer and how to install the unit on
your bicycle.
Please set up the unit according to the specified procedure, then it will be ready for use as a
cyclocomputer.
Before use, read the instruction manual that comes with the product thoroughly to the
end to understand the functions of this unit, and to use it safely in a correct manner.
Next
This PDF contains a movie file.
When you click on the movie screen, a message regarding security appears. Click the
“Trust in the text” or “Play” button to close the message.
Click the screen again to play the movie.
Next
CATEYE PADRONE +
Quick Start Manual Contents
Click the item you wish to view.
Setting up the computer
How to install the speed sensor (movie)
How to install the bracket (movie)
Backlight (Night Mode)
Return to a Cover
MENU
MODE
Operation of buttons
Set up the computer by operating the buttons as follows.
Check the button position before you start setting up.
Back
Press the MENU button and the MODE
button on the back of the computer.
Next
CATEYE PADRONE +
Quick Start Manual Setting up the computer
Setting the speed unit
Entering the tire circumference
Setting the clock display
Clear all data (initialization)
Measuring screen
(Setup completed)
Setting the hour
Setting the minute
Clear all data (initialization)
AC
Clear all data (initialization)
Press the AC button on the back of the computer.
After full lighting of the screen, the computer switch-
es to the speed unit setting screen to start setup.
Full lighting Setting the speed unit
Return to Contents
Next
Return
CATEYE PADRONE +
Quick Start Manual Setting up the computer
Setting the speed unit
Entering the tire circumference
Setting the clock display
Clear all data (initialization)
Measuring screen
(Setup completed)
Setting the hour
Setting the minute
Setting the speed unit
Clear all data (initialization)
MENU
MODE
km/h ↔mph
Setting the speed unit
Setting the speed unit
When the MODE button is pressed, either “km/h” or
“mph” is selected for the speed unit display. Select the
unit of your choice.
After selecting, press the MENU button to proceed to the
next step “Entering the tire circumference”.
To the next step
Return
Return to Contents
Next
CATEYE PADRONE +
Quick Start Manual Setting up the computer
Setting the speed unit
Entering the tire circumference
Setting the clock display
Clear all data (initialization)
Measuring screen
(Setup completed)
Setting the hour
Setting the minute
Entering the tire circumference
Setting the speed unit
Clear all data (initialization)
MODE
MENU
MODE
Entering the tire circumference
Enter the tire circumference (mm) of your bicycle with 4
digits using the tire circumference reference table.
(0100-3999 mm)
Pressing the MODE button increases the value flashing,
and pressing and holding the MODE button moves to the
next digit.
After entering, press the MENU button to proceed to the
next step “Setting the clock display”.
Entering the tire
circumference
Move digit
Increase
the value To the next step
(Press
and hold)
Tire circum-
ference refer-
ence table
Return
Return to Contents
Next
CATEYE PADRONE +
Quick Start Manual Setting up the computer
Setting the speed unit
Entering the tire circumference
Setting the clock display
Clear all data (initialization)
Measuring screen
(Setup completed)
Setting the hour
Setting the minute
Setting the clock display
Entering the tire circumference
Setting the speed unit
Clear all data (initialization)
24h ↔12h
MODE
MODE
Setting the clock display
When the MODE button is pressed, either “12h” or “24h”
is selected for the clock display. Select the display of
your choice.
After selecting, press and hold the MODE button to pro-
ceed to the next step “Setting the hour”.
Clock display
To the next step
(Press
and hold)
Return
Return to Contents
Next
CATEYE PADRONE +
Quick Start Manual Setting up the computer
Setting the speed unit
Entering the tire circumference
Setting the clock display
Clear all data (initialization)
Measuring screen
(Setup completed)
Setting the hour
Setting the minute
Setting the clock display
Entering the tire circumference
Setting the speed unit
Clear all data (initialization)
12h format
MODE
MODE
Setting the hour
A: a.m.
P: p.m.
Setting the hour
Pressing the MODE button increases the value flashing
(“Hour” of the clock). Enter any value.
*When 12h mode is selected, check whether A(a.m.) or
P(p.m.) is displayed before entering the value.
After entering, press and hold the MODE button to pro-
ceed to the next step “Setting the minute”.
Hour
To the next stepIncrease the value
(Press
and hold)
Return
Return to Contents
Next
