Installation Ceiling Installation/Wall
mounting/In-Ceiling Installation
Relative Temperature 10-75%（in case no condensation）
Operation Temperature 0℃~40℃
Waterproof grade
（metal）IP66
Function
Size 4.5″
CCD 1/3″Color Sony CCD
Horizontal Scanning
Range: 360°
Horizontal Scanning
Speed: 0-12°/s
Vertical Scanning Range: 0°～90°
Vertical Scanning Speed: 0-12°/s
Scanning Limitation: Horizontal adjustable
TV format: PAL format,1/4″color CCD
Resolution: 480TVL
Lowest Luminous: 0.1LUX
Built-In Lens: Fix lens 2.8-16mm
Presetting Position: 32
Decoder: Have
Cover Material: Aluminum alloy,Vandal proof and
whether proof
Input voltage 12V DC
Wattage: 12VA
ⅡDescription of Functions
The intelligent dome camera is a hi-tech CCTV product, which
incorporates the high-clarity color camera, panoramic speed-variable
PAN/TILT, multifunctional decoder into a whole. It can largely reduce
connection and installation processes of components in the system, rise
up reliability of the system and facilitate installation and maintenance.
Therefore it has advantages of beautiful appearance, compact structure
and easy operation.
1. Built-in color video camera with vari focus lens
a. 4mm、6mm、8mm、12mm lens are available;
b. Automatic iris and shutter;
2. Integrated Multi-Protocol Decoder.
a. With built-in Decoder and integrated multi-protocol, the
customer can set up communication protocol and baud rates at
his discretion directly according to the need of the system. It is
completely compatible with over ten kinds of control system
form main manufacturers;
b. RS485 serial control and addresses of the dome 1-1023.
3. Integrated Speed-Variable PAN/TILT
a. Turning 0--360° horizontally and continuously with unlimited
positions and turning 90ºvertically;
b. With 32 prepositions and data power off memory.
c. The dome camera can scan cubically between two positions
with dwelling time of 4s at each position and the scan speed of
7.5°/s;
d. With the tour locus setup function with data power-failure
memory which can be called;
e. The range of both horizontal and vertical speed is 0 - 12°/S;
Six patrol can be set up in maximum and each patrol can set up
sixteen preset positions with dwelling time fixed at 4s and the
tour speed is 7.5°/s;
