CEECO SSW-321-X Manuale utente

SSW-321-X-ISSUE 4.0

SERVICE MANUAL

FOR

MODEL SSW-321-X

STAINLESS STEEL WALL TELEPHONE

Serving the Telephone Industry Since 1930

Communication Equipment 519 W South Park Street

& Engineering Company Okeechobee, FL 34972

Voice: 863-357-0798

Fax: 863-357-0006

ISSUE 4.0

CEECO

Communication Equipment & Engineering Company

PROPRIETARY

IMPORTANT INFORMATION

FOR

CUSTOMER

Please fill in before you continue.

The following information is necessary when calling CEECO for assistance.

MODEL NUMBER

MODEL SSW-321-X STAINLESS STEEL

WALL TELEPHONE.

SERIAL NUMBER

DATE MANUFACTURED

LOCATION INSTALLED

For us to better serve you, please have this information available when calling for

technical support.

CEECO

Communication Equipment and Engineering Company

519 W South Park Street

Okeechobee, FL 34972

863-357-0798- telephone

863-357-0006- facsimile

[email protected]

www.ceeco.net

ISSUE 4.0

CEECO

Communication Equipment & Engineering Company

PROPRIETARY

TABLE OF CONTENTS

SECTION PAGE

1.0 INTRODUCTION................................................................................................... 4

2.0 GENERAL DESCRIPTION.................................................................................. 4

3.0 OPERATION .......................................................................................................... 4

4.0 RECOMMENDED TOOLS AND TEST EQUIPMENT.................................... 4

5.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS..................... 5

6.0 TESTING................................................................................................................. 6

7.0 TROUBLESHOOTING GUIDE........................................................................... 6

8.0 SPECIFICATIONS................................................................................................. 7

10.0 FCC NOTICE......................................................................................................... 9

11.0 REPAIR AND RETURN INFORMATION...................................................... 10

12.0 WARRANTY POLICY....................................................................................... 11

ISSUE 4.0

CEECO

Communication Equipment & Engineering Company

PROPRIETARY

1.0 INTRODUCTION

The practices in this manual provide installation and maintenance information for

the Model SSW-321-X Stainless Steel Wall Telephone.

The information in this manual is subject to change without notification.

For information not included in this manual, please call or write:

CEECO

Customer Service

519 W South Park Street

Okeechobee, FL 34972

863-357-0798- telephone

863-357-0006- facsimile

[email protected]

www.ceeco.net

2.0 GENERAL DESCRIPTION

The CEECO Model SSW 321-X is a Stainless Steel Telephone designed for

special applications where a durable telephone instrument must be sturdy and

attractive. The SSW 321-X will accept incoming calls only. The user cannot

initiate a call. Please note, however, that external automatic dialing equipment

could be used in conjunction with this phone, which would allow it to

automatically dial a number when the handset is lifted.

3.0 OPERATION

An incoming call is indicated by an audible ringer. When the phone rings, lift the

handset. Normal operation will follow.

4.0 RECOMMENDED TOOLS AND TEST EQUIPMENT

Volt/Ohm Meter

1/4" Nut Driver

Flat Blade Screw Driver

Security Tool, CEECO Part Number 301-037

ISSUE 4.0

CEECO

Communication Equipment & Engineering Company

PROPRIETARY

5.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS

5.1 Using a 301-037 security tool (sold separately), loosen and remove the

security screw located in the bottom of the phone case.

5.2 The security tool is for a standard 5/32" button head screw generally used

on the framework of the phone booths.

5.3 Separate the telephone housing from the backplate by pulling the bottom

of the housing forward and lifting up on the housing.

5.4 The backplate is designed to be mounted on a flat vertical surface. Four

mounting holes are provided.

5.5 Run the inside station wire through the backplate and terminate on the

RJ11C terminal block inside.

5.6 The use of a gas tube station protector is recommended. The station

ground should not exceed 50 ohms.

5.7 Plug the modular line cord from the telephone into the RJ11C terminal

block.

5.8 Dress the line cable away from the locking screw and seat the case onto

the backplate. Secure the case by tightening the security screw.

*****WARNING*****

A. Never install telephone wiring during a lightning storm.

B. Never install telephone jacks in wet locations

unless the jack is specifically designed for wet

locations.

C. Never touch uninsulated telephone wires or

terminals unless the telephone line has been

disconnected at the network interface.

D. Use caution when installing or modifying telephone lines.

ISSUE 4.0

CEECO

Communication Equipment & Engineering Company

PROPRIETARY

6.0 TESTING

6.1 Connect the phone to a phone line or a DTMF phone test set.

6.2 From the test set or another phone place a call into the 321-X.

6.3 Verify that the ringer is working.

6.4 Lift the handset and check that a normal conversation is allowed.

7.0 TROUBLESHOOTING GUIDE

Always visually check the phone for loose or shorted wires, damaged terminals or

damaged parts.

PROBLEM: NO DIAL TONE

POSSIBLE CAUSE:

LINE CORD

RJ11C CONNECTOR

NETWORK

HANDSET

HOOKSWITCH ASSEMBLY

PROBLEM: DIAL TONE IS DISTORTED

POSSIBLE CAUSE:

NETWORK

HANDSET

PROBLEM: TRANSMITTER DOES NOT TURN ON

POSSIBLE CAUSE:

HANDSET

NETWORK

PROBLEM: RINGER DOES NOT OPERATE

POSSIBLE CAUSE:

RINGER

NETWORK

ISSUE 4.0

CEECO

Communication Equipment & Engineering Company

PROPRIETARY

8.0 SPECIFICATIONS

INPUT POWER: C.O. Line Powered

LOOP CURRENT: 23mA min to 80mA max

IMPEDANCE: 600 ohms

HEARING AID

COMPATIBLE: Meets EIA standards

ENVIRONMENTAL: Temperature 0C to 50C

Humidity 20%-90% non-condensating

TELEPHONE COVER: Brushed 16 ga. Stainless Steel

DIMENSIONS: 5" Wide x 10 3/4" High x 5 1/2" Deep

(Handset On Hook)

MOUNTING: Vertical Surface Mount

WEIGHT: 6 lbs.

FCC REGISTRATION: BW88T7-68413-TE-T

UL LISTED NO.: 6OF5

RINGER EQUIVALENCY: 0.4A

TYPE JACK: RJ11C

ISSUE 4.0

CEECO

Communication Equipment & Engineering Company

PROPRIETARY

9.0 PARTS LIST

QUANTITY PART NUMBER DESCRIPTION

1 301-004 Handset with armored cord

1 401-009 Ringer

1 301-009 Network

1 301-581 Tongue & Bracket

1 301-528 Hookswitch & Cradle assembly

1 321-012 Stainless Steel Housing

1 321-017 Stainless Steel Backplate

2 301-570 Microswitch

1 321-016 1/4"x 20"x 3/4" Security Screw

1 301-018 Modular cord

1 301-054 Modular jack

ACCESSORIES:

1 301-037 Security tool, 1/8" button head

ISSUE 4.0

CEECO

Communication Equipment & Engineering Company

PROPRIETARY

10.0 FCC NOTICE

10.1 FCC REGISTRATION AND REPAIR INFORMATION

Your new telephone has been registered with the Federal Communication

Commission (FCC) in accordance with Part 68 of its rules. The FCC

requires that you be advised of certain requirements involving the use of

this telephone.

10.2 CONNECTION AND USE WITH THE NATIONWIDE

TELEPHONE NETWORK

The FCC requires that you connect this telephone to the Nationwide

Telephone Network through a registered jack provided by the telephone

company in your area. This jack is a modular outlet which you can order

from your local telephone company.

10.3 NOTIFICATION TO THE TELEPHONE COMPANY

Before connecting this telephone, the FCC requires that you notify your

local telephone company business office. The number is in the front of

your phone book.

Tell them:

The "line" to which you will connect the telephone (that is, your phone

number) and the telephone's FCC registration number and ringer

equivalence number. These numbers are listed in Section 8.0.

The FCC further requires that you notify your local telephone company

when permanently disconnecting this telephone.

ISSUE 4.0

CEECO

Communication Equipment & Engineering Company

PROPRIETARY

11.0 REPAIR AND RETURN INFORMATION

11.1 WARRANTY REPAIR

Any device returned requiring warranty service, repair or credit must be

accompanied with a "Return Material Authorization" (RMA) FORM. It

must include: return shipping instructions, original purchase order number

and special marking instruction. A description of the trouble observed

must be attached to the defective unit. This information must be inside

the shipping container.

11.2 DIRECT ALL INQUIRES TO:

CEECO

Repair Department

863-357-0798- telephone

863-357-0006- facsimile

[email protected]

www.ceeco.net

11.3 NON-WARRANTY REPAIR

CEECO will repair equipment out of warranty for a set charge plus parts.

The customer must pay the shipping costs both directions.

11.4 RETURN FOR CREDIT

Material may be returned for credit only with prior approval. Material

authorized for return is subject to a 20% restocking charge based on the

manufacturers list price. Return Material Authorization must be requested

no later than 30 days after original shipment.
