Introduction:
With the VG41DA video splitter, you can use one PC to display
identical images on 2, 4, 8, 16 or more monitors.
Video splitter is ideal for:
• Test bench facilities
• Data Center
• Help desk
• Video broadcasting:
Presentation
Stock quotes
Timetables
Educational facilities
Features:
• With 400 MHz pixel frequency.
• Extends the video signal up to 65 meter (213 feet).
• Supports the DDC, DDC2, DDC2B. (For video out port 1)
• Can be cascaded.
• The output is compatible with standard VGA card.
SPECIFICATIONS
VG41DAModel
Video Input Connector (HD-15 Female)
Video Output Connector (HD-15 Female)
2048 x 1536 60 HzMax. Resolution
Pixel Frequency
Cable Distance (Device to Monitor) 65 m (213 feet) Max.
VGA SVGA XGA QXGA UXGA MultisyncSignal Type
DC 12V 600mAPower Adapter (Min.)
455 gthgieW
)HxWxL(snoisnemiD 130x75x42 mm
1
4
400 MHz
MetalHousing
TECHNICAL SPECIFICATIONS
Input/Output Signal
Pin # Signal
1 Red video
2 Green video
3 Blue video
4 ID2
5 Ground
6 Analog Ground
7 Analog Ground
8 Analog Ground
Pin # Signal
9 NC
10 Ground
11 ID0
12 ID1
13 Horizontal Sync
14 Vertical Sync
15 ID3
Front View:
1. Power LED
Rear View:
1. Input Power Jack
2. “Video In” Port
3. “Video Out” Port
1
1 2 3
Installation:
1. Turn off the PC and monitors.
2. Connect the HD-15 video extension cable between the PC and the
“video in” port of splitter.
3. Connect the HD-15 video extension cables between the monitors
and the “video out” ports of splitter.
4. Connect the power cord and turn on the splitter.
5. Turn on the PC and monitors.
Note:
• If you install the DDC monitor for the splitter, the rest of monitors
must be the same resolution as the DDC monitor.
• Supported monitors include the VGA, SVGA, XGA, QXGA, UXGA,
Multisync, and exclude the CGA, EGA, Mono.
