GOLF GPS
MODEL 44870 / 44871
USER’S GUIDE
www.celestronGolf.com
GET TO KNOW YOUR COURSEPRO
KEYS
1. Power/Menu Key
2. 5 Way Navigation Key Pad
(Edges are directional.
Center button is “Select”)
3. Page Key
ICONS
A. Satellite Signal Strength
B. Real Time Display
C. Hole and Par Information
D. Battery Strength
E. Distance to Green Information
AD
E
C
2
B
13
www.celestronGolf.com
DETAILS OF YOUR COURSEPRO
MAIN FEATURES
>> 20,000+ course maps available online
for download
>> 5 FREE course map downloads included
with your purchase
>> Stores up to 50 course maps
>> 2.2” Full transmission mode (TFT) LCD screen;
240x320 pixels / 260K
>> Backlight option for viewing in low light
>> Powered by Lithium Ion 1100maH rechargeable
battery; 8-10 hours of life per charge
>> Water resistant to IXP6 industry standard
>> WAAS enabled and SiRF Star III sensitivity
for better signal strength
>> Green View screen shows the distance
to front, center and back of green
>> Green Edit function allows you to change the
front, center and back distance to green
>> Shot Distance calculator allows you to
measure distance for any shot
>> Time displayed on LCD screen
>> Choice of 12 languages
>> Belt Clip and Soft Storage bag included
>> Mini USB cable included
>> 2 Year Warranty on components
>> Dimensions: 2.30” x 4.6” x 1”
>> Weight: 6 oz.
#44870 #44871
www.celestronGolf.com
CHARGE YOUR COURSEPRO
> Using the included USB cable, plug your CoursePro
into an open USB port on your computer
> Charge time is about 4 to 5 hours
> A full charge will last 8 to 10 hours
NEW USER SETUP
> Log onto www.celestronGolf.com
> Locate and select one of the New User buttons
> Download the latest software
> Create an account and register your CoursePro
> Choose your payment options
DOWNLOAD COURSE MAPS
>> Log onto www.celestronGolf.com and select the ‘Download Courses’ button
>> The Course Download window will load
>> If you are not already signed on, you will be prompted to log in
>> In the search window, type the name of the course you would like to download
or browse through the list to find your course
>> Once the course is located, click the course map icon for your course
>> Depending on your payment plan and the number of courses you may have
already downloaded, you may be prompted to pay for the course
>> Follow the on screen instructions to pay for the course and verify your payment
>> Once verified, the download will begin
>> Once completed you will be prompted to save the course map file to a folder
on your computer
GET STARTED
www.celestronGolf.com
>> Turn on your CoursePro (remember to press and hold the ON button for at
least 3 seconds) and using the mini USB cable, connect it to your computer
>> Open the Course Map Manager software by double clicking the icon on
your desktop
>> If your CoursePro isn’t automatically recognized, click CONNECT [Figure 1]
>> Once your CoursePro is recognized and syncs up with the Course Map
Manager, select ADD COURSE [Figure 2], then OPEN [Figure 3]
>> Browse to your saved folder and select the course map you would like to add
>> The course map will download to your CoursePro and show up in the
MY COURSE window in the Course Map Manager interface
>> Repeat these steps to add more course maps
ADD COURSE MAPS TO YOUR
COURSEPRO
Figure 2
Figure 1
Figure 3
www.celestronGolf.com
> PRESS and HOLD the POWER button for at least 3 seconds.
This screen will appear as your CoursePro
attempts to link to a satellite signal.
Once the satellite signal is locked in, this menu screen
will appear. PRESS the upper or lower point on the
ring of the 5 WAY NAVIGATION key to scroll through
your choices. PRESS the CENTER button of the
5 WAY NAVIGATION key to select the
PLAY GOLF choice.
Your CoursePro will auto search for a local course for
you. You can stop the auto search by pressing the
PAGE key.
PLAY GOLF
www.celestronGolf.com
PLAY GOLF
Once the auto search is complete, your screen will
display the local course along with choices to select
another nearby search or to select your course
manually. To select the displayed course, PRESS
the CENTER button of the 5 WAY NAVIGATION
key. PRESS the upper or lower point on the ring of
the 5 WAY NAVIGATION key to scroll through your
choices and select your choice by again pressing the
CENTER button.
If the course map cannot be found, this screen
will be displayed, and you will be returned to the
PLAY GOLF screen.
If your CoursePro has no course maps downloaded
to its internal memory, this screen will be displayed.
See steps above for downloading course maps and
saving them to your CoursePro.
www.celestronGolf.com
PLAY GOLF
Once you have selected the course you want to play,
the START window will appear. PRESS the left and
right points of the 5 WAY NAVIGATION key to scroll
to your preferred starting hole. PRESS the CENTER
button to select.
The Green View window will appear displaying
information about this hole.
GREEN VIEW INFORMATION:
> Hole Number [A]
> Par for the Hole [B]
> Distance to the back, center
and front of the green [C]
> Real time [D]
> Your round running time [E]
You are now ready to tee off.
A
DE
B
C
www.celestronGolf.com
OTHER FEATURES
I. SHOT DISTANCE PAGE
The Shot Distance page allows you to measure
the distance of any of your shots easily and
precisely. Before teeing off or taking any shot,
PRESS and HOLD the PAGE key until the
displayed distance in the yellow band is reset to
“0”. You are now ready to hit away. After hitting
away, and as you move towards your ball’s new
position, your CoursePro will be calculating the
distance. When you arrive at your ball’s new
position, look at your CoursePro screen.
The number displayed in the yellow band has now
changed to represent the distance that your ball
has traveled. PRESS the CENTER button of the
5 WAY NAVIGATION key to lock this number in.
This number will remain until you want to measure
your shot distance again. Repeat the same steps
to measure your next shot or PRESS the left
edge of the 5 WAY NAVIGATION key to return
to the Scorecard page, or PRESS the right
edge to go to the Edit Course page.
www.celestronGolf.com
The Green Edit feature allows you to change
the distances to the front, center and back of
the green for any hole. From the Green View
page, use the left or right edge of the 5 WAY
NAVIGATION key and scroll to Green View edit
page seen above. Choose to edit by pressing the
PAGE key. Use the top and bottom of the 5 WAY
NAVIGATION key to select which distance you
would like to edit. While standing at the position
that you have chosen, i.e., front, center or back
of the green, mark that position by pressing
and holding the CENTER button. The distance
will be reset to “0”. Mark the other positions, if
you choose to, in the same manner. When you
are completed with your editing, choose OK by
selecting the PAGE key. This will bring you back
to the main Green Edit screen. Use the keypad
to get back to the Green View window and
proceed with play.
OTHER FEATURES
II. GREEN EDIT PAGE
