Celestron FirstScope 114EQ Manuale utente

Use the three tightening screws located at the

bottom of each leg to secure the extended legs

in place.

To set up the tripod, spread the legs outward

until they are fully extended. Extend the center

portion of each of the three tripod legs down 6-

8".

Item #31132

Quick Set-up Guide

123

All three legs should be the same length to

provide a level platform for the telescope.

Locate the equatorial mount and place the

base of the mount through the hole in the

center of the tripod mounting platform.

Properly assembled, the accessory tray should

appear as pictured above.

From underneath the tripod mounting platform,

thread the mounting bolt with washer into the

threaded hole on the bottom of the equatorial

mount.

Thread the latitude adjustment screws into the

equatorial mount until both screws are

touching the inside of the mount and the

mount can no longer pivot up and down.

FirstScope 114

Compact

Your FirstScope 114 includes: optical tube w/ tube

rings attached; tripod with center support bracket;

equatorial mount; two eyepieces; StarPointer

finderscope; 5 lb. counterweight; counterweight bar;

two slow motion cables; eyepiece accessory tray;

documentation including an owner’s manual, The

Sky™ CD Software.

Latitude

Screw #2

Item# 31041

Place the accessory tray on top of tripod's

center leg brace. Thread the tray's post into the

threaded hole in the center of the leg brace.

Questions or Problems with Set-up?

CONTACT:

Celestron Technical Support: 310.803.5955

Quick Set-up Guide [cont]

Locate the counterweight bar and

counterweight. Slide the counterweight half

way down the counterweight bar and tighten

the locking screw to secure in place.

Thread the threaded end of the counterweight

bar into the Dec axis of the equatorial mount.

The longer cable should attach to the Right

Ascension axis and the shorter cable attaches

to the Declination axis..

Properly assembled, the slow motion controls

should appear as pictures above. You should be

able to see the mount move when you turn the

cable knobs.

Remove the wingnuts from the bottom of each

tube ring.

Place the telescope tube on the equatorial

mount so that the threaded posts slide through

the holes on the mount.

17 18

Remove the plastic cap covering the end of

the focuser.

19 20

Insert the chrome barrel of the 20mm eyepiece

into the focuser and tighten the set screw.

Locate the StarPointer finderscope. Remove

the knurled nuts on the threaded posts at the

focuser end of the telescope tube.

Orient the Star Pointer so that the glass

window is facing towards the front of the tube.

Mount the Star Pointer bracket by placing it

over the posts on the tube and tightening it

down with the knurled nuts.

The focuser end of the telescope should be

over the counterweight assembly. Replace the

wing nut and tighten to hold the telescope in

place.

Slide the chrome end of the slow motion

control cables onto equatorial mount gear

shaft.

Loosen the set screw on the focuser so that it

does not obstruct the inner diameter of the

focuser.

Long

Cable Short

Cable

Remove the lens cap from the front of the

telescope. To observe, look through the

eyepiece as shown above.

For detailed usage information please consult your owner’s manual.
