Certikin Dolphin Sport Manuale utente

Pool build procedure for 6m x 4m, 4m x 4m and Dolphin Sport Certikin Wooden Pools

Superior wooden pools, British built to the highest quality

IMPORTANT

Please read before commencing the build process of your wooden pool

The pool timbers have all been pressure treated and depending on the weather and temperature

may remain swollen and damp for some time.

Please allow a reasonable period for the timbers to dry back to their pre-treated size.

As a result, DO NOT ﬁx the upright posts to the steel base shoes (only ﬁx at the top)

as it is important that the pool timbers are allowed to dry and settle into the shoes.

SKU Description Length (mm) Width (mm) Thickness (mm) Per pool (quantity)

SPGPW11 Timber log-lap (notched twice) 3,600 110 45 18

SPGPW12 Timber log-lap base (tongue only, notched twice) 3,600 110 45 2

SPGPW13 Timber log-lap top drilled 4 holes (groove only, notched twice) 3,600 110 45 2

SPGPW02 Timber log-lap full wall base (tongue only, notched twice) 1,786 110 45 2

SPGPW04 Timber log-lap top drilled 3 holes (groove only, notched twice) 1,786 110 45 1

SPGPW03 Timner log-lap top drilled 4 holes top skimmer (groove only, notched twice) 1,786 110 45 1

SPGPW01 Timber log-lap (notched twice) 1,786 110 45 54

SPGPW05 Timber log-lap machined 2 return jets (notched twice) 1,786 110 45 1

SPGPW06 Timber log-lap machined 1 suction point (notched twice) 1,786 110 45 1

SPGPW07 Timber log-lap machined skimmer set bottom 1,786 110 45 1

SPGPW08 Timber log-lap machined skimmer pair (notched once) LH & RH sides 688 110 45 1

SPGPW09 Timber log-lap half base (tongue only, notched twice) 1,786 55 45 4

SPGPW10 Timber log-lap half top (groove only, notched twice) 1,786 55 45 4

SPGPR05 Timber 96 x 96 upper ring beam drilled 4 holes (long side) 3,541 96 96 2

SPGPR01 Timber 96 x 96 upper ring beam drilled 4 holes (skimmer panel) 1,723 96 96 1

SPGPR02 Timber 96 x 96 upper ringbeam drilled 3 holes (intermediate panels) 1,723 96 96 5

SPGPR03 TImber 96 x 96 upright posts drilled top 1,210 96 96 11

SPGPR04 Timber 96 x 96 skimmer support drilled twice 872 96 96 1

SPGPB02 Timber 200 x 50 lower ring beam drilled for corner plate 3,511 200 50 2

SPBPB01 Timber 200 x 50 lower base beam drilled for corner plate 1,729 200 50 6

SPGPT02H Timber 285 x 50 top deck surround (machined and drilled) 3,553 285 50 2

SPGPT01H Timber 285 x 50 top deck surround 1,733 285 50 6

SPGPS01 Pool external timber step set 1

Timber materials list for 6m x 4m pool - END SKIMMER (NO FASTLANE FITTED)

SKU Description Length (mm) Width (mm) Thickness (mm) Per pool (quantity)

SPGPW11 Timber log-lap (notched twice) 3,600 110 45 18

SPGPW12 Timber log-lap base (tongue only, notched twice) 3,600 110 45 2

SPGPW13 Timber log-lap top drilled 4 holes (groove only, notched twice) 3,600 110 45 2

SPGPW02 Timber log-lap full wall base (tongue only, notched twice) 1,786 110 45 2

SPGPW04 Timber log-lap top drilled 3 holes (groove only, notched twice) 1,786 110 45 2

SPGPW03C Timber log-lap skimmer top corner (notched twice) 1786 110 45 1

SPGPW01 Timber log-lap (notched twice) 1,786 110 45 53

SPGPW05 Timber log-lap machined 2 return jets (notched twice) 1,786 110 45 1

SPGPW05FL TImber log-lap2 hole Fastlane panel (notched twice) 1786 110 45 1
