Airow | Electrical | Continuous Plumbed-In Systems Instructions
- Page G -
Airow Instructions
The airow in, and airow out vents have
two functions (Refer to Airow Diagram - Page E):
• To supply fresh air to theVapor-Fire burners.
• To allow airow out of the top of the unit to
maintain optimal vapor ame.
There are a number of options for letting air
in. Some examples include:
• Through the toe kick/baseboards
• Ventilation grate at nished oor
• Other
There are also a number of options for
letting air out. Some examples include:
• Ventilation grate wall/ceiling
• Custom design - reveal at top of wall
• Other
Most importantly, venting must follow
each unit's airow requirements (See Pages A, C &
E).
Consult the project manager for full CF + D
drawings if you are unsure of vent placement.
NOTE: Ensure all vent options have been
addressed before closing the wall.
Electrical Installation
This replace has two CDFI1000P model
burners (40" each) installed.
The replace requires switch power with a
dedicated circuit to control the replace operation
(on/off switch on wall recommended).
NOTE: All electrical to be completed
rst. Do not turn on electrical until
plumbing has been completed.
The electrical and ¼” water line
connection is supplied with the replace. The
electrical connections are to be located at the
oor where the replace will be installed. A
junction box is provided inside the replace for
electrical connection. Found on the left side of the
unit.
A dedicated circuit is required for the
junction box. Connect the power 120V wire, 15
Amp service to the junction box to meet electrical
requirements.
NOTE: Make sure theVapor-Fire
burner power is off before
connecting.
Instructions for Continuous
Plumbed-In Systems
• The plumbing accessory kit is designed for use
with copper piping.
• Ensure that all plumbing connections meet local
plumbing code requirements.
• Ensure that the location of the plumbing
connection allows for easy access for shutoff
during scheduled maintenance.
Normal tap water can be used in theVapor-
Fire as long as the tap water is not considered to
be hard water. In the event your tap water is hard,
softened water is recommended.
