Challenge Xtreme CXPHT22 Manuale utente
Quick Start Guide
Your Safety is most important
22 CC Petrol Hedge Trimmer
CXPHT22
please read these safety rules before you use this machine
General Safety Rules
Read user manual before using the machine
Wear safety goggles to guard your eyes from possible injury
Wear gloves to protect your hands
Wear safety shoes to protect your feet
Wear hearing protection
Note - This quick start guide is intended for experi-
enced users who have already assembled the tool,
please refer to the manual for further details
Quick Start Guide
1Unpack the Hedge Trimmer
a) Open carton carefully and remove all items
b) Ensure you have all items (see above) before you discard the packaging
3Starting the Hedge Trimmer
Do you have questions?
We can help
Call Customer Service
Mon-Thur 08:45 am - 5:00 pm
Friday 08:45 am - 3:15 pm
UK: 0151 649 1500
IRELAND: 189 094 6244
Spare Parts also available
Items Included
1 Plug spanner
2 Spanner
3 Mixing Bottle
4 Blade guard
1
2
3
4
2Fuel / Lubrication
a) Mix the fuel in the mixer bottle provided
b) Shake the container gently to ensure that
it is properly mixed.
N.B Failure to use the correct oil/fuel mixture
will cause the engine to seize
Fuel Mixture is
40:1 (40 parts Fuel
to 1 part 2 stroke oil)
Use regular grade
unleaded petrol
and quality 2 stroke oil
Choke Lever Fuel Cap / tank
Starter Cord
Primer bubble
Ignition switch
Throttle
lever
a) Add the fuel to the hedge trimmer
b) Set the choke lever ON
c) Secure the throttle lever on
d) Push primer 10 times
e) Pull starter cord rapidly 4 times
f) Switch ignition to “I” (on)
g) Pull the starter cord up to 6 more times
NOTE: amount of choke will vary slightly
Depending on the external temperature.
(Warm = choke off “0”, cold = Choke on “I”)
h) Allow engine to warm up at half throttle for
a short time and then push the choke in fully
