Chevrolet 2014 CORVETTE Istruzioni per il montaggio

Review this Quick Reference Guide for an overview of some important features in your Chevrolet

Corvette. More detailed information can be found in your Owner Manual. Some optional equipment

described in this guide may not be included in your vehicle. For easy reference, keep this guide with

your Owner Manual in your glove box.

www.chevrolet.com

Turn Signal

Lever/

Exterior Lamps

Control

Bluetooth

Controls/Driver

Information

Center Controls

Advanced

Theft

Protection

ButtonF

INSTRUMENT PANEL

Stability Control Off

Low Tire Pressure

Brake System

Antilock Brake

System

Stability Control Active

Door Ajar

Cruise Control Set

BRAKE

Electric Parking Brake Set

Charging System

Oil Pressure

Engine Coolant

Temperature

Service Electric

Parking Brake

Traction Control Off

Tilt/Telescopic

Steering

Wheel Control

Audio Next/

Favorite Station

Controls

Symbols

Interior

Lighting

Control

Head-Up

Display

ControlsF

Windshield

Wipers Lever

Trunk/Hatch

Release

Button

Audio

Volume

Controls

Engine

Start/Stop

Button

Cruise

Control

Buttons

Manual Shift

Paddles or

Active Rev

Match On/Off

Power

Mirror

Controls

Hazard Warning

Flashers Button

Infotainment

System Touch

Screen

Driver’s

Heated/

Ventilated Seat

ControlF

Driver Mode

Control/Stability

Control Button

Automatic

Climate Controls

Passenger’s

Heated/

Ventilated Seat

ControlF

Passenger’s

Temperature

Controls

Refer to your Owner Manual to learn about the information being

relayed by the lights and gauges of the instrument cluster.

See In Brief in your Owner Manual.

Accessory

Power Outlet

Electric

Parking Brake

Switch

Low Fuel

Airbag Readiness

Check Engine

Safety Belt Reminder

Security

Screen Storage

Compartment

(with USB)

Button

FOptional equipment

KEYLESS ACCESS SYSTEM

Entering the Vehicle

With the transmitter within range of the

vehicle, press the door handle touch

pad (A) at the rear edge of the door to

unlock and open the door.

Leaving the Vehicle

Press the door latch button on the pull

handle to open the door.

Trunk/Hatch Access

The vehicle must be in Park (automatic

transmission) or the vehicle must be off

with the parking brake set (manual trans-

mission) to open the trunk/hatch. There are

four ways to open the trunk/hatch:

With the transmitter within range of

the vehicle, press the release touch

pad (C).

Press and hold the Trunk/Hatch

button on the transmitter.

Insert the master key from the transmit-

ter into the lock cylinder (D).

From inside the vehicle, press the

Trunk/Hatch button on the left side of

the instrument panel.

Transmitter Battery

If the transmitter battery is weak and the

No Fob Detected message is displayed:

Insert the transmitter into the steering

column pocket with the buttons facing

up and the base facing outward. This

will enable the engine to start.

Replace the transmitter battery as soon as

possible. Refer to the Owner Manual for

battery replacement information.

Note: Do not twist the master key inside the

transmitter to open the case.

See Keys, Doors and Windows in your Owner Manual.

The Keyless Access System enables operation of the doors, ignition and trunk/hatch

without removing the transmitter from a pocket or purse. The transmitter must be within

three feet of the door being unlocked or the trunk/hatch.

Fuel Door: The vehicle must be unlocked

to open the fuel door. With Passive Locking

active, the driver’s door must be opened rst

before the fuel door will unlock. Press and

release the center rear edge of the fuel door

(B) to open it.

AUXILIARY RELEASES

Outside the Vehicle

1. Insert the master key into the lock

cylinder above the license plate and turn

it to open the hatch/trunk.

2. Pull the Door Release handle on the

driver’s side of the hatch/trunk.

If the vehicle battery is weak or disconnected, the driver’s door can be opened manually.

BATTERY CARE TIPS

Battery ChargerF

If the vehicle is not driven weekly or the battery is disconnected or drained, use the

optional battery maintainer to charge the battery. To operate the battery maintainer, plug it

into a standard electrical outlet and into the vehicle’s rear accessory power outlet.

See Vehicle Care in your Owner Manual.

Window Indexing

To provide a tight seal, window indexing automatically lowers the window slightly when the

door is opened and then automatically raises the window when the door is closed.

If battery power is disconnected, reset the indexing feature:

1. Close the doors.

2. Start the vehicle.

3. Hold up the window switch to the fully closed position.

Note: The power windows’ express-up feature and power convertible top

will not operate until the

window indexing feature is reset.

See Keys, Doors and Windows in your Owner Manual.

Inside the Vehicle

Pull the Door Release handle on the

oor next to the driver’s seat.

See Keys, Doors and Windows in your Owner Manual.

FOptional equipment

POWER SEATS

A. Seat Adjustment

Move the front control to move the seat

forward or rearward, or to tilt, raise or

lower the seat.

B. Seatback Recline Adjustment

Move the top of the vertical control to

recline or raise the seatback.

C.Lumbar/SideBolsterAdjustment♦

Move the rear control forward or rear-

ward to adjust the lumbar support.

Move the rear control up or down to

adjust the side bolsters.

See Seats and Restraints in your Owner Manual.

STARTING AND STOPPING THE ENGINE

Start the Engine

• With the vehicle in Park or Neutral,

press the brake pedal (automatic

transmission) or the clutch pedal

(manual transmission) and then press

the ENGINE START/STOP button.

Stopping the Engine

• Shift to Park (automatic transmission

only) and press and hold the ENGINE

START/STOP button.

See Driving and Operating in your Owner Manual.

The Keyless Access transmitter must be in the vehicle to turn on the ignition.

WINDSHIELD WIPERS AND WASHER

HI Fast wipes

LO Slow wipes

INT Intermittent

Rotate the band up for more frequent

wipes or down for less frequent wipes.

OFF

Mist Single wipe

Washer Fluid

Pull the lever toward you to spray washer

uid on the windshield.

See Instruments and Controls in your Owner Manual.

AB C

Move the lever to activate the wipers.

FOptional equipment

EXTERIOR/INTERIOR LIGHTING

Off/On

AUTO Automatic Headlamp System

Automatically activates the Daytime

Running Lamps (DRLs) or the headlamps

and other exterior lamps depending on

outside light conditions.

Parking Lamps

Headlamps

Instrument Brightness Control

Rotate the knob to brighten or dim the

instrument panel lighting.

Turn the knob completely clockwise to turn

on the interior lights.

See Lighting in your Owner Manual.

Exterior Lamps

Rotate the outer band to operate the

exterior lamps.

Interior Lighting

CRUISE CONTROL

Adjusting Cruise Control

RES/+ Resume/Accelerate

Press to resume the set speed.

When the system is active, press to

increase speed.

SET/– Coast

When the system is active, press to

decrease speed.

Cancel

Press to cancel the cruise control without

erasing the set speed from memory.

Pressing the brake pedal or clutch pedal

also will cancel cruise control.

The set speed is erased when cruise

control or the vehicle ignition is turned off.

See Driving and Operating in your Owner Manual.

Setting Cruise Control

1. Press the On/Off button. The

Cruise Control symbol will illuminate in

white on the instrument cluster.

2. When traveling at the desired speed,

press the SET/– button. The symbol

will illuminate in green on the instrument

cluster.

INFOTAINMENT SYSTEM

Power/

Volume

Additional Pages:

Touch to view

additional pages of

applications

(if available)

SCREEN:

Access hidden

storage

compartment

with USB port

Applications:

Touch the screen

icon to access

the application

SEEK:

Previous/Next

radio station,

track or le

BACK:

Move back

one level in

the menus

MEDIA:

Select the

media source Home page

TUNE/MENU:

Tune radio

stations/Open

and select

menus

Interaction

Selector:

Display pages

of favorite

radio stations

RADIO:

Select AM,

FM, XM♦

An accessory power outlet, two USB ports,

3.5mm auxiliary input jack, and an SD card

slot are located in the center console.

An iPod®, iPhone®, MP3 Player, a USB

ash drive or a USB mass storage

device can be connected to the USB

port.

Press the MEDIA button to select a

portable device as the audio source.

See your Infotainment System Owner Manual.

FOptional equipment

Portable Audio Devices – MEDIA

Refer to your Owner Manual for important safety information about using the infotainment system

while driving.

The infotainment system controls include the audio system buttons and touch screen.

INFOTAINMENT SYSTEM

FOptional equipment

Setting the Time

1. Touch Settings on the home page.

2. Touch Time and Date.

3. Touch Set Time.

4. Touch the arrows to adjust the hours, minutes and AM or PM.

5. Touch BACK to exit the menu.

Storing Favorite Stations

Radio stations from all bands (AM, FM or XMF), media (song, artist, album, and genre),

phone contacts and navigation destinationsFcan be stored in any order.

1. Display the desired radio station, media favorite, navigation destination or contact.

2. Swipe up from the bottom of the screen if the favorite buttons are not displayed.

3. Touch and hold one of the favorite buttons until a beep is heard.

4. Repeat the steps to store another favorite item. Swipe up the Interaction Selector

at the bottom of the screen to display additional favorite buttons.

Natural Voice Recognition

Control the music source and make phone calls hands-free (after pairing your Bluetooth-

enabled phone) using the natural voice recognition system.

• Phone(usingyourpairedphone):

Example command: “Call Amanda” or

“Dial 555-1212”

• MediaMusicDeviceSearch(when

connectedtoUSBonly):

Example command: “Play artist [name]”

See Infotainment System in your Owner Manual.

1. Press the Push to Talk button on

the steering wheel.

2. The radio will say “Say a command,”

followed by a beep.

3. Say what you want it to do.

• Radiocontrol:

Example command: “Tune FM 104.3”

Chevrolet MyLink

MyLink uses a Bluetooth or USB connection to link to a compatible smartphone, cell phone,

USB ash drive or portable audio player/iPod®. MyLink enables streaming audio through a

smartphone and hands-free voice control. For assistance with MyLink, contact Customer

Assistance at 1-855-4-SUPPORT (855-478-7767) or visit www.chevrolet.com/mylink.

PANDORA®Internet Radio

Listen to personalized radio stations based on favorite artists or genres.

Download the Pandora app to your smartphone. Restart the smartphone and sign in to

Pandora.

Create a station on your phone to listen to a customized song list in the vehicle.

Connect your smartphone/device to the system by Bluetooth or, for Apple devices,

by a USB cable.

Touch the Pandora icon on the touch screen to access Pandora. A slight delay may

occur when loading a song or changing a station.

See your Infotainment System Owner Manual.

AUDIO STEERING WHEEL CONTROLS

Push to Talk

Press to answer an incoming call or to use

natural voice recognition with the audio,

Bluetooth, navigationFor OnStar®system.

End Call/Mute

Press to end or reject a call.

Press to mute the vehicle speakers.

Next/Previous

With the Audio screen displayed on the

DIC, press or to seek the previous or

next radio station or track.

Volume

Press the top or bottom button to adjust the

volume.

FAV Favorites

Press either button to view the favorites

list. Press the top or bottom button to go to

the next or previous favorite radio station

or track.

See Infotainment System in your Owner Manual.

BLUETOOTH® SYSTEM

Before using a Bluetooth-enabled device in the vehicle, it must be paired with the in-vehicle

Bluetooth system. Not all devices will support all functions. The pairing process is disabled

when the vehicle is moving. For more information, visit www.gmtotalconnect.com.

Pair a Phone

1. To use voice recognition, press the Push to Talk button; after the beep, say “Pair.”

To use the screen buttons, touch the Phone icon > Pair Device.

2. Start the pairing process on the phone. Locate Chevrolet MyLink on the phone.

3. Enter the four-digit code that appears on the touch screen into the phone or, if a six-digit

code appears on the phone, conrm it on the touch screen.

4. If your phone prompts you to accept the connection or phone book download, click “yes”

and always allow.

Streaming Audio

With a paired device connected via Bluetooth, press the MEDIA button until Bluetooth is

displayed on the touch screen to stream audio from the device. Control audio operation

using the device controls.

See Infotainment System in your Owner Manual.

Altri manuali per 2014 CORVETTE

Indice

Altri manuali Chevrolet Automobile

Chevrolet

Chevrolet Sonic 2014 Manuale utente

Chevrolet

Chevrolet 2013 Malibu Istruzioni per il montaggio

Chevrolet

Chevrolet 1994 Blazer Manuale utente

Chevrolet

Chevrolet 2011 Silverado 1500 Crew Cab Manuale utente

Chevrolet

Chevrolet 2004 Corvette Manuale utente

Chevrolet

Chevrolet Blazer 2019 Istruzioni per il montaggio

Chevrolet

Chevrolet 2006 Corvette Manuale utente

Chevrolet

Chevrolet 1993 Corvette Manuale utente

Chevrolet

Chevrolet 2011 Traverse Manuale utente

Chevrolet

Chevrolet 2015 SPARK EV Manuale utente

Chevrolet

Chevrolet VENTURE 2004 Manuale utente

Chevrolet

Chevrolet 2005 Silverado 1500 Pickup Manuale utente

Chevrolet

Chevrolet Cruze 2016 Istruzioni per il montaggio

Chevrolet

Chevrolet Silverado 1500 2021 Manuale utente

Chevrolet

Chevrolet 1998 Corvette Manuale utente

Chevrolet

Chevrolet Sonic 2015 Manuale utente

Chevrolet

Chevrolet Impala Limited 2015 Manuale utente

Chevrolet

Chevrolet 2007 TrailBlazer Istruzioni per il montaggio

Chevrolet

Chevrolet Corvette 2934 1956 Manuale utente

Chevrolet

Chevrolet Equinox 2014 Manuale utente

Chevrolet

Chevrolet Malibu 2020 Istruzioni per il montaggio

Chevrolet

Chevrolet 2011 Volt Manuale utente

Chevrolet

Chevrolet Tahoe 2012 Manuale utente

Chevrolet

Chevrolet 2000 Lumina Manuale utente

Manuali Automobile popolari di altre marche

Toyota

Toyota 2000 Tundra Manuale utente

CITROËN

CITROËN DS4 DSign Manuale utente

Lexus

Lexus 2015 CT 200h Manuale utente

Cadillac

Cadillac CTS 2008 Manuale utente

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuale utente

Porsche

Porsche Boxster S Manuale utente

GMC

GMC 2010 Savana 1500 Cargo Manuale utente

KIAM

KIAM SPORTAGE 2014 Manuale elenco delle parti

GMC

GMC 2013 Terrain Istruzioni per il montaggio

GMC

GMC T-Series 1999 Manuale utente

Mercury

Mercury 1998 Mystique Manuale utente

Mercury

Mercury 2007 Mariner Manuale utente

Mazda

Mazda 2007 Mazdaspeed 3 Guida

Mazda

Mazda 2014 CX-5 Manuale utente

GMC

GMC Chevrolet Express 2022 Manuale utente

GMC

GMC 1997 Jimmy Manuale utente

Cadillac

Cadillac 2010 Escalade Manuale utente

Skoda

Skoda FABIA RS - ANNEXE 118 Manuale utente
