INSIDE YOUR VEHICLE

Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . . .2

Instrument Panel Cluster . . . . . . . . . . . . . . . . . . .3

Heated Front Seats . . . . . . . . . . . . . . . . . . . . . . . .4

Power Lumbar Front Seats . . . . . . . . . . . . . . . . .4

Passenger Automatic Locking Restraint (ALR) .4

Driver and Front Passenger

Safety Belt Reminder . . . . . . . . . . . . . . . . . . . . . .4

Automatic Dimming Rearview Mirror with

OnStar®, Compass and Temperature Display . . .5

Automatic Climate Control System . . . . . . . . . . .5

Manual Climate Control System . . . . . . . . . . . . .6

Entertainment Systems — Radio/CD . . . . . . . . .6

Touch Screen Navigation Entertainment System

HomeLink®Transmitter . . . . . . . . . . . . . . . . . . . . .8

Steering Wheel Controls (OnStar®/Radio) . . . . . .9

Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Adjustable Pedals . . . . . . . . . . . . . . . . . . . . . . . .10

OUTSIDE YOUR VEHICLE

Power Folding Mirrors . . . . . . . . . . . . . . . . . . . .10

Power Camper-Type Mirrors . . . . . . . . . . . . . . .10

Automatic Headlamp Controls . . . . . . . . . . . . . .11

Daytime Running Lamps (DRL) . . . . . . . . . . . . .11

Content Theft-Deterrent System . . . . . . . . . . . .12

Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Rear Window Removal and Storage . . . . . . . . .13

Lowering the MidgateTM . . . . . . . . . . . . . . . . . . . .15

PERSONALIZING YOUR VEHICLE

Memory Positions for Driver’s Seat,

Mirrors and Power Adjustable Pedals . . . . . . . .16

Memory Settings for Your Vehicle

(Driver Information Center) . . . . . . . . . . . . . . . .16

Odometer/Trip Settings . . . . . . . . . . . . . . . . . . . .17

Fuel Information . . . . . . . . . . . . . . . . . . . . . . . . .18

VEHICLE SYMBOLS GLOSSARY . . . . . . . . . . . . . . . .19

ROADSIDE ASSISTANCE, My GMLink . . . . . . . . . . .20

Congratulations on your purchase of a Chevrolet Avalanche. Please read this information and your Owner

Manual to ensure an outstanding ownership experience. Note that your vehicle may not include all the

features described in this booklet. Place this booklet in your Owner Manual portfolio for easy reference.

A. Air Outlets

B. Lamp Controls

C. Cargo/Top-Box Storage Lamps

Button

D. Automatic Transfer Case/Traction

Assist System (if equipped)/

StabiliTrak®System (if equipped)

E. Radio and OnStar®Steering

Wheel Controls

F. Instrument Panel Cluster

G.Gearshift Lever with

Tow/Haul Selector Button

H. Audio System

I. Dome Lamp Override Button

J. Fog Lamps Button

K. Turn Signal/Multifunction Lever

L. Hood Release

M.Tilt Lever

N. Driver Information Center (DIC)

Buttons

O.Parking Brake Release

P. Comfort Control System

Q.Lighter or Accessory Power Outlet

(if equipped)

R. Accessory Power Outlet

(if equipped)

S. Traction Control Button

T. Glove Box

Getting to Know Your Avalanche

Instrument Panel

See Section 3 of your Owner Manual.

Instrument Panel Cluster

Your vehicle’s instrument panel is

equipped with this cluster or one very

similar to it. The instrument panel

cluster includes these key features:

A. Transmission Temperature Gauge

(if equipped)

B. Tachometer

C. Speedometer and Transmission

Gear Selector

D. Oil Pressure Gauge

E. Fuel Gauge

F. Voltmeter

G.Engine Coolant Temperature

Gauge

H. Driver Information Center (DIC)

and Odometer

IMPORTANT: See Section 3 of your

Owner Manual for more information

about what the lights, gauges and

indicators on your vehicle’s instru-

ment panel tell you about your

vehicle’s operation.

Getting to Know Your Avalanche

Heated Front Seats (if equipped)

This feature allows you to heat the front

seatbacks and seat cushions simultane-

ously or just the seatbacks. The controls

are located on the driver and front pas-

senger door panels.

Select a heat setting for both the

seatback and seat cushion

• Press and release the horizontal

button (“A” above) until the indicator

light shows the desired setting.

Select a heat setting for the seatback

only

• Press and release the vertical button

(“B” above) until the indicator light

shows the desired setting.

See Section 1 of your Owner Manual.

Passenger Automatic Locking

Restraint (ALR)

The safety belt is designed to lock

during an accident, but it will also lock if

it is pulled out all the way during initial

buckling, and you may be unaware that

this has happened. If the safety belt

does lock, unbuckle it and allow it to

retract fully, then pull it out and re-buckle

the belt.

See Section 1 of your Owner Manual.

Power Lumbar Front Seats

(if equipped)

Adjust lumbar

support

• Press the front

or rear of the

control located

on the side of

the seat cush-

ion near the door. Release at the pre-

ferred setting.

Adjust outer portion of lumbar seat-

back area

• Press the top or bottom of the lumbar

control. Release at the preferred

setting.

See Section 1 of your Owner Manual.

A chime will sound and the safety belt

light ( ) will be illuminated and flash

for several seconds when the ignition

key is turned to Run or Start, or at

any time the vehicle is running, and the

driver’s safety belt is not buckled.

If your vehicle is equipped with the pas-

senger sensing system, the chime will

sound and a message will be displayed

on the Driver Information Center for

several seconds if the passenger’s

safety belt is not buckled under the

same conditions.

See Section 3 of your Owner Manual.

Driver and Front Passenger

Safety Belt Reminder

(if equipped)

Automatic Dimming Rearview

Mirror with OnStar®, Compass

and Temperature Display

(if equipped)

Controls for the dimming feature, as well

as OnStar®(if equipped) and the com-

pass and temperature displays, are

located on the bottom of the mirror.

When on, the automatic interior dimming

rearview mirror automatically dims to the

proper level to minimize glare from lights

behind you when it’s dark outside.

Turn the self-dimming function

on or off

• Press and hold for approximately

eight seconds.

Use the OnStar system

• Press to connect to an OnStar®

Advisor.

• Press or (depending on vehi-

cle equipment) to answer or end a

call from the OnStar®Center or

Personal Calling.

•Press in an emergency to connect

to an OnStar®Advisor who can con-

tact the nearest emergency services

provider.

Automatic Climate Control

System (if equipped)

Adjust settings for automatic

operation

• Push the AUTO button (“A” above)

and adjust the temperature knob (“B”

above) to the desired temperature.

When automatic operation is active,

the system will control the inside

temperature, air delivery, air inlet and

fan speed.

Set same temperature for driver and

front passenger

• Press and hold the AUTO button for

four seconds.

•Turn the passenger-side temperature

knob to select a different temperature

for the passenger.

Turn the outside temperature displays

and compass readings on or off

• Press .

Display temperature

• Press and hold for four seconds

(until the display blinks) to toggle

between °C and °F. Once the desired

°C or °F is displayed, release the

button. Wait four seconds and the

temperature will be displayed.

See Section 2 of your Owner Manual.

Getting to Know Your Avalanche

Manual Climate Control System

(if equipped)

Adjust settings for operation

• Adjust air delivery location with mode

control knob (“A” above).

Entertainment Systems —

Radio/CD

Set the time on radios without a

Radio Data System (RDS)

• Press and hold the HR or MIN arrow

for two seconds.

• Press the HR (down) arrow until the

correct hour appears on the display.

• Press and hold the MIN (up) arrow

Select air distribution manually

• Press and release the MODE

button (“C” previous page) until the

desired source of air is indicated on

the display.

The MODE feature allows you to select

air delivery to the floor, the instrument

panel outlets, or the windshield outlets.

Manually raise or lower fan speed

•

Press the upper or lower portion of the

FAN control button (“D” previous page).

Additional Climate Control System

Functions

:Recirculates interior air while in

Vent, Bi-Level positions. Use this setting

to get maximum cooling from the air

conditioning system. To prevent

window fogging, Recirculation will not

operate in the Defog, Defrost or Floor

mode.

:Clears windshield and front side

windows of fog/frost.

:Clears rear glass of fog/frost and

activates heated outside rearview mir-

rors (if equipped).

See Section 3 of your Owner Manual.

• Adjust driver/passenger temperatures

with levers (“B” left).

• Set fan speed to desired setting

(“C” left).

Additional Climate Control System

Functions

:Recirculates interior air while in

Vent, Bi-Level positions. Use this setting

to get maximum cooling from the air

conditioning system. To prevent

window fogging, Recirculation will not

operate in the Defog, Defrost or Floor

mode.

:Clears windshield and front side

windows of fog/frost.

:Clears rear glass of fog/frost and

activates heated outside rearview mir-

rors (if equipped).

:Turns the air conditioning

system on and off. The button’s LED

will illuminate when the air conditioning

system is on.

See Section 3 of your Owner Manual.

Note: When the climate control system

is in the OFF position ( ), outside air

will continue to enter the vehicle and will

be directed according to the mode

position selected. This is normal climate

control operation.

• Press AUTO EQ or AUTO TONE

(as applicable to your radio) to select

the equalization that best suits the

type of station selected.

• Press and hold one of the six num-

bered buttons until a beep sounds;

release the button.

• Repeat these steps for each station

preset, using a different numbered

button for each station.

Access one of the two available XM

Satellite Radio bands (if equipped)

• Press the BAND button until XM1 or

XM2 appears on the display. (Note:

Requires subscription to XM Radio.)

Six-Disc CD Changer (if equipped)

Loading/Unloading

Quick Load

• Press LOAD (“A” above) for approxi-

mately three seconds. The lowest

available number will flash.

•Wait for amber lights to flash on

sides of slot (“B” above) before insert-

ing CD. The next available number

will flash and accept another CD until

all are occupied.

• To exit Quick Load, press either a

number with a CD in it or LOAD.

Quick Unload

•Press EJECT ( ) for approx-

imately three seconds; all CDs will

eject from highest number to lowest.

until the correct minute appears on

the display.

Set the time on radios with a Radio

Data System (RDS)

Your radio may have a button marked

“H” or “HR” to represent hours and an

“M” or “MIN” to represent minutes.

• Press and hold the hour button until

the correct hour appears on the

display.

• Press and hold the minute button

until the correct minute appears on

the display.

Program radio station presets

• Turn the radio on.

• Press BAND to select the band

(AM, FM1/FM2/XM1/XM2).

• Use the seek or tune knob to tune in

the desired station.

Note: The time may be set with the

ignition on or off.

Getting to Know Your Avalanche

Touch Screen Navigation

Entertainment System

(if equipped)

Your vehicle’s Navigation Entertainment

System provides you with detailed maps

of all major highways and roads

throughout the United States. After you

enter a destination, the system provides

turn-by-turn instructions for reaching

HomeLink®Transmitter

(if equipped)

Program HomeLink

1. Determine which of the three chan-

nels (buttons) you want to program:

garage door opener, gate opener,

entry door locks or other.

2. Press and hold the desired HomeLink

button through step 3.

3. When the HomeLink light blinks slow-

ly (within 30 seconds), hold your

transmitter/opener 1" to 3" away from

the HomeLink buttons. Then hold

your transmitter button on until the

HomeLink light flashes rapidly (up to

90 seconds). The process is now

complete.

See Section 2 of your Owner Manual.

Note: If your transmitter has a “rolling

code” feature, the above process may

not work. Please refer to your Owner

Manual or contact HomeLink at

1-800-355-3515 (www.homelink.com).

Load 1 CD

• Press LOAD; all available numbers

will flash amber.

• Select the number desired.

•Wait for amber lights to flash on

sides of slot before inserting CD.

• Insert CD.

• Repeat to load more CDs.

Unload 1 CD

• Press EJECT ( ).

• Press number for CD desired.

Play a CD

• Option 1: Select the number for the

CD desired (wait eight seconds).

• Option 2: Press 5/SIDE button on

radio face to scroll through CDs.

Select CD Track

• Option 1: PREV/NEXT on radio.

• Option 2: SEEK arrows on radio.

• Option 3: SEEK arrows on steering

wheel.

See Section 3 of your Owner Manual.

your destination. In addition, the system

can help you locate banks, airports,

restaurants, post offices, ATMs and

more.

See your Owner Manual or Navigation

Entertainment System Quick Reference

Guide for operating instructions.

See Section 3 of your Owner Manual.

Steering Wheel Controls

(OnStar®/Radio) (if equipped)

: (OnStar/Voice Recognition)

(if equipped): This button will activate

OnStar®for use. (Note: If your vehicle is

not equipped with the OnStar® system,

pressing this button will mute the radio.

For additional OnStar®features informa-

tion, including Personal Calling and

Virtual Advisor, see the OnStar®section

of your Owner Manual.)

PROG : This button will cycle through

the radio presets.

: Selects AM, FM, XM Satellite

Radio (if equipped), cassette or CD.

: Seeks radio stations.

: Adjusts radio volume.

See Sections 2 and 3 of your Owner Manual.

Cruise Control (if equipped)

Cruise control allows you to maintain a

constant speed of 25 mph or more with-

out keeping your foot on the accelerator

pedal.

Setting Cruise Control:

1. Move the cruise control switch to on

( ).

2. Attain the speed you want to

cruise at.

3. Press in the Set button ( ) at

the end of the multifunction lever on

the left side of the steering column.

4. Take your foot off the accelerator

pedal.

5. The cruise symbol on the instrument

cluster will illuminate.

Getting to Know Your Avalanche

Power Camper-Type Mirrors

(if equipped)

Extend or retract mirrors

• Move the selector switch located

above the mirror control to the center

position (as shown under Power

Folding Mirrors above).

• Press the left side of the four-way

control pad to extend mirrors.

• Press the right side of the four-way

control pad to retract mirrors.

See Section 2 of your Owner Manual.

Power Folding Mirrors

(if equipped)

Fold mirrors

• Move the

selector switch

located above

the mirror

control

(“A” right) to

the center

position.

• Press the right

side of the

four-way control pad (“B” above)

to fold the mirrors in.

• Press the left side of the four-way

control pad to fold the mirrors out.

If the mirrors have been folded manual-

ly, they must be moved through the

power folding cycle three times to reset

them in their tracks.

See Section 2 of your Owner Manual.

Adjustable Pedals

(if equipped)

The buttons used to

adjust the pedals are

located on the driver’s

side door panel.

• Press the button

closest to you to

move the pedals closer to your body.

• Press the button farthest from you to

move the pedals away from your

body.

The vehicle must be in Park (P) for this

feature to operate.

See Section 2 of your Owner Manual.

There are two ways to increase speed

while cruising:

• Use the accelerator pedal to get to a

higher speed. Press at the end of

the multifunction lever to set the

cruising speed. Release the accelera-

tor pedal.

• Press the resume/accelerate switch

(+) to get to a higher speed, and then

release the switch.

To reduce speed while cruising:

• Press and hold at the end of the

multifunction lever until you reach the

desired lower speed, and then

release it.

See Section 3 of your Owner Manual.

Altri manuali per Avalanche 2005

Indice

Altri manuali Chevrolet Automobile

Chevrolet

Chevrolet COLORADO 2011 Manuale utente

Chevrolet

Chevrolet 1980 Light Duty Truck Istruzioni operative

Chevrolet

Chevrolet 1999 Express Van Manuale utente

Chevrolet

Chevrolet Enjoy Manuale utente

Chevrolet

Chevrolet SILVERADO 2018 Istruzioni per il montaggio

Chevrolet

Chevrolet Captiva 2007 Guida utente

Chevrolet

Chevrolet Beat diesel Manuale utente

Chevrolet

Chevrolet AVEO - S Manuale utente

Chevrolet

Chevrolet Tahoe 2015 Manuale utente

Chevrolet

Chevrolet 1995 Astro Cargo Manuale utente

Chevrolet

Chevrolet Malibu 2014 Istruzioni per il montaggio

Chevrolet

Chevrolet VOLT 2019 Manuale utente

Chevrolet

Chevrolet 2012 Corvette Manuale utente

Chevrolet

Chevrolet AVEO - S Manuale utente

Chevrolet

Chevrolet spark 2017 Manuale utente

Chevrolet

Chevrolet 1995 Tahoe Manuale utente

Chevrolet

Chevrolet 2009 Corvette Manuale utente

Chevrolet

Chevrolet 2002 Silverado 1500 Pickup Manuale utente

Chevrolet

Chevrolet Corvette GMP 00-Y-ELV 2000 Manuale utente

Chevrolet

Chevrolet 2011 Equinox Manuale utente

Chevrolet

Chevrolet Colorado 2024 Manuale utente

Chevrolet

Chevrolet 2013 VOLT Istruzioni per il montaggio

Chevrolet

Chevrolet Camaro 2014 Istruzioni per il montaggio

Chevrolet

Chevrolet 2001 Astro Manuale utente

Manuali Automobile popolari di altre marche

Toyota

Toyota 2000 Tundra Manuale utente

CITROËN

CITROËN DS4 DSign Manuale utente

Lexus

Lexus 2015 CT 200h Manuale utente

Cadillac

Cadillac CTS 2008 Manuale utente

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuale utente

Porsche

Porsche Boxster S Manuale utente

GMC

GMC 2010 Savana 1500 Cargo Manuale utente

KIAM

KIAM SPORTAGE 2014 Manuale elenco delle parti

GMC

GMC 2013 Terrain Istruzioni per il montaggio

GMC

GMC T-Series 1999 Manuale utente

Mercury

Mercury 1998 Mystique Manuale utente

Mercury

Mercury 2007 Mariner Manuale utente

Mazda

Mazda 2007 Mazdaspeed 3 Guida

Mazda

Mazda 2014 CX-5 Manuale utente

GMC

GMC Chevrolet Express 2022 Manuale utente

GMC

GMC 1997 Jimmy Manuale utente

Cadillac

Cadillac 2010 Escalade Manuale utente

Skoda

Skoda FABIA RS - ANNEXE 118 Manuale utente
