2016 Trax

Getting to Know Your

Review this Quick Reference Guide for an overview of some important

features in your Chevrolet Trax. More detailed information can be

found in your Owner Manual. Some optional equipment described

in this guide may not be included in your vehicle. For easy reference,

keep this guide with your Owner Manual in your glove box.

Symbols

Instrument Panel

Cruise

Control

ButtonsF

Windshield

Wipers/Rear

Wiper Lever

Exterior Lamps Control/

Instrument Panel

Illumination Control

Tilt/Telescope

Steering Wheel

Lever

Turn Signal Lever/

Driver Information

Center Controls

Power

Mirror

Control

Trip

Odometer

Reset Stem*

Storage

Compartment

Hood

Release Lever

Driver

Information

Center

Audio

Steering Wheel

Controls

Low Fuel

Door Ajar

Traction Control Off

Engine Coolant

Temperature

Brake System

Cruise Control Set

StabiliTrak Active

StabiliTrak Off

Low Tire Pressure

Reduced Engine Power

Antilock Brake System

Passenger Safety Belt

Reminder

*To reset the trip odometer

that is currently displayed, press

and hold the reset stem on the

tachometer.

Refer to your Owner Manual

to learn about the information

being relayed by the lights,

gauges and indicators on the

instrument cluster.

See In Brief in your Owner Manual.

Infotainment

System Hazard Warning

Flashers Button

Card

Holder Traction Control/

StabiliTrak

Button

USB Port/

Auxiliary Input Jack

(in glove box)

Climate

Controls

Accessory

Power

Outlet

Check Engine

Oil Pressure

Charging System

Safety Belt Reminder

Airbag Readiness

Security

Power Steering

Lamps On Reminder

Optional equipment

Unlock

Press to unlock the

driver’s door. Press

again to unlock all

doors and liftgate.

Lock

Press to lock all

doors and liftgate.

Vehicle Locator/

Panic Alarm

Press and release to

locate your vehicle. The

turn signal lamps will

ash and the horn will

sound 3 times.

Press and hold to activate the

alarm. The turn signal lamps will ash and

the horn will sound for 30 seconds, or until

the button is pressed again or the ignition

is turned on.

Remote Keyless Entry Transmitter

Remote Vehicle StartF

Press and release the Lock button and

then press and hold the button to

start the engine from outside the vehicle.

After entering the vehicle, turn the igni-

tion to the On position.

• The engine will run for 10 minutes.

Repeat these steps for a 10-minute

time extension.

• Only 2 remote starts are allowed

between ignition cycles.

• Press and hold the button to cancel

a remote start.

Note: To change the remote lock, unlock and

remote start settings, go to Lock, Unlock Settings

in the Vehicle Settings menu. See Vehicle

Personalization on page 12.

See Keys, Doors and Windows in your Owner Manual.

The driver’s window has an express-down/express-up feature. Fully press or pull the

window switch momentarily to lower or raise the window completely. Momentarily

press or pull the window switch again to stop window travel.

See Keys, Doors and Windows in your Owner Manual.

With the vehicle parked, push down the lever on the lower left side of the steering

column to adjust the steering wheel. The steering wheel can then be moved up or

down and in or out. Pull up the lever to lock the steering wheel in place.

See Instruments and Controls in your Owner Manual.

Express Power Window

Tilt/Telescope Steering Wheel

Optional equipment

Manual Driver’s Seat

Seats

A. Seat Fore/Aft Adjustment

Lift the handle under the front of the seat

to slide the seat forward or rearward.

B. Seat Height Adjustment

Ratchet the lever up or down repeatedly

to raise or lower the seat.

C. Seatback Recline Adjustment

Lift the lever to recline or raise the

seatback.

D. Power Lumbar Adjustment

Press the control to adjust the lumbar

support.

A. Power Lumbar Adjustment

Press the control to adjust the lumbar

support.

B. 6-way Seat Adjustment

Move the control to move the seat

forward or rearward and to tilt, raise or

lower the seat.

C. Seatback Recline Adjustment

Lift the lever to recline or raise the

seatback.

Power Driver’s SeatF

Folding Front Passenger Seat

With the head restraint lowered and the seat moved as far back as possible, pull the

recline lever on the outboard side of the front passenger seat to fold the seat at.

Folding Rear Seats 1. Unbuckle the safety belts and return

them to their normal stowed position.

2. Lower the head restraints.

3. Pull up the tab (A) located at the

center front of each seat cushion.

4. Pull up the rear edge of the seat

cushion and tilt it forward.

5. Press the lever (B) in the cup on top of

the seatback. When the red marking is

visible, the seatback is unlatched.

6. Fold down the seatback.

7. When unfolding the seats, make sure

the safety belt buckles are accessible

above the seat cushions.

See Seats and Restraints in your Owner Manual.

Optional equipment

AUTO Automatic Headlamp System

Automatically activates the Daytime

Running Lamps (DRLs) or the headlamps

and other exterior lamps depending on

outside light conditions.

To turn the system off or on, rotate the

knob to the position.

Parking Lamps

Headlamps

Fog LampsF

Press to turn the fog lamps on or off.

Exterior Lamps

Rotate the knob to activate the exterior

lamps.

Lighting

Instrument Brightness Control

Rotate and hold the thumbwheel to adjust

the instrument panel lighting.

Dome Lamp Override – Lamp Off

Door Open – Lamp On

Lamp On

See Lighting in your Owner Manual.

Windshield Wipers

HI Fast Wipes

LO Slow Wipes

INT Intermittent

Rotate the band to adjust the delay

between wipes. The wipers activate more

often as the band is rotated upward.

OFF

1x Single Wipe

Washer Fluid

Pull the lever toward you to spray washer

uid on the windshield.

Windshield Wipers and Washer

Raise or lower the lever to activate the

wipers.

Rear Wiper and Washer

Press the switch on the end of the lever to

operate the rear wiper.

Push the lever away from you to spray

washer uid on the rear window.

ON Slow Wipes

OFF

INT Intermittent Wipes

Washer Fluid

See Instruments and Controls in your Owner Manual.

Instrument Panel Lighting

Dome Lamp

The controls are in the front overhead

console.

Optional equipment

Climate Controls

Recirculation Mode

The Recirculation Mode can help to quickly cool the air inside the vehicle or prevent

outside odors from entering the vehicle. When the Recirculation Mode is used without air

conditioning, the air humidity increases and the windows may fog.

Defog and Defrost Mode

When the Defog or Defrost Mode is selected, the air conditioning also will run when

above certain ambient temperatures to help reduce air humidity.

See Climate Controls in your Owner Manual.

Air Conditioning

Control

Recirculation

Mode

Temperature

Control

Air delivery modes:

Vent Mode

Bi-level Mode

Floor Mode

Defog Mode

Defrost Mode

Fan Speed

Control/Off Heated Outside

Mirror Defogger

Rear Window

Defogger

Driver’s Heated

Seat Control

Passenger’s Heated

Seat Control

Optional equipment

See Infotainment System in your Owner Manual.

Infotainment System

Refer to your Owner Manual for important safety information about using the infotainment system

while driving.

picture & movie:

View a picture or

play a video

telephone:

Open the

Phone menu

audio:

AM, FM, XM

, iPod/

iPhone®, USB, Aux,

Bluetooth audio

smartphone link:

Access

smartphone apps

Storing Favorite Stations

Radio stations from all bands (AM, FM or XMF) can be

stored, in any order, on up to seven pages of favorites.

1. Tune in the desired radio station.

2. Touch the or button to display the page

where the station is to be stored.

3. Touch and hold one of the ve preset screen

buttons until a beep is heard.

4. Repeat the steps for each desired station.

Go to the

Home page

Power

VOL:

Volume

settings:

Open the Settings menu –

Languages, Time and Date, Radio,

Bluetooth, and Vehicle settings

Before using a Bluetooth-enabled device in the vehicle, it must be paired with the in-

vehicle Bluetooth system. The pairing process is disabled when the vehicle is moving. Not

all devices will support all functions. For more information, visit my.chevrolet.com/learn.

Pair a Phone

1. Press the Home button.

2. Touch Settings.

3. Touch Connection Settings.

4. Touch Bluetooth Settings.

5. Touch Pair Device.

6. Touch Search Bluetooth Device.

7. Start the pairing process on your device.

8. Once your device appears on the vehicle’s

touch screen, touch the device name and

conrm the PIN code on the device.

9. When complete, a prompt will request transfer of phone data.

See Infotainment System in your Owner Manual.

Infotainment System

Bluetooth® System

Portable Audio Devices

A USB port and auxiliary input jack are located in the instrument panel upper storage

compartment.

Note: Connect an iPod/iPhone USB cord after

starting the vehicle for optimum performance.

An iPod®, iPhone®, MP3 Player, or a USB

drive can be connected to the USB port.

Compatible devices connected to the

USB port can be controlled by the audio

system. Not all devices may be supported.

Use the audio controls and audio steering

wheel controls to access various functions.

See Infotainment System in your Owner Manual.

MyLink uses a Bluetooth or USB connection to link to a compatible device, such as a

smartphone, cell phone, USB ash drive or portable audio player/iPod®. MyLink enables

a variety of entertainment options and smartphone apps. Connect your smart-

phone/device to the system by Bluetooth or, for Apple devices, by a USB cable. For

assistance with the MyLink system, contact Customer Assistance at 1-855-4-SUPPORT

(1-855-478-7767) or visit www.chevrolet.com/mylink.

Following are some of the currently available apps.

PANDORA®Internet Radio

Listen to personalized radio stations based on favorite artists or genres.

1. Download the Pandora app to your smartphone. Restart the smartphone and sign in

to Pandora.

2. Create a station on your smartphone to listen to a customized song list in the vehicle.

3. Connect the smartphone to the infotainment system.

4. Touch Smartphone Link and then the Pandora icon on the touch screen. A slight delay

may occur when loading a song or changing a station.

Stitcher SmartRadio™

Stream favorite podcasts, radio shows and news to your vehicle.

1. Download the Stitcher app to your smartphone. Restart the smartphone and sign in

to Stitcher.

2. Connect the smartphone to the infotainment system.

3. Touch Smartphone Link and then the Stitcher icon on the touch screen.

4. Select a category to listen to. A slight delay may occur when loading a station.

BringGo Navigation (separate purchase required)

Display and control full-function navigation and trafc features.

1. Download the BringGo app to your smartphone. Restart the smartphone.

2. Connect your smartphone to the infotainment system.

3. Touch Smartphone Link and then the BringGo icon on the touch screen.

TuneIn Radio

Listen to favorite radio stations.

1. Download the TuneIn app to your smartphone. Restart the smartphone.

2. Connect your smartphone to the infotainment system.

3. Touch Smartphone Link and then the TuneIn icon on the touch screen.

See Infotainment System in your Owner Manual.

Chevrolet MyLink

Altri manuali per Trax 2016

Indice

Altri manuali Chevrolet Automobile

Chevrolet

Chevrolet Silverado 1500 2023 Manuale utente

Chevrolet

Chevrolet CHEVY-2001 Guida utente

Chevrolet

Chevrolet 2010 Tahoe Police Manuale utente

Chevrolet

Chevrolet EXPRESS - 2011 Manuale utente

Chevrolet

Chevrolet express van 2007 Manuale utente

Chevrolet

Chevrolet 1963 Corvair Manuale utente

Chevrolet

Chevrolet 2002 Corvette Manuale utente

Chevrolet

Chevrolet Spark EV Manuale utente

Chevrolet

Chevrolet Spark 2021 Manuale utente

Chevrolet

Chevrolet Orlando 2013 Manuale utente

Chevrolet

Chevrolet Sail Hatchback Diesel Manuale utente

Chevrolet

Chevrolet 1996 Astro Manuale utente

Chevrolet

Chevrolet SS Sedan 2017 Manuale utente

Chevrolet

Chevrolet Colorado 2020 Istruzioni per il montaggio

Chevrolet

Chevrolet 2013 SONIC Manuale di istruzioni

Chevrolet

Chevrolet 2004 SSR Pickup Manuale utente

Chevrolet

Chevrolet 2005 Express Van Manuale utente

Chevrolet

Chevrolet 2008 Avalanche Manuale utente

Chevrolet

Chevrolet 2003 Venture Manuale utente

Chevrolet

Chevrolet 2015 City Express Manuale utente

Chevrolet

Chevrolet 2005 TrailBlazer Istruzioni per il montaggio

Chevrolet

Chevrolet 2011 Volt Manuale utente

Chevrolet

Chevrolet Silverado 4500HD 2022 Manuale utente

Chevrolet

Chevrolet 2004 Monte Carlo Manuale utente

Manuali Automobile popolari di altre marche

Toyota

Toyota 2000 Tundra Manuale utente

CITROËN

CITROËN DS4 DSign Manuale utente

Lexus

Lexus 2015 CT 200h Manuale utente

Cadillac

Cadillac CTS 2008 Manuale utente

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuale utente

Porsche

Porsche Boxster S Manuale utente

GMC

GMC 2010 Savana 1500 Cargo Manuale utente

KIAM

KIAM SPORTAGE 2014 Manuale elenco delle parti

GMC

GMC 2013 Terrain Istruzioni per il montaggio

GMC

GMC T-Series 1999 Manuale utente

Mercury

Mercury 1998 Mystique Manuale utente

Mercury

Mercury 2007 Mariner Manuale utente

Mazda

Mazda 2007 Mazdaspeed 3 Guida

Mazda

Mazda 2014 CX-5 Manuale utente

GMC

GMC Chevrolet Express 2022 Manuale utente

GMC

GMC 1997 Jimmy Manuale utente

Cadillac

Cadillac 2010 Escalade Manuale utente

Skoda

Skoda FABIA RS - ANNEXE 118 Manuale utente
