CHIEF Hospitality Solutions Manuale utente
HOSPITALITY SOLUTIONS
professional av mounts
Why Chief?
Chief mounts appear in the
finest hotels and casinos around
the world, providing end users
the ultimate guest experience
and comforts of home. An
industry leader for more than
30 years, Chief’s innovative AV mounting solutions
are ideal for guest rooms, hanging quietly in
lobbies and common areas, or securely supporting
technology in the outdoors.
Chief is not just a mount provider, but also an
industry partner providing valuable resources to
ensure a complete state-of-the-art solution – from
placement and aesthetics to full integration.
Largest line of mounting solutions worldwide
Chief offers the broadest line of solutions and
supporting accessories worldwide. We aggressively
evolve our products with changing technology, to
ensure that we are at the forefront of the industry.
Top quality products, fast installation
Chief builds unique features into every mount,
focusing on speed of installation while providing
end users with the best in form and function. Our
mounts are shipped fully assembled, and backed by
an expert Technical and Customer Service Team.
year
Multiple levels of assistance
Chief is fully staffed to handle projects of
varying complexity, in a wide range of
applications. Dedicated technical and
design resources work with you to create
the perfect solution on time and within
budget. From custom mounts to fully-
integrated audio visual solutions, we can
assist with as much or as little as you like.
State-of-art standard product mix,
including custom and universal
interfaces, and UL Listed designs
A Display Solutions Team that is
capable of generating completely
unique mounting solutions
Skilled, on-site consulting services
for larger projects
Custom kitting to assist with
sourcing of all aspects of your
installation through Chief - from flat
panel TVs and projectors to cables
and power conditioners
Hospitality Solutions for:
nGuest Rooms
nBathrooms
nLobbies
nConference Rooms
nBars and Restaurants
nOutdoor Patios
nGaming/Casinos
Flat Panel Wall Mounts FSR™nFixed Wall Mount
nLow-profile solution, only 0.75”
(19 mm) deep
n0.5” (13 mm) left/right lateral shift
nVESA 75 x 75 mm and 100 x 100 mm
nAvailable in black
26”
45 lbs
MSR™nFixed Wall Mount
nLow-profile solution, 1.25”
(32 mm) deep*
n1.5” (38 mm) left/right lateral shift
nRapid Level™System for fast,
hands-free leveling on wall
nAvailable in black
50”
125 lbs
PST™nFixed Wall Mount
nLow-profile solution, 1.21”
(31 mm) deep*
n4” (102 mm) left/right lateral shift
nRapid Level™System for fast,
hands-free leveling on wall
nAvailable in black
65”
200 lbs
*Depth does not include interface bracket
Common Applications
Guest Room
Bathroom
Common Area
Lobby
Restaurant/Bar
(20.4 kg)
(56.7 kg)
(90.7 kg)
FTR™nTilt Wall Mount FWS™nSingle Swing Arm
n+5/-15˚ smooth fingertip tilt
nLow-profile solution, 1.95”
(50 mm) deep
n0.5” (13 mm) left/right lateral shift
nVESA 75 x 75 mm and 100 x 100 mm
nAvailable in black
nExtends 9.44” (240 mm) and pivots
up to 180˚ for broad range of motion
n+/-15˚ Centris™Fingertip Tilt
nIn-arm cable channels conceal and
protect cables
nAvailable in black and silver
26”
45 lbs
26”
40 lbs
MTR™nTilt Wall Mount MPW™nDual Swing Arm
n15˚ tilt adjustment
n1.5” (38 mm) left/right lateral shift
nRapid Level™System for fast,
hands-free leveling on wall
nAvailable in black
nExtends 8.75” (222 mm) and swivels
up to 45˚ for broad range of motion
nLow-profile solution, only 1.5”
(38 mm) deep in home position*
nIntegrated lateral shift
nAvailable in black and silver
50”
125 lbs
50”
100 lbs
PLP™nPull-N-Tilt™Wall Mount PDR™nDual Swing Arm
n15˚ smooth fingertip tilt
nLow-profile solution, 1.8”
(46 mm) deep*
nBottom pulls out 3” (76 mm) for
easy cable access and routing
nAvailable in black
nExtends 37.38” (949 mm) and swivels
up to 90˚ for broad range of motion
n+5/-15˚ Centris™Fingertip Tilt
nIn-arm cable channels conceal and
protect cables
nAvailable in black and silver
65”
200 lbs
65”
200 lbs
(20.4 kg)
(56.7 kg)
(90.7 kg)
(18.1 kg)
(45.4 kg)
(90.7 kg)
Table Stands MTS™nBolt-Down Table Stand
nSecure bolt-down design
nKeyed locking options
nSwivel of +/- 10˚, 20˚, 30˚, 40˚or 270˚
nQuick-connect/disconnect for fast
installation and service
nAvailable in black and silver
45”
100 lbs
MSS™nSwivel Table Stand
n+/-45˚ swivel with optional stops at
+/-15˚, 25˚ or 35˚
n5” (127 mm) height adjustment for
screen heights up to 32” (813 mm)
nTwo cable management options
nAvailable in black and silver
50”
125 lbs
MPO™nPull-Out Swivel Mount
nFor new or retrofit cabinet and
armoire installations
n5.5” (140 mm) SmoothGlide™
extension for better viewing angle
n15˚ yaw left and right of center
nAvailable in black
40”
130 lbs
Also Available: PSS™Swivel Table Stand for large flat
panel TVs up to 50” and 175 lbs (79.4 kg)
Common Applications
Guest Room
Common Area
Conference Room
(45.4 kg)
(56.7 kg)
(59 kg)
MF1™nDisplay Stand
n4’ - 7’ (1.2 m - 2.1 m) telescoping
height adjustment
n+/-15˚ Centris™Fingertip Tilt
nClickConnect™Technology confirms
flat panel is secure - no tools or levers
nAvailable in black and silver
50”
125 lbs
MFC™nMobile Cart
n4’ - 6’ (1.2 m - 1.8 m) telescoping
height adjustment
n+/-15˚ Centris™Fingertip Tilt
nClickConnect™Technology confirms
flat panel is secure - no tools or levers
nAvailable in black and silver
Also Available: PF1™Display Stand for extra-large flat
panel TVs up to 65” and 200 lbs (90.7 kg)
Also Available: PFC™Mobile Cart for extra-large flat
panel TVs up to 65” and 200 lbs (90.7 kg)
Display Carts & Stands
Common Applications
Common Area
Lobby
Conference Room
(56.7 kg)
50”
125 lbs
(56.7 kg)
Automated Mounts CM1W18™nSwing Arm Mount
nExtends 18” (457 mm) and swivels up
to 50˚ for a broad range of motion
nCollapses to 4.25” (108 mm) with a
recessed installation
n3 progammable viewing positions
nAvailable in black
61”
170 lbs
CM7W12™nSwing Arm Mount
nExtends 12” (305 mm) and swivels up
to 28˚ for a broad range of motion
n2 programmable viewing positions
nEasy on-wall installation with
decorative cover for a finished look
nAvailable in black
63”
180 lbs
Common Applications
Guest Room
Common Area
Lobby
Conference Room
(77.1 kg)
(81.6 kg)
CM2L40™nPop-Up Lift CM3T45™nSwivel Table Stand
nTravels up to 40” (102 cm) with a
stored height of only 31” (787 mm)
nProvides quick, quiet travel at over 2”
(51 mm) per second
nIntegrated cable management
nAvailable in black
n+/-45˚ automated swivel with optional
stops at 15˚, 25˚ and 35˚
n5” (127 mm) height adjustment
nFree standing base with bolt-down
capability for increased security
nAvailable in black and silver
61”
190 lbs
50”
125 lbs
CM2C40™nCeiling Lift
nTravels up to 40” (102 cm) with a
stored height of only 31” (787 mm)
nProvides quick, quiet travel at over 2”
(51 mm) per second
nIntegrated cable management
nAvailable in black
61”
190 lbs
(86.2 kg)
(86.2 kg)
(56.7 kg)
Furniture JFA36e™nAV Cabinet
nVersatile 5-shelf design
nAdjustable shelves accommodate
any size AV system
nConvection cooling system keeps AV
components at proper temperature
nAvailable in Espresso
32”
JFV65e™nLowboy Cabinet
nVersatile 3-shelf design
nAdjustable, tempered glass shelves
accommodate any size AV system
nSliding glass doors provide easy
access to AV components
nAvailable in Espresso
80”
275 lbs
JFBD1e™nBackdrop
nMounts directly to back of JFV65e
Lowboy; supports large and
extra-large flat panel wall mounts
nGrade A hardwood veneers and solid
frame provide stability and style
nAvailable in Espresso
63”
100 lbs
Common Applications
Guest Room
Common Area
(45.4 kg)
(124.7 kg)
