Model CKST-4SH
Voltage/Phase/frequency 220V/1PH/50HZ
Amps Per Phase 5.0Amps
Min.Circuit Size 6.5Amps
Heating Capacity 4.0KW
Heating Power Input 1.1KW
Heating COP※4.2
Noise Level 48dB(A)@3m
Type Rotary
Number Per Unit 1
FLA(Full Load Amp) 5.5Amps
Voltage/Phase 220-240V/1PH
Type Propeller
Number Per Unit 1
Power Input 0.2KW
Voltage/Phase 220~240V/1PH
Fan Speed 720Rmp
Type Plate Type Heat Exchanger
Water Flow Volume (m^3/h) 0.8
Max.Outlet Water Temp 55℃
Water Connection 3/4Inch
Refrigerant R410A
Defrost Automatic Hot Gas Injection
Shipping weight Outdoor Unit:70kg;Intdoor Unit:18kg
Dimension L x W x H (mm) Outdoor Unit:780*258*540
Intdoor Unit:455*185*605
※※Heating: Outdoor Air Temp:15℃ DB ,11℃WB, Water Temp: 35℃
※Heating: Outdoor Air Temp:7℃ DB ,6℃WB, Water Temp: 40℃
GENERAL INFORMATION
HEAT EXCHANGER(Water Side)
AIR TO WATER HEAT PUMP-SPLIT TYPE
Fan
Compressor
PERFORMANCE
ELECTRICAL INPUT
TECHNICAL DATA
