C H R Y S L E R 2 00 C O N V E R T I B L E /S P E C I F I C A T I O N S

NOTE: Information shown is correct at time of publication and is subject to change.

2011 Chrysler 200 Convertible

SPECIFICATIONS

The information shown is preliminary and based on data available at the time of publication. All dimensions are in inches

(millimeters) unless otherwise noted. All dimensions are measured at curb weight with standard wheels and tires unless

otherwise noted.

GENERAL INFORMATION

Body Style

Four-door sedan

Assembly Plant

Sterling Heights Assembly, Mich.

EPA Vehicle Class

Mid-size sedan

Introduction Date

January 2011

ENGINE: 2.4-LITER, GASOLINE, DOHC, 16-VALVE, VVT, SMPI I-4

Availability

Standard on 200 Touring

Type and Description

Four-cylinder inline, tuned intake manifold with electronic active charge

motion control valves with dual counter-rotating balance shafts

Displacement

144 cu. in. (2360 cu. cm)

Bore x Stroke

3.46 x 3.82 (88 x 97)

Valve System

Chain-driven DOHC, 16 valves, electronically controlled dual variable-

valve timing (VVT), direct-acting shimless mechanical bucket tappets

Fuel Injection

Sequential, multi-port, electronic, returnless

Construction

High-pressure die-cast aluminum block with dry iron liners, cast-aluminum

cylinder heads, cast-aluminum ladder frame, forged-steel crankshaft

Compression

10.5:1

Power (SAE net, estimated)

173 bhp (129 kW) @ 6,000 rpm (71 bhp/liter)

Torque (SAE net, estimated)

166 lb.-ft. (225 N•m) @ 4,400 rpm

Max. Engine Speed

6,500 rpm (electronically limited)

Fuel Requirement

Unleaded regular, 87 octane (R+M)/2

Oil Capacity

4.5 qt. (4.23L) SAE 5W-20

Coolant Capacity

7.7 qt. (7.3L)

Emission Controls

Single catalytic converter dual heated oxygen sensors and engine

features(a)

Estimated EPA Fuel Economy mpg

(City/Hwy)

18 mpg city/29 mpg highway

(a) Meets Federal Tier 2, Bin 5 emissions requirements and PZEV requirements in California, Massachusetts, New York, Maine,

Vermont, Connecticut, Pennsylvania, Rhode Island, New Jersey, Oregon and Washington. Meets Euro IV emissions

requirements.

ENGINE: 3.6-LITER, GASOLINE, DOHC, 24-VALVE, SMPI V-6

Availability

Available on 200 Touring. Standard on Limited and S

Type and Description

60-degree bank angle, liquid-cooled, three-plenum intake manifold with

electronically controlled manifold tuning valve and short-runner valves

Displacement

3605 cu. cm

Bore x Stroke

3.78 x 3.28 (96 x 83 mm)

C H R Y S L E R 2 00 C O N V E R T I B L E /S P E C I F I C A T I O N S

Valve System

DOHC, 24 valves, hydraulic, roller finger followers

Fuel Injection

Sequential, multi-port, electronic

Construction

High-pressure die-cast A380 aluminum block with iron liners and semi-

permanent mold A319 aluminum heads

Compression Ratio

10.2:1

Power (SAE net, estimated)

283 bhp (211 kW) @ 6,400 rpm

Torque (SAE net, estimated)

260 lb.-ft. (353 N•m) @ 4,400 rpm

Max. Engine Speed

6,800 rpm (electronically limited)

Fuel Requirement

Unleaded regular, 87 octane (R+M)/2

Oil Capacity

6 qt. (5.7L) with dry filter SAE 5W30

Coolant Capacity

11.6 qt. (10.98L)

Emission Controls

Dual catalytic converters, four heated oxygen sensors, electronic EGR,

and internal engine features(d)

Estimated EPA Fuel Economy mpg

(City/Hwy)

19 mpg city/29 mpg highway

(d) Meets Federal Tier 2, Bin 5 emission requirements and ULEV II requirements in California, Massachusetts, New York, Maine,

Vermont, Connecticut, Pennsylvania, Rhode Island, New Jersey, Oregon and Washington. Meets Euro IV emissions

requirements.

TRANSAXLE: 62TE, AUTOMATIC SIX-SPEED OVERDRIVE

Availability

Standard on 200 Touring, Limited and S

Description

Six-speed, adaptive electronic control or Auto Stick driver-interactive

manual control and electronically modulated torque converter clutch

Gear Ratios

1st

4.127

2nd

2.842

3rd

2.283

4th

1.452

5th

6th

0.69

Reverse

3.214

Transfer Ratio

0.95

Final Drive Ratio

3.16 w/ 3.6L engine, 3.43 w/ 2.4L engine

Overall Top Gear

2.06 w/ 3.6L engine, 2.24 w/ 2.4L engine

DRIVETRAIN

Front-wheel Drive

Standard with all engines

DIMENSIONS AND CAPACITIES

General

Wheelbase

108.9 (2765)

Track, Front

61.7 (1567)

Track, Rear

62.7 (1594)

Overall Length

194.8 (4947)

C H R Y S L E R 2 00 C O N V E R T I B L E /S P E C I F I C A T I O N S

Overall Width

72.5 (1842.6)

Overall Height w/Cloth Convertible Top

57.9 (1470)

Overall Height w/Retractable Hard Top

57.8 (1469)

Aero

.34

Fuel Tank Capacity, gal. (L)

16.9 (64.0)

Towing Capabilities, NAFTA Markets lbs. (kg)(e)

2.4L Auto. Trans

1,000 (450)

3.6L Auto. Trans

1,000 (450)

(e) Maximum frontal area of trailer or boat: 22 square feet 3.6L engine and 11 square feet 2.4L engine.

U.S. Curb Weight, Base Vehicle, lbs. (kg)

2.4L Gasoline Engine

3820 (1733) (200 Touring)

3.6L Gasoline Engine

3977 (1804) (200 Touring)

ACCOMMODATIONS

Seating Capacity - F/R

2/2

EPA Total Interior Passenger Volume,

cu. ft. (cu. m)

88.4 (2.50)

Front

Head Room w/o Sunroof

38.7 (984)

Head Room w/Sunroof

39.0 (992)

Legroom

42.4 (1077)

Shoulder Room

56.4 (1432)

Hip Room

52.7 (1339)

Seat Travel

10.2 (260)

EPA Front Compartment Volume,

cu. ft. (cu. m)

53.6 (1.52)

Rear

Head Room w/Cloth Convertible Top

37.0 (939)

Head Room w/Retractable Hard Top

36.3 (921)

Legroom

33.5 (850)

Shoulder Room

48.5 (1233)

Hip Room

44.2 (1123)

EPA Rear Compartment Volume,

cu. ft. (cu. m)

35.0 (0.99)

Cargo

Trunk Lift-over Height

31.2 (792)

EPA Total Trunk Volume – Top Up

13.1 (0.37)

EPA Total Trunk Volume – Top Down

6.6 (0.19)

C H R Y S L E R 2 00 C O N V E R T I B L E /S P E C I F I C A T I O N S

BODY/CHASSIS

Layout

Transverse front engine with front-wheel drive

Construction

Steel unibody

SUSPENSION

Front

Independent MacPherson strut, coil spring over gas-charged shock

absorbers, stabilizer bar

Rear

Multi-link independent with coil springs, link-type stabilizer bar, gas-

charged shock absorbers and isolated rear suspension cradle

STEERING

Type

Power rack and pinion

Overall Ratio

16.65:1

Turning Diameter (curb-to-curb)

36.5 ft. (17-in. wheels), 37.7 ft. (18-in. wheels)

Steering Turns (lock-to-lock)

3.3 (17-in. wheels), 3.0 (18-in. wheels)

BRAKES

Power-assist Type

8 x 9 (204 x 230) tandem-diaphragm vacuum

Availability

Standard on Touring, Limited and S models

Front

Size and Type

11.5 x 1.0 (294 x 26) vented rotors with 2.2 (57.0) single-piston floating

caliper

Swept Area (Total Front)

223.5 sq. in. (1442.1 sq. cm)

Rear

Size and Type

10.3 x 0.4 (262 x 10) solid rotor with 1.4 (35.0) single-piston floating

caliper

Swept Area (Total Rear)

138.6 sq. in. (894.6 sq. cm)

Parking Brake Type

Drum-in-hat

Anti-lock Brake System (ABS)

Standard

Electronic Stability Control (ESC)

Standard

Traction Control

Standard

Brake Assist

Standard

C H R Y S L E R 2 00 C O N V E R T I B L E /S P E C I F I C A T I O N S

WHEELS

Availability

Standard on 200 Touring model

Type and Material

Machined and painted cast-aluminum, Sparkle Silver

Size

17 in. x 6.5 in.

Availability

Standard on 200 Limited model

Type and Material

Polished with Painted Pockets, cast-aluminum, Satin Carbon

Size

18 in. x 7.0 in.

Availability

Standard on 200 S model

Type and Material

Polished with Painted Pockets, cast-aluminum, Gloss Black

Size

18 in. x 7.0 in.

TIRES

Availability

Standard on 200 Touring model

Size and Type

225/55R17, All-season

Model

Michelin Primacy MXV4 Touring

Revs per Mile (km)

778 (1252.0)

Availability

Standard on 200 Limited and S models

Size and Type

P225/50R18, All-season Touring

Model

Goodyear Eagle LS-2 Touring

Revs per Mile (km)

777 (1250.4)

• • •
