TABLE OF CONTENTS

SECTION PAGE

1INTRODUCTION .............................................................3

2THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ...........................7

3UNDERSTANDING THE FEATURES OF YOUR VEHICLE ............................51

4UNDERSTANDING YOUR INSTRUMENT PANEL .................................101

5STARTING AND OPERATING ................................................149

6WHAT TO DO IN EMERGENCIES .............................................175

7MAINTAINING YOUR VEHICLE ..............................................187

8MAINTENANCE SCHEDULES ................................................235

9IF YOU NEED CONSUMER ASSISTANCE .......................................251

10 INDEX ...................................................................261

Information Provided by:

INTRODUCTION

CONTENTS

䡵Introduction

...........................4

䡵How To Use This Manual

.................4

䡵Warnings And Cautions

..................6

䡵Vehicle Identification Number

..............6

Information Provided by:

INTRODUCTION

This manual has been prepared with the assistance of

service and engineering specialists to acquaint you with

the operation and maintenance of your new vehicle. It is

supplemented by a Warranty Information Booklet and

various customer oriented documents. You are urged to

read these publications carefully. Following the instruc-

tions and recommendations in this manual will help

assure safe and enjoyable operation of your vehicle.

NOTE:

After you read the manual, it should be stored

in the vehicle for convenient reference and remain with

the vehicle when sold.

When it comes to service, remember that your manufac-

turers dealer knows your vehicle best, has the factory-

trained technicians and genuine Mopar威parts, and is

interested in your satisfaction.

WARNING!

Engine exhaust, some of its constituents, and certain

vehicle components contain or emit chemicals

known to the State of California to cause cancer and

birth defects or other reproductive harm.

HOW TO USE THIS MANUAL

Consult the table of contents to determine which section

contains the information you desire.

The detailed index, at the rear of this manual, contains a

complete listing of all subjects.

Consult the following table for a description of the

symbols that may be used on your vehicle or throughout

this owner’s manual:

4 INTRODUCTION

Information Provided by:

INTRODUCTION 5

Information Provided by:

WARNINGS AND CAUTIONS

This manual contains WARNINGS against operating

procedures which could result in an accident or bodily

injury. It also contains CAUTIONS against procedures

which could result in damage to your vehicle. If you do

not read this entire manual you may miss important

information. Observe all Warnings and Cautions.

VEHICLE IDENTIFICATION NUMBER

The vehicle identification number (VIN) is on a stamped

plate at the left front corner of the instrument panel,

visible through the windshield. This number also ap-

pears on the Automobile Information Disclosure Label

affixed to a window on your vehicle. Save this label as a

convenient record of your vehicle identification number

and optional equipment.

6 INTRODUCTION

Information Provided by:

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

CONTENTS

䡵A Word About Your Keys

.................9

▫Sentry Key Engine Immobilizer — If

Equipped ............................9

▫Ignition Key Removal ...................12

▫Key-In-Ignition Reminder ................12

▫Floor Shift Ignition Interlock System .........13

䡵Glove Compartment Lock

.................13

䡵Illuminated Entry System

.................14

䡵Door Locks

...........................14

▫Power Door Locks .....................14

▫Central Locking Feature — If Equipped ......15

▫“Child-Protection” Lock System (Rear Doors) . .15

▫Automatic (Rolling) Door Locks ............16

▫Automatic Unlock On Exit (Only Available If

Automatic Door Locks Enabled) ............18

䡵Remote Keyless Entry

....................18

▫To Unlock The Doors ...................18

▫Enable/Disable Lamp Flash ...............19

▫To Lock The Doors .....................19

▫Enable/Disable Horn Chirp ...............19

▫To Unlock The Trunk ....................19

▫Enable/Disable Trunk Press And Hold .......19

▫Panic Alarm ..........................20

▫To Use The Panic Alarm .................20

Information Provided by:

▫To Program Additional Transmitters .........20

▫Transmitter Linked To Memory Programming . .21

▫General Information ....................22

▫Transmitter Battery Service ...............22

䡵Security Alarm System

...................23

▫To Set The Alarm ......................23

▫To Disarm The System ...................24

▫Security System Manual Override ...........24

䡵Power Windows

........................25

䡵Remote Trunk Lid Release

................25

䡵Trunk Safety Warning

....................26

▫Trunk Emergency Release ................26

䡵Occupant Restraints

.....................27

▫Lap/Shoulder Belts .....................28

▫Seat Belts And Pregnant Women ............32

▫Seat Belt Extender ......................32

▫Driver And Right Front Passenger Supplemental

Restraint System (SRS) - Airbag ............33

▫Child Restraint ........................41

䡵Engine Break-In Recommendations

..........48

䡵Safety Tips

............................49

▫Exhaust Gas ..........................49

▫Safety Checks You Should Make Inside The

Vehicle ..............................49

▫Periodic Safety Checks You Should Make

Outside The Vehicle ....................50

8 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Information Provided by:

A WORD ABOUT YOUR KEYS

You can insert the double sided keys into the locks with

either side up.

The dealer that sold you your new vehicle has the key

code numbers for your vehicle locks. These numbers can

be used to order duplicate keys only from your dealer.

Ask your dealer for these numbers and keep them in a

safe place.

CAUTION!

An unlocked car is an invitation to thieves. Always

remove the key from the ignition and lock all the

doors when leaving the vehicle unattended.

Sentry Key Engine Immobilizer — If Equipped

The Sentry Key Immobilizer System prevents unautho-

rized operation of the vehicle by disabling the engine.

The system will shut the engine down after 2 seconds of

running if an invalid key is used to start the vehicle. This

system utilizes ignition keys which have an electronic

chip (transponder) embedded into them. Only keys that

have been programmed to the vehicle can be used to start

and operate the vehicle for more than the two second

validation time period.

The Sentry Key Immobilizer System does not need to be

armed or activated. Operation of the system is automatic

regardless of whether or not the vehicle is locked or

unlocked. During normal operation, the Sentry Key

Indicator light, located on the instrument panel upper

cover, will come on for 3 seconds immediately after the

ignition is turned on for a bulb check. Afterwards, if the

bulb remains on solid, this indicates a problem with the

electronics. If the bulb begins to flash after the bulb check,

this indicates that an invalid key has been used to start

the vehicle or there is a communication failure between

the transponder and the Sentry Key Immobilizer module.

Both of these conditions will result in the engine being

shut down after 2 seconds of running. Keep in mind that

a key which has not been programmed is also considered

an invalid key even if it is cut to fit the ignition for that

vehicle. All of the keys provided with your new vehicle

have been programmed to the vehicle electronics.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 9

Information Provided by:

If the Sentry Key Immobilizer System indicator light

comes on during normal vehicle operation (it has been

running for longer than 10 seconds) a fault has been

detected in the electronics and the vehicle should be

serviced as soon as possible.

NOTE:

•

The Sentry Immobilizer System is not compatible with

remote starting systems. Use of these systems may

result in vehicle starting problems and loss of security

protection.

•

Mobil SpeedPass, additional sentry keys, or any other

transponder equipped components on the same key-

chain will not

cause a key-related (transponder)

fault unless the additional part is physically held

against the ignition key being used when starting

the vehicle. Cell phones, pagers, or other RF Elec-

tronics will also not cause interference with this

system.

The Theft Alarm Light, located on top of the instrument

panel, will illuminate for about 3 seconds when the

ignition switch is first turned to the On position. If the

vehicle electronics do not receive a valid signal from the

ignition key, the theft alarm light will flash continuously

to signal that the vehicle has been immobilized. If the

Theft Alarm Light remains On during vehicle operation,

it indicates a fault in the system electronics.

All of the keys provided with your new vehicle have

been programmed to the vehicle electronics.

Important Note about Service

A four digit PIN is needed to service the Sentry Key

Immobilizer System. This number can be obtained by the

dealership. However, this number can also be found on

your customer invoice that you were given upon receipt

of your vehicle. YOU MUST BRING ALL SENTRY KEYS

that are programmed to your vehicle with you when

bringing your vehicle in for service.

Replacement Keys

NOTE:

Only keys that have been programmed to the

vehicle electronics can be used to start the vehicle. Once

a Sentry Key has been programmed to a vehicle, it can

not be programmed to any other vehicle.

At the time of purchase, the original owner is provided

with a four digit PIN number. This number is required

10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Information Provided by:

Altri manuali per 2004 Concorde

Indice

Altri manuali Chrysler Automobile

Chrysler

Chrysler 1997 Stratus Convertible RHD Manuale utente

Chrysler

Chrysler Town & Country 2011 Manuale utente

Chrysler

Chrysler 2017 Pacifica Manuale utente

Chrysler

Chrysler 2014 Grand Cherokee Manuale utente

Chrysler

Chrysler Sebring Convertible 2010 Manuale utente

Chrysler

Chrysler TOWN & COUNTRY 2010 Manuale utente

Chrysler

Chrysler 2010 PT Cruiser Manuale utente

Chrysler

Chrysler 1998 Voyager Manuale utente

Chrysler

Chrysler PACIFICA 2024 Manuale utente

Chrysler

Chrysler 300C Sedan Manuale utente

Chrysler

Chrysler Town & Country 2011 Manuale utente

Chrysler

Chrysler 2008 Town and Country Manuale utente

Chrysler

Chrysler 200 CONVERTIBLE 2011 Manuale utente

Chrysler

Chrysler 300 2012 Manuale utente

Chrysler

Chrysler CHARGER PURSUIT Manuale del proprietario

Chrysler

Chrysler Imperial 1963 Manuale utente

Chrysler

Chrysler 300 2012 Manuale utente

Chrysler

Chrysler All Vehicles 2013 Manuale di istruzioni

Chrysler

Chrysler Cruiser PT 2010 Manuale utente

Chrysler

Chrysler 2006 PT Cruiser Manuale utente

Chrysler

Chrysler 300c 2015 Manuale utente

Chrysler

Chrysler Pacifica CS 2004 Manuale utente

Chrysler

Chrysler Dodge Avenger 2012 Manuale

Chrysler

Chrysler 2013 Town&Country Manuale utente

Manuali Automobile popolari di altre marche

Toyota

Toyota 2000 Tundra Manuale utente

CITROËN

CITROËN DS4 DSign Manuale utente

Lexus

Lexus 2015 CT 200h Manuale utente

Cadillac

Cadillac CTS 2008 Manuale utente

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuale utente

Porsche

Porsche Boxster S Manuale utente

GMC

GMC 2010 Savana 1500 Cargo Manuale utente

KIAM

KIAM SPORTAGE 2014 Manuale elenco delle parti

GMC

GMC 2013 Terrain Istruzioni per il montaggio

GMC

GMC T-Series 1999 Manuale utente

Mercury

Mercury 1998 Mystique Manuale utente

Mercury

Mercury 2007 Mariner Manuale utente

Mazda

Mazda 2007 Mazdaspeed 3 Guida

Mazda

Mazda 2014 CX-5 Manuale utente

GMC

GMC Chevrolet Express 2022 Manuale utente

GMC

GMC 1997 Jimmy Manuale utente

Chevrolet

Chevrolet 2012 Malibu Manuale utente

Cadillac

Cadillac 2010 Escalade Manuale utente
