1/ CHRYSLER 300 SPECIFICATIONS http://media.chrysler.com

300 / SPECIFICATIONS

2012 Chrysler 300

SPECIFICATIONS

Dimensions are in inches (millimeters) unless otherwise noted.

GENERAL INFORMATION

Body Style

E-segment sedan

Assembly Plant

Brampton Assembly Plant, Ontario, Canada

EPA Vehicle Class

Large car

Introduction Date

2011 model

ENGINE: 3.6-LITER PENTASTAR DOHC 24-VALVE V-6

Availability

Standard — 300, 300 Limited and 300S (V-6) (RWD/AWD)

Type and Description

60-degree V-type, liquid-cooled

Displacement

220 cu. in. (3604 cu. cm)

Bore x Stroke

3.78 x 3.27 in. (96.0 x 83.0 mm)

Valve System

Chain-driven DOHC, 24 valves, hydraulic end-pivot roller rockers

Fuel Injection

Sequential, multi-port, electronic, returnless

Construction

Aluminum deep-skirt block with aluminum-alloy heads

Compression Ratio

10.2:1

Power (SAE net)

292 bhp (218 kW) @ 6,350 rpm (81.1 bhp/L)

Torque (SAE net)

260 lb.-ft. (353 N•m) @ 4,800 rpm

Max. Engine Speed

6,400 rpm (electronically limited)

Fuel Requirement

Unleaded regular, 87 octane (R+M)/2; and E-85 (Federal Bin 5,

37 state compliant)

Oil Capacity

6 qt. (5.7L) with dry filter

Coolant Capacity

14.0 qt. (13.25L)

Emission Controls

Dual three-way catalytic converters, heated oxygen sensors and

internal engine features(a)

Max. Gross Trailer Weight (unbraked trailer)

1,000 lbs. (454 kg)

EPA Fuel Economy mpg (City/Hwy)

18/27 (RWD with WA580 5-speed automatic transmission)

19/31 (RWD with ZF 8HP45 eight-speed automatic transmission)

18/27 (AWD with ZF 8HP45 eight-speed automatic transmission)

Engine Assembly Plant

Trenton South Engine Plant, Trenton, Mich.

(a) Meets Federal Tier 2 Bin 5 emission requirements and ULEV II requirements in California, Massachusetts, New York, Maine, Vermont,

Connecticut, Pennsylvania, Rhode Island, New Jersey, Oregon and Washington.

2/ CHRYSLER 300 SPECIFICATIONS http://media.chrysler.com

300 / SPECIFICATIONS

ENGINE: 5.7-Liter HEMI®V-8 WITH FOUR-CYLINDER MODE FUEL SAVER TECHNOLOGY

Availability

Standard — 300C, 300S (V-8) and 300C Luxury Series

(RWD/AWD)

Type and Description

90-degree V-type, liquid-cooled with variable-cam timing (VCT)

Displacement

345 cu. in. (5654 cu. cm)

Bore x Stroke

3.92 x 3.58 (99.5 x 90.9)

Valve System

Pushrod-operated overhead valves, 16 valves, eight deactivating

and eight conventional hydraulic lifters, all with roller followers

Fuel Injection

Sequential, multi-port, electronic, returnless

Construction

Deep-skirt cast-iron block with cross-bolted main bearing caps,

aluminum alloy heads with hemispherical combustion chambers

Compression Ratio

10.5:1

Power (SAE net)

363 bhp (270 kW) @ 5,200 rpm (63.7 bhp/L)

Torque (SAE net)

394 lb.-ft. (534 N•m) @ 4,200 rpm

Max. Engine Speed

5,800 rpm (electronically limited)

Fuel Requirement

Unleaded midgrade, 89 octane (R+M)/2 — Recommended

Unleaded regular, 87 octane (R+M)/2 — Acceptable

Oil Capacity

7 qt. (6.6L)

Coolant Capacity

14.7 qt. (13.9L)

Emission Controls

Dual close-coupled three-way catalytic converters,

Quad heated oxygen sensors and internal engine features(b)

Max. Gross Trailer Weight

1,000 lbs. (454 kg)

EPA Fuel Economy mpg (City/Hwy)

16/25 (RWD) and 15/23 (AWD)

(b) Meets Tier 2 Bin 4 emission requirements in all 50 states.

TRANSMISSION: AUTOMATIC FIVE-SPEED OVERDRIVE WITH AUTO STICK

Availability

Standard on all Chrysler 300, 300C, 300S V-8 and 300C Luxury

Series (RWD and AWD) models

Description

Adaptive electronic control or Auto Stick driver-interactive manual

control and electronically modulated torque converter clutch

Gear Ratios

1st

3.59

2nd

2.19

3rd

1.41

4th

1.00

5th

0.83

Reverse

3.16

Final Drive Ratio

300, 300C, 300S (V-8) and 300C Luxury Series (RWD) — 2.65

300, 300C, 300S (V-8) and 300C Luxury Series (AWD) — 3.07

Overall Top Gear

300, 300C, 300S (V-8) and 300C Luxury Series (RWD) — 2.20

300, 300C, 300S (V-8) and 300C Luxury Series (AWD) — 2.54

3/ CHRYSLER 300 SPECIFICATIONS http://media.chrysler.com

300 / SPECIFICATIONS

TRANSMISSION: ZF 8HP45 AUTOMATIC EIGHT-SPEED WITH AUTO STICK

Availability

Optional on Chrysler 300 model

Standard on Chrysler 300 Limited and 300S (RWD and AWD)

models

Description

Adaptive electronic control, ‘Sport’ mode or paddle-shifted driver-

interactive manual control. Five clutch-pack design with only two

open clutches in any gear. Off-center line pump with low-viscosity

oil for reduced spin loss. Torque converter lock with turbine

torsional damper for low lock-up speeds in 1st through 8th gear.

Gear Ratios

1st

4.71

2nd

3.14

3rd

2.10

4th

1.67

5th

1.29

6th

1.00

7th

0.84

8th

0.67

Reverse

3.30

Final Drive Ratio

300 (RWD)—2.65

300 Limited and 300S V-6 (RWD)—2.65

300 Limited and 300S V-6 (AWD)—3.07

Overall Top Gear

300 (RWD)—1.78

300 Limited and 300S V-6 (RWD)—1.78

300 Limited and 300S V-6 (AWD)—2.05

TRANSFER CASE

Availability

Standard on Chrysler 300 Limited, 300S (V-6 and V-8) models,

300C and 300C Luxury Series with AWD

Type

Active, fully variable with front-axle disconnect

Center Differential

Planetary

Torque Split, Front/Rear

Fully variable

ELECTRICAL SYSTEM

Alternator

160-amp — standard on 300

180-amp — standard on 300 Limited, 300S (V-6), 300C, 300S

(V-8) and 300C Luxury Series models (RWD/AWD)

Battery

H7 Case, 730 CCA, maintenance-free

4/ CHRYSLER 300 SPECIFICATIONS http://media.chrysler.com

300 / SPECIFICATIONS

DIMENSIONS AND CAPACITIES(d)

Wheelbase

120.2 (3052)

Track, Front

63.4 (1611)

Track, Rear

63.8 (1620)

Overall Length

198.6 (5044)

Overall Width

75.0 (1902)

Overall Height

300 (RWD with 17-in. tires) — 58.4 (1484.4)

300 (RWD with 18-in. tires) — 58.5 (1485.2)

300 (RWD with 20-in. tires) — 58.7 (1492.0)

300 (AWD with 19-in. tires) — 59.2 (1503.9)

Ground Clearance

300 (RWD with 17-in. tires) — 4.7 (120.3)

300 (RWD with 18-in. tires) — 4.7 (120.3)

300 (RWD with 20-in. tires) — 5.0 (127.9)

300 (AWD with 19-in. tires) — 4.8 (122.3)

Drag Coefficient (Cd)

0.320

Curb Weight, lb. (kg)

300 (RWD) — 3,999 (1814)

300 Limited and 300S V-6 (RWD) — 4,029 (1828)

300 Limited and 300S V-6 (AWD) — 4,235 (1921)

300C, 300S V-8 and 300C Luxury Series (RWD) — 4,326 (1962)

300C, 300S V-8 and 300C Luxury Series (AWD) — 4,515 (2048)

Weight Distribution, percent F/R

300 (RWD) — 52/48

300 Limited and 300S V-6 (RWD) — 52/48

300 Limited and 300S V-6 (AWD) — 53/47

300C, 300S V-8 and 300C Luxury Series (RWD) — 55/45

300C, 300S V-8 and 300C Luxury Series (AWD) — 56/44

Fuel Tank Capacity, gal. (L)

19.1 (72.2)

(d) All dimensions measured at curb weight with standard tires.

ACCOMMODATIONS

Seating Capacity, F/R

2/3

Front

Head room

38.6 (981)

36.9 (936.6) with dual-pane sunroof

Legroom

41.8 (1061)

Shoulder room

59.5 (1510)

Hip room

56.2 (1428)

Seat travel

Driver — 10.6 (270)

Passenger — 8.66 (220)

Recliner angle range, deg.

Power — 70.7

Manual — 70

EPA front row interior volume, cu. ft. (cu. m)

55.6 (1.573)

5/ CHRYSLER 300 SPECIFICATIONS http://media.chrysler.com

300 / SPECIFICATIONS

Rear Seat

Head room

37.9 (963)

36.9 (937) with dual-pane sunroof

Legroom

40.1 (1019)

Knee clearance

3.9 (99)

Shoulder room

57.7 (1465)

Hip room

56.1 (1425)

EPA second row interior volume, cu. ft. (cu. m)

50.7 (1.4)

Total Interior Volume, cu. ft. (cu. m)

106.3 (3.0)

EPA Luggage Compartment Volume, cu. ft. (cu. m)

16.3 (0.5)

EPA Interior Volume Index, cu. ft. (cu. m)

122.6 (3.5)

Trunk Liftover Height

30.1 (768.9)

BODY

Layout

Longitudinal front engine, RWD

Construction

Unitized steel body and aluminum hood

SUSPENSION

Front

Independent SLA with high upper “A” arm, coil spring over gas-

charged monotube shock absorbers and stabilizer bar — standard

on 300, 300 Limited and 300C

Lateral and diagonal lower links with dual ball joint knuckles —

standard on 300, 300 Limited and 300C

One piece lower-control arms — standard on 300C AWD only

Rear

Five-link independent with coil springs, gas-charged monotube

shock absorbers, stabilizer bar and isolated suspension cradle —

standard on all 300 models

STEERING

Type

Rack and pinion with hydraulic power assist

Overall Ratio

300 (RWD)—15.5:1

300 Limited and 300S V-6 (RWD)—15.5:1

300 Limited and 300S V-6 (AWD)—16.5:1

300C, 300S V-8 and 300C Luxury Series (RWD)—15.5:1

300C, 300S V-8 and 300C Luxury Series (AWD)—16.5:1

Steering Turns (lock-to-lock)

300 (RWD)—2.8

300 Limited and 300S V-6 (RWD)—2.8

300 Limited and 300S V-6 (AWD)—3.1

300C, 300S V-8 and 300C Luxury Series (RWD)—2.8

300C, 300S V-8 and 300C Luxury Series (AWD)—3.1

6/ CHRYSLER 300 SPECIFICATIONS http://media.chrysler.com

300 / SPECIFICATIONS

TIRES

Availability

Standard on 300 (RWD)

Size and type

P215/65R17 BSW all-season touring

Mfr. and model

Michelin Energy Saver

Revs per mile (km)

748 (465)

Availability

Standard on 300 Limited and 300C (RWD)

Size and type

P225/60R18 BSW all-season performance

Mfr. and model

Firestone FR710

Revs per mile (km)

730 (456)

Availability

Standard on 300C AWD

Size and type

P235/55R19 BSW all-season performance

Mfr. and model

Michelin MXM4

Revs per mile (km)

710 (446)

Availability

Optional on 300 Limited and 300C (RWD)

Size and type

P245/45R20 BSW all-season performance

Mfr. and model

Firestone Firehawk GTV

Revs per mile (km)

725 (451)

WHEELS

Availability

Standard on 300 (RWD)

Type and material

12-spoke design, cast-aluminum, fully painted

Size

17 x 7.0

Availability

Standard on 300 Limited and 300C (RWD)

Type and material

10-spoke design, cast-aluminum, chrome clad

Size

18 x 7.5

Availability

Standard on 300 Limited, 300C and Standard on 300C Luxury

Series (AWD)

Type and material

10 split-spoke design, cast-aluminum, polished face with silver

painted pockets

Size

19 x 7.5

Availability

Standard on 300S (V-6 and V-8 AWD)

Type and material

10 split-spoke design, cast-aluminum, polished face with black

painted pockets

Size

19 x 7.5

7/ CHRYSLER 300 SPECIFICATIONS http://media.chrysler.com

300 / SPECIFICATIONS

Availability

Optional on 300 Limited and 300C (RWD)

Standard on 300C Luxury Series (RWD)

Type and material

10 split-spoke design, cast-aluminum, polished face with silver

painted pockets

Size

20 x 8.0

Availability

Standard on 300S (V-6 and V-8 RWD)

Type and material

10 split-spoke design, cast-aluminum, polished face with black

painted pockets

Size

20 x 8.0

BRAKES

Touring Brake Package

Standard on 300, 300 Limited and 300S (V-6) (RWD)

Front

Rotor size and type

12.6 x 1.1 (320 x 28) vented

Caliper size and type

2.36 (60) single-piston sliding with aluminum housing

Swept area

259 sq. in. (1671 sq. cm)

Rear

Rotor size and type

12.6 x 0.4 (320 x 10) solid

Caliper size and type

1.65 (42) single-piston sliding with aluminum housing

Swept area

264 sq. in. (1703 sq. cm)

Performance Brake Package

Standard on 300C, 300S (V-8) and 300C Luxury Series (RWD)

Standard on 300 Limited and 300S (V-6) (AWD)

Front

Rotor size and type

13.6 x 1.26 (345 x 28) vented

Caliper size and type

1.65 (42) dual-piston sliding with aluminum housing

Swept area

249 sq. in. (1606 sq. cm)

Rear

Rotor size and type

12.6 x 0.87 (320 x 22) vented

Caliper size and type

1.65 (42) single-piston sliding with aluminum housing

Swept area

264 sq. in. (1703 sq. cm)

8/ CHRYSLER 300 SPECIFICATIONS http://media.chrysler.com

300 / SPECIFICATIONS

SUSPENSION

Comfort-tuned Suspension

Standard on 300, 300 Limited and 300C (RWD)

Front

Stabilizer bar

25 mm, solid

Shock type/rate

Monotube with 204 lb./in.

Rear

Stabilizer bar

12 mm, solid

Shock type/rate

Monotube with 547 lb./in.

Touring-tuned Suspension

Standard on 300S (V-6 RWD) and 300C Luxury Series

Optional on 300 Limited and 300C (RWD) with 20-in. wheels

Front

Stabilizer bar

27 mm, solid

Shock type/rate

Monotube with 240 lb./in.

Rear

Stabilizer bar

16 mm, solid

Shock type/rate

Monotube with 547 lb./in.

AWD Touring-tuned Suspension

Standard on 300 Limited, 300S (V-6 and V-8), 300C and 300C

Luxury Series (AWD)

Front

Stabilizer bar

32 mm, solid

Shock type/rate

Monotube with 340 lb./in.

Rear

Stabilizer bar

16 mm, solid

Shock type/rate

Monotube with 600 lb./in.

Performance-tuned Suspension

Standard on 300S (V-8) (RWD)

Front

Stabilizer bar

27 mm, solid

Shock type/rate

Monotube with 340 lb./in.

Rear

Stabilizer bar

16 mm, solid

Shock type/rate

Monotube with 670 lb./in.

• • •

Altri manuali per 300 2012

Indice

Altri manuali Chrysler Automobile

Chrysler

Chrysler Caliber SRT4 Manuale utente

Chrysler

Chrysler 3500 CHASSIS CAB Manuale del proprietario

Chrysler

Chrysler Crossfire Manuale utente

Chrysler

Chrysler 2005 300 SRT8 Manuale utente

Chrysler

Chrysler 200 Convertible 2012 Manuale utente

Chrysler

Chrysler 1991 Stealth Documento tecnico

Chrysler

Chrysler 200 Convertible Manuale utente

Chrysler

Chrysler 2004 Town and Country Manuale utente

Chrysler

Chrysler Stratus RHD 1997 Manuale utente

Chrysler

Chrysler Sebring Manuale utente

Chrysler

Chrysler TOWN & COUNTRY 2016 Manuale utente

Chrysler

Chrysler 300 includes srt8 2010 Manuale utente

Chrysler

Chrysler 2006 Pacifica Manuale utente

Chrysler

Chrysler 300 2014 Manuale utente

Chrysler

Chrysler Prowler (PR) 2002 Manuale di istruzioni

Chrysler

Chrysler Automobile Manuale utente

Chrysler

Chrysler Sebring Convertible Manuale utente

Chrysler

Chrysler SRT Viper Manuale utente

Chrysler

Chrysler Town & Country 2014 Manuale utente

Chrysler

Chrysler 2005 Town and Country Manuale utente

Chrysler

Chrysler Sebring Manuale utente

Chrysler

Chrysler TOWN & COUNTRY 2009 Manuale utente

Chrysler

Chrysler RAM TRUCK 2500 1994 Manuale utente

Chrysler

Chrysler PACIFICA HYBRID 2019 Manuale utente

Manuali Automobile popolari di altre marche

Toyota

Toyota 2000 Tundra Manuale utente

CITROËN

CITROËN DS4 DSign Manuale utente

Lexus

Lexus 2015 CT 200h Manuale utente

Cadillac

Cadillac CTS 2008 Manuale utente

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuale utente

Porsche

Porsche Boxster S Manuale utente

GMC

GMC 2010 Savana 1500 Cargo Manuale utente

KIAM

KIAM SPORTAGE 2014 Manuale elenco delle parti

GMC

GMC 2013 Terrain Istruzioni per il montaggio

GMC

GMC T-Series 1999 Manuale utente

Mercury

Mercury 1998 Mystique Manuale utente

Mercury

Mercury 2007 Mariner Manuale utente

Mazda

Mazda 2007 Mazdaspeed 3 Guida

Mazda

Mazda 2014 CX-5 Manuale utente

GMC

GMC Chevrolet Express 2022 Manuale utente

GMC

GMC 1997 Jimmy Manuale utente

Chevrolet

Chevrolet 2012 Malibu Manuale utente

Cadillac

Cadillac 2010 Escalade Manuale utente
