1/ 300 SRT8® SPECIFICATIONS http://media.chrysler.com

300 SRT8®

SPECIFICATIONS

2012 Chrysler 300 SRT8®

SPECIFICATIONS

All dimensions are in inches (millimeters) unless otherwise noted.

All dimensions are measured at curb weight with standard tires and wheels.

Note: Information shown is correct at time of publication, and is subject to change without notice.

GENERAL INFORMATION

Body Style

E-segment sedan

Assembly Plant

Brampton Assembly Plant, Ontario, Canada

EPA Vehicle Class

Large car

Introduction Date

Summer 2011 as 2012 model

ENGINE: 6.4-LITER HEMI®V-8 WITH FUEL SAVER TECHNOLOGY

Availability

Standard

Type and Description

90-degree V-type, liquid-cooled

Displacement, cu. in. (cu. cm.)

392 (6,424)

Bore x Stroke

4.09 x 3.72 (103.9 x 94.5)

Valve System

Pushrod-operated overhead valves, 16 valves with sodium-filled

exhaust valves and hollow stem intake valves,

16 conventional hydraulic lifters, all with roller tips

Fuel Injection

Sequential, multi-port, electronic, returnless; automatic features

Fuel Saver mode

Construction

Deep-skirt cast-iron block with cross-bolted main bearing caps,

aluminum alloy heads with hemispherical combustion chambers

Compression Ratio

10.9:1

Power (SAE J2723)

470 hp (351 kW) at 6,000 rpm

Torque (SAE J2723)

470 lb.-ft. (637 N•m) at 4,300 rpm

Max. Engine Speed

6,400 rpm (electronically limited)

Fuel Requirement

Premium 91 octane (R+M)/2 — recommended

Oil Capacity, qt. (L)

7 (6.6)

Factory Oil Fill

5W-40 Synthetic

Coolant Capacity, qt. (L)

14 (13.25)

Emission Controls

Dual close-coupled three-way catalytic converters, quad-heated

oxygen sensors and internal engine features(a)

EPA Fuel Economy mpg (City/Hwy)

14/23

Assembly Plant

Saltillo Engine Plant, Saltillo, Mexico

(a) Meets Federal Tier 2 Bin 5 emission requirements and ULEV II requirements in California, Massachusetts, New York, Maine, Vermont,

Connecticut, Pennsylvania, Rhode Island, New Jersey, Oregon and Washington.

2/ 300 SRT8® SPECIFICATIONS http://media.chrysler.com

300 SRT8®

SPECIFICATIONS

TRANSMISSION: W5A580 FIVE-SPEED AUTOMATIC

Availability

Standard

Description

Adaptive electronic control or Auto Stick driver-interactive manual

control and electronically modulated torque converter clutch

Gear Ratios

1st

3.59

2nd

2.19

3rd

1.41

4th

1.00

5th

0.83

Reverse

3.16

Final Drive Ratio

3.06 – Getrag limited-slip differential

Overall Top Gear

2.54

ELECTRICAL SYSTEM

Alternator

220-amp

Battery

H7 case, 730 CCA, maintenance free

DIMENSIONS AND CAPACITIES(b)

Wheelbase

120.2 (3,052)

Track, Front

63.4 (1,610.93)

Track, Rear

63.1 (1,604)

Overall Length

200.33 (5,088.4)

Overall Width

74.24 (1,885.8)

Overall Height

58.26 (1,479.76)

Frontal Area

26.2 ft²

Ground Clearance (Minimum)

4.37 (111.2) – Front

Drag Coefficient (Cd)

0.334

Curb Weight, lb. (kg)

4,365 (1,979.7)

Weight Distribution, percent F/R

54/46

Fuel Tank Capacity, gal. (L)

19.1 (72.2)

(b) All dimensions measured at curb weight with standard tires.

3/ 300 SRT8® SPECIFICATIONS http://media.chrysler.com

300 SRT8®

SPECIFICATIONS

ACCOMMODATIONS

Seating Capacity, F/R

2/3

Front

Head room

38.6 (981)

36.9 (938.4) with dual-pane sunroof

Legroom

41.8 (1,061)

Shoulder room

59.5 (1,510)

Hip room

56.2 (1,428)

Seat travel

Driver — 10.6 (270)

Passenger — 8.66 (220)

Recliner angle range, deg.

Power — 70.7

Manual — 70

EPA front row interior volume, cu. ft. (cu. m.)

55.6 (1.573)

Rear Seat

Head room

37.9 (963)

36.9 (937) with dual-pane sunroof

Legroom

40.1 (1,019)

Knee clearance

3.9 (99)

Shoulder room

57.7 (1,465)

Hip room

56.1 (142)

EPA second row interior volume, cu. ft. (cu. m.)

50.7 (1.4)

Total Interior Volume, cu. ft. (cu. m.)

106.3 (3.0)

EPA Luggage Compartment Volume, cu. ft. (cu. m)

16.3 (0.5)

EPA Interior Volume Index, cu. ft. (cu. m)

122.6 (3.5)

Trunk Liftover Height

30.1 (768.9)

BODY

Layout

Longitudinal front engine, RWD

Construction

Unitized steel body and aluminum hood

EXHAUST

Type

Dual 2.75-in. active exhaust with dual 4-in. round tips

SUSPENSION

Type

SRT tuned adaptive damping

Front

Independent SLA with high upper “A” arm, coil spring over ADS

Bilstein shock absorber, 30 mm. stabilizer bar, lateral and

diagonal lower links

Rear

Five-link independent with coil spring, ADS Bilstein shock

absorber and isolated suspension cradle, link type 18 mm.

stabilizer bar

4/ 300 SRT8® SPECIFICATIONS http://media.chrysler.com

300 SRT8®

SPECIFICATIONS

STEERING

Type

SRT tuned rack and pinion with hydraulic power assist

Overall Ratio

14.4:1

Steering Turns (lock-to-lock)

2.75

TIRES

Front and Rear

Standard on 300 SRT8

Size and type

245/45R20 All-season

Mfr. and model

Goodyear Eagle RS-A 2

Revs per mile, (km)

731 (456)

Front and Rear

Optional on 300 SRT8

Size and type

245/45R20 Three-season

Mfr. and model

Goodyear F1 Supercar

Revs per mile, (km)

726 (450)

WHEELS

Availability

Standard on 300 SRT8

Type and material

Full forged aluminum, (Optional black chrome finish)

Size

20 x 9.0

BRAKES

Front

Rotor size and type

14.2 x 1.26 (360 x 32) vented and slotted

Caliper size and type

1.73 (44) Brembo four-piston fixed with aluminum housing

Swept area, sq. in. (sq. cm.)

351 (2,261)

Rear

Rotor size and type

13.8 x 1.10 (350 x 28) vented and slotted

Caliper size and type

1.26 (32) Brembo four-piston fixed with aluminum housing

Swept area, sq. in. (sq. cm.)

316 (2,036)

• • •
