QUICK START

GUIDE

—

HD TERMINAL

4642

HD PERSONAL VIDEO

RECORDER 8642

ILLICO

DIGITAL TV

POWERSELECT

VOL+VOL-

CH+

CH-

SETTINGSEXITINFOGUIDE

Explorer 4642HD

91132145678 10

HD terminal 4642

1 VOL +, VOL - Increases and decreases the volume

2 CH+, CH - Scrolls up and down through the channels

3 Select Provides access to your on-screen selection

4 Display Displays the selected channel number and time of day. The display shows the following:

 •Record() •Auto •1080i/1080P •MoCALink()

 •Power() •Message() •720i/720P 

 •5.1 •HDTV •480i/480P 

5 Guide

Provides access to on-screen services, such as the on-screen guide

6 Info Displays a description of the selected program. This button is available from the on-screen

guide and while viewing a program

7 Exit Exits menus, the on-screen guide, and program information

8 Settings Provides access to the Settings menu

9 IR Sensor Receivestheinfraredsignalfromtheremotecontrol

10 USB Port Connects to external USB equipment (reservedforfutureuse)

11 Power Turns the set-top box on and off

MCARD SN: PXCPRPSLV

MCARD MAC: 00 1BD73E17D9

MULTI-STREAM CABLE CARD

THIS DEVICE IS INTENDED TO BE ATTACHED TO A RECEIVER THAT

IS NOT USED TO RECEIVE OVER-THE-AIR-BROADCAST SIGNALS.

CONNECTION OF THIS DEVICE IN ANY OTHER FASHION MAY CAUSE

HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS AND IS IN

VIOLATION OF THE FCC RULES, PART 15.

120V~

60Hz 50W

120 V ~

60Hz 3A

CATV CONVERTER

MADE IN MEXICO

LISTED 36MW

VIDEO PRODUCT

CAUTION

RISK OFELECTRIC SHOCK

DO NOT OPEN

AVIS:

RISQUE DE CHOC ÉLECTRIQUE NE PAS OUVRIR

ETHERNET

USB

1394

eCM MAC: 01CEA05D679

STB SN: SABPQTMNWW

CABLE

OUT

CABLE

S-VIDEO

OUT

OPTICAL

AUDIO OUT

L R

Y Pb Pr

L R

DIGITAL

AUDIO

OUT

L AUDIO IN R VIDEO IN

POWER SELECT

VOL+VOL-

CH+

CH-

LISTEXITINFOGUIDE

Explorer 8642HD

1 5 6

3 127 8 9 10 11

HD PERSONAL VIDEO recorder 8642

1 Power Turns the set-top box on and off

2 VOL +, VOL - Decreases and increases the volume

3 USB 2.0

ConnectstoexternalUSBequipmentapprovedbyyourserviceprovider(reservedforfutureuse).

4 CH+, CH - Scrolls up and down through the channels

5 Select Provides access to your on-screen selection

6 IR Sensor Receivestheinfraredsignalfromtheremotecontrol

7 Guide

Provides access to on-screen services, such as the on-screen guide

8 Info Displays a description of the selected program. This button is available from the on-screen

menu and while viewing a program

9 Exit Exit menus, the on-screen menu, and program information

10 List Displays the recorded list

11 Display Displays the selected channel number and time of day. The display shows the following:

 •Power() •MoCALink() •1080i/1080P •5.1

 •Message() •HDTV •720i/720P

 •Record() •Auto •480i/480P

12 Smart Card Allowssmartcardaccess(reservedforfutureuse)

MCARD SN: PXCPRPSLV

MCARD MAC: 00 1BD73E17D9

MULTI-STREAM CABLE CARD

CATV CONVERTER

MADE IN MEXICO

LISTED 14H1

VIDEO PRODUCT

AVIS: RISQUE DE CHOC ÉLECTRIQUE

NE PAS OUVRIR

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

S-VIDEO

OUT

OPTICAL

AUDIO

OUT

DIGITAL

AUDIO

OUTPUT

R Pr R

L Pb L

YVIDEO

CABLE IN

120V~

60Hz 80W

120 VAC

60Hz 4.2A

500W

CABLE OUT

USB 2.0 eSATA

THIS DEVICE IS INTENDED TO BE ATTACHED

TO A RECEIVER THAT IS NOT USED TO

RECEIVE OVER-THE-AIR BROADCAST

SIGNALS. CONNECTION OF THIS DEVICE

IN ANY OTHER FASHION MAY CAUSE

HARMFUL INTERFERENCE TO RADIO

COMMUNICATIONS AND IS IN VIOLATION

OF THE FCC RULES, PART 15.

SCIENTIFIC-ATLANTA, INC.

eCM MAC: 001AC3F4F757

STB RF MAC: 001AC3F$F756

STB SN: SABPQBQGD

ETHERNET1394

HD TERMINAL OR HD PERSONAL VIDEO RECORDER + HD TV

This connection will allow you to:

A. Watchthechannelorserviceofyourchoice(inHD,whenavailable);

B. Recordprogramsontheharddrivewhiletheyareplaying,allowingtheuseoftheLiveTVcontrolfunctions

(inHD,whenavailable);

C. Watchaprogrampreviouslyrecordedontheharddrive(inHD,whenavailable);

D. Recordontheharddrivefromonechannelwhilewatchinganotherchannel(inHD,whenavailable);

E. Recordontheharddrivefromtwodifferentchannelswhilewatchingathird,previously

 recordedprogram(inHD,whenavailable);

F. ProgramyourPVRtorecordoneprogramortwoprogramssimultaneouslyinyourabsence

 (inHD,whenavailable).

Notes :

• Thebestpossibleconnectionwiththecablessuppliedisillustratedbythesolidlines.Thedottedlines

represent viable options, however.

•

Althoughtherearoftheterminaldependsonthemodel(socketsindifferentpositions),theconnection

is done in the same way.

•

You should turn the terminal volume all the way up and adjust the volume on the TV to your taste.

For explanations, see the “Volume adjustment” section of the User Guide.

CONNECTION

HD TERMINAL

or HD PVR

HD TV

Wall-mounted

cable outlet

Remote CONTROL RT-U63P-15

Notes :

 TheremotecontrolrequirestwoalkalineAAbatteries.Adiagraminsidethecompartementofthe

remotecontroleindicatesproperbatteryplacement.Replaceasneeded,whentheindicatorlight

becomes dim or no longer illuminates.

For more information on how to program your remote control, see the Programming And Operating Instructions

that came with your terminal.

CUSTOMER SERVICE

For more information, please consult the User guide or call the Customer Service Center. Our

agentsareavailablebetween10a.m.and9:30p.m.MondaythroughFriday,between8a.m.and

6p.m.onSaturdayandbetween9a.mand5:30p.m.onSunday.

  Montréal514-281-1711

  Québec418-847-4410

  Saguenay418-545-1114

  Outaouais819-771-7715

  ElsewhereinQuebec1-88-VIDEOTRON

TECHNICAL SUPPORT

For problems of a technical nature, please contact Technical Support. Our technicians

areavailable24hoursaday,sevendaysaweek.

  Montréal514-841-2611

  Québec418-842-2611

  Saguenay418-543-4611

  Outaouais819-771-2611

  ElsewhereinQuebec1-88-VIDEOTRON

Visit our Web site: videotron.com

Notes

CUSTOMER SERVICE

ILL-GRA-HD-001-1010
