CHAPTER

3-1

Cisco PIX Security Appliance Hardware Installation Guide

78-15170-02

PIX 506/506E

This chapter describes how to install a PIX 506/506E, and includes the following sections:

•PIX 506/506E Product Overview, page 3-1

•Installing the PIX 506/506E, page 3-3

•Connecting a Power Supply Module to the PIX 506/506E, page 3-4

•Removing and Replacing the PIX 506/506E Chassis Cover, page 3-6

•Replacing a Lithium Battery, page 3-7

Note The PIX 506 and the PIX 506E are the same except the PIX 506E has a faster processor and a different

power supply.

PIX 506/506E Product Overview

This section describes the PIX 506/506E front and rear panels and the panel LEDs.

Figure 3-1 shows the front view of the PIX 506/506E.

Figure 3-1 PIX 506/506E Front Panel

67945

POWER

ACT NETWORK

CISCO PIX 506E

FIREWALL

3-2

Cisco PIX Security Appliance Hardware Installation Guide

78-15170-02

Chapter 3 PIX 506/506E

PIX 506/506E Product Overview

Figure 3-2 shows the rear view of the PIX 506/506E.

Figure 3-2 PIX 506/506E Rear Panel

Figure 3-3 shows the PIX 506/506E front panel LEDs.

Figure 3-3 PIX 506/506E Front Panel LEDs

Table 3-1 lists the states of the PIX 506/506E front panel LEDs.

67947

CONSOLE

ETHERNET 0

ACT LINK LINK

POWER

INPUT

ACT

USB

ETHERNET 1

POWER ACT NETWORK

25735

Table 3-1 PIX 506/506E Front Panel LEDs

LED Color State Description

POWER Green On The unit has power.

ACT Green Flashing Active indicator—On when the software image has been

loaded on the security appliance.

NETWORK Green Flashing On when at least one network interface is passing traffic.

3-3

Cisco PIX Security Appliance Hardware Installation Guide

78-15170-02

Chapter 3 PIX 506/506E

Installing the PIX 506/506E

Figure 3-4 shows the PIX 506/506E rear panel LEDs.

Figure 3-4 PIX 506/506E Rear Panel LEDs

Table 3-2 lists the states of the PIX 506/506E rear panel LEDs.

The USB port at the left of the Console port is not used.

Installing the PIX 506/506E

Place the PIX 506/506E on a flat, stable surface. The PIX 506/506E is not rack mountable.

To install the PIX 506/506E, perform the following steps:

Step 1 Connect the cable so that you have either a DB-9 or DB-25 connector on one end as required by the serial

port for your computer, and the other end is the RJ-45 connector.

Note Use the RJ-45 Console port to connect a computer to enter configuration commands. Locate the

serial cable from the accessory kit. The serial cable assembly consists of a null modem cable

with RJ-45 connectors, and one DB-9 connector and one DB-25 connector.

CONSOLE

ETHERNET 0

ACT LINK LINK

POWER

INPUT

ACT

USB

ETHERNET 1

38852

10BaseT

(RJ-45)

10BaseT

(RJ-45)

Console

port (RJ-45)

USB

port

Power switch

LINK

LED

LINK

LED

ACT(ivity)

LED

ACT(ivity)

LED

Table 3-2 PIX 506/506E Rear Panel LEDs

LED Color State Description

ACT Green On Shows network activity.

LINK Green On Shows that data is passing on the network to which the

connector is attached.

3-4

Cisco PIX Security Appliance Hardware Installation Guide

78-15170-02

Chapter 3 PIX 506/506E

Connecting a Power Supply Module to the PIX 506/506E

Step 2 Connect the RJ-45 connector to the PIX 506/506E and connect the other end to the serial port connector

on your computer (see Figure 3-7).

Figure 3-5 PIX 506/506E Serial Console Cable

Step 3 Connect the inside network cable to the interface connector marked ETHERNET 0 or ETHERNET 1.

Note The inside or outside network connections can be made to either interface port on the

PIX 506/506E.

Step 4 Connect the outside network cable to the remaining Ethernet port.

Connecting a Power Supply Module to the PIX 506/506E

This section describes how to connect the power supply module to the PIX 506/506E. Use this

information in conjunction with the Regulatory Compliance and Safety Information document.

The PIX 506/506E uses an external AC to DC power supply. Power is supplied to the PIX 506/506E by

connecting the power supply to the back of the security appliance and connecting a separate AC power

cord to the power supply.

CONSOLE

ETHERNET 0

ACT LINK LINK

POWER

INPUT

ACT

USB

ETHERNET 1

38853

Console

port (RJ-45)

RJ-45 to

DB-9 or DB-25

serial cable

(null-modem)

Computer serial port

DB-9 or DB-25

3-5

Cisco PIX Security Appliance Hardware Installation Guide

78-15170-02

Chapter 3 PIX 506/506E

Connecting a Power Supply Module to the PIX 506/506E

Figure 3-6 displays the cable connection from the power supply to the PIX 506, and displays the AC

power cord connector (at the opposite end of the power supply).

Figure 3-6 Connecting the Power Supply Module to the PIX 506 6-Pin Connector

Figure 3-7 displays the cable connection from the power supply to the PIX 506E, and displays the AC

power cord connector (at the opposite end of the power supply).

Figure 3-7 Connecting the Power Supply Module to the PIX 506E 8-Pin Connector

Complete these steps to connect the power supply module:

Step 1 Place the PIX 506/506E on a flat, stable surface. The PIX 506/506E is not rack mountable.

Step 2 Connect the power supply to the back of the PIX 506/506E. See Figure 3-6 for the PIX 506 and

Figure 3-7 for the PIX 506E.

Step 3 When you are ready to start the PIX 506/506E, power on the unit from the switch at the rear of the unit.

CONSOLE

ETHERNET 0

ACT LINK LINK

POWER

INPUT

ACT

USB

ETHERNET 1

38854

Power supply

CONSOLE

ETHERNET 0

ACT LINK LINK

POWER

INPUT

ACT

USB

ETHERNET 1

67847

Power supply

3-6

Cisco PIX Security Appliance Hardware Installation Guide

78-15170-02

Chapter 3 PIX 506/506E

Removing and Replacing the PIX 506/506E Chassis Cover

This section describes how to remove and replace the chassis cover from the PIX 506/506E. This section

includes the following topics:

•Removing the Chassis Cover, page 3-6

•Replacing the Chassis Cover, page 3-7

Removing the Chassis Cover

Complete the following to remove the chassis cover:

Note Removing the chassis cover does not affect your Cisco warranty. Upgrading the PIX security appliance

does not require any special tools and does not create any radio frequency leaks.

Step 1 Read the Regulatory Compliance and Safety Information document.

Step 2 Power off the security appliance and unplug the power cord.

Warning

Before working on a system that has an On/Off switch, turn OFF the power and unplug the power cord.

Step 3 Disconnect the network interface cables.

Step 4 Remove the two screws from the back of the chassis (see Figure 3-8).

Figure 3-8 Removing PIX 506/506E Chassis Cover Screws

Step 5 With the rear panel facing you, slide the chassis cover back and then lift it up off the bottom section, as

shown in Figure 3-8.

119681

CONSOLE

ETHERNET 0

ACTLINKLINK

POWER

INPUT

ACT

USB

ETHERNET 1

3-7

Cisco PIX Security Appliance Hardware Installation Guide

78-15170-02

Chapter 3 PIX 506/506E

Replacing a Lithium Battery

Replacing the Chassis Cover

Caution Do not operate PIX security appliances without the chassis cover installed. The chassis cover protects

the internal components, prevents electrical shorts, and provides proper air-flow for cooling the

electronic components.

Complete the following to replace the chassis cover:

Step 1 Place the chassis on a secure surface with the front panel facing you.

Step 2 Hold the chassis cover so the tabs at the rear of the cover are aligned with the bottom of the chassis.

Step 3 Lower the front of the cover onto the chassis, making sure that the side tabs of the cover fit under the

side panels of the chassis.

Step 4 Slide the chassis cover toward the front, making sure that the cover tabs fit under the back panel, and the

back panel tabs fit under the chassis cover.

Step 5 Secure the chassis cover with the screws you set aside earlier.

Step 6 Reconnect the network interface cables.

Step 7 Place the PIX 506/506E on a flat, stable surface. The PIX 506/506E is not rack mountable.

Step 8 Reconnect the power cord and power on the security appliance.

Replacing a Lithium Battery

The PIX 506/506E has a lithium battery on its main circuit board (see Figure 3-9). This battery has an

operating life of about ten years. When the battery loses its charge, the PIX security appliance cannot

function. The battery is a field-replaceable unit (FRU). You can use a standard 3V lithium battery to

replace the used battery.

3-8

Cisco PIX Security Appliance Hardware Installation Guide

78-15170-02

Chapter 3 PIX 506/506E

Replacing a Lithium Battery

Figure 3-9 PIX 506/506E Lithium Battery Location

Warning

Danger of explosion exists if the lithium battery is incorrectly replaced. Replace only with the same

or equivalent type recommended by the manufacturer. Dispose of used batteries according to the

manufacturer's instructions.

To replace the lithium battery, perform the following steps:

Step 1 Remove the chassis cover as described in the “Removing the Chassis Cover” section on page 3-6.

Step 2 Use a flathead screwdriver to slide the battery out of the metal clip on the circuit board (see Figure 3-9).

Step 3 Place the used battery aside and replace it with a new battery. Install the new battery writing side up.

Step 4 The battery snaps into place as you slide it into the battery slot.

Step 5 Replace the chassis cover by lining up the cover tabs with the bottom panel tabs, and sliding the chassis

cover back into the side and front panel slots on the chassis.

Step 6 Replace the chassis cover as described in the “Replacing the Chassis Cover” section on page 3-7.

119680

Battery

Front
