Cisco SPA 508 Series Manuale utente

Cisco SPA 508 Series IP Phone

How to Use Cisco SPA 508

Features

Description

Handset

Pick up to place or answer a call.

Message Waiting Indicator

Displays solid red when you have a new voice mail

message. Flashes red during an incoming call.

LCD Screen

Displays date and time, phone station name, line

extensions, and soft-key options.

Line keys

Indicates phone line status. When lit:

Green: Line is idle.

Red (steady): Line is active or in use.

Red (blinking): Line is on hold.

Orange: Line is unregistered and cannot be used.

Soft-key buttons

Press a soft-key button to perform the action shown

gTalk® PBX

USER GUIDE

on the label on the LCD screen above.

Navigation button

Press an arrow to scroll left, right, up, or down through

items shown on the LCD screen.

Messages button

Press to access voice mail.

Hold button

Press to place a call on hold.

Setup button

Press to access a menu to configure features and

preferences (such as your directory and speed dials),

access your call history, and set up functions (such as

call forwarding).

10.

Mute button

Press to mute or unmute the phone. When phone is

muted, the button glows red. A flashing mute button

indicates the network connection cannot be found.

11.

Headset button

Push to turn the headset on or off. When the headset

is on, the button glows green.

12.

Volume button

Press + to increase the volume and - to lower the

volume of the handset, headset, speaker (when the

handset is off the phone), or ringer volume (when the

handset is on the phone).

13.

Speaker button

Push to turn the speaker on or off. When the speaker

is on, the button glows green.

14.

Keypad

Use to dial outbound calls, enter letters, and choose

menu items.

Placing or Answering a Call

Basic techniques to answer a call:

• Pick up the handset.

• Press the Speaker button.

• Press the Headset button.

• Press a green line button to place a call or a red flashing line button to answer a call.

Techniques to place a call without dialing a number:

• Press the ‘redial’soft-key, then move up or down by soft-key to reach and ‘dial’the last number.

Placing Internal (extension) Calls

Basic techniques to call extension:

• Dial the extension number using keypad then pick up the handset.

• Dial the extension number using keypad then press the Speaker button.

Placing Outbound Calls

You can make outbound calls by simply dialing the destination telephone number. For those who have a

10 digit US/Canada number in addition to 4 digit extension number their selection (pressing) of ‘green’

line button next to the extension number will display company’s business telephone number to the call

recipient. On the other hand selection (pressing) of ‘green’ line button next to the 10 digit number will

display that number to the call recipient

Ending a Call

To end a call:

• If you are using the handset, just hang up.

• If you are using the speakerphone, press the Speaker button.

• If you are using a headset, either press the Headset button (wired) or replace the receiver (when using

certain wireless models).

Ignoring an Incoming Call:

• When call lands press ‘Ignore’soft-key button.

Transferring a Call

You can perform following types of transfers:

Performing an Attended Transfer

• Attended Transfer:

- transfer the call while the phone is ringing.

- wait for the person to answer before transferring the call.

STEP 1 - During an active call, press ‘xfer’soft-key. The call is placed on hold and a new line is opened to

dial the number where the call in intended to be transferred.

STEP 2 Either:

• Enter the number to which you want to transfer the call, then press the ‘dial’soft-key or wait a few

seconds.

• Press the ‘dir’ soft-key and either choose a number from the personal directory or select the

Corporate Directory, then press the ‘dial’soft-key.

STEP 3 - Press the ‘xfer’ soft-key after the phone begins to ring, or at any time after the phone is

answered.

Performing an Unattended (Blind) Transfer

• Blind Transfer—You transfer the call without speaking to the other party to which you are transferring

the call.

STEP 1- During an active call, press the ‘bXfer’ soft-key.

STEP 2- Enter the number to which you want to transfer the call and press the ‘dial’ soft-key. The call is

transferred with no further action required on your part.

Redialing a Number

To redial the last number called, press the ‘redial’soft-key and then ‘dial’ soft-key.

To redial another number press the ‘redial’soft-key, then navigate to the desired number and then

press the ‘dial’ soft-key.

Viewing and Returning Missed Calls

The LCD screen on your IP phone will notify you if a call came but was unanswered.

To return a missed call:

• If the LCD screen shows a missed call, press the ‘lcr’soft-key to return the last missed call. Press the

‘miss’soft-key to view a list of missed calls, select a call, and press ‘dial’.

• If the LCD screen does not show the ‘lcr’or ‘miss’soft-keys, you can return a call from the Missed Call

list:

STEP 1- Press the Setup button.

STEP 2- Scroll to Call History and press the ‘select’soft-key.

STEP 3- Scroll to Missed Calls and press the ‘select’soft-key.

STEP 4- Choose the call you want to return and press the ‘dial’soft-key.

Placing a Three-Way Conference Call

To initiate a conference call:

STEP 1 - During an active call, press the ‘conf’soft-key. The first call is placed on hold, a second line is

opened, and you hear a dial tone.

STEP 2 - Dial the second person’s telephone number.

STEP 3 - When the second person answers, press the ‘conf’soft-key again. All three parties are

connected in the conference call. (You can cancel the conference by pressing the ‘EndCall‘soft-key

before connecting the calls, then press the ‘resume’soft-key to resume the original call.) NOTE When

you hang up, the other two parties are disconnected too.

Setting Do Not Disturb

Use the Do Not Disturb feature to prevent incoming calls ringing your phone. The screen indicates that a

call is incoming, but the phone does not ring. The unanswered call is handled according to your normal

settings.

• To activate Do Not Disturb feature, press the ‘dnd’soft-key. The LCD screen indicates that Do Not

Disturb is turned on for your phone.

• To deactivate Do Not Disturb, press the ‘-dnd’soft-key.

Accessing Voice mail

To access voice mail, press the Messages button on your phone. Your phone administrator should

configure your phone with the correct voice mail number so that pressing the Messages button

automatically dials your voice mail system.

• To hear the voice mail press 1.

• To hear the old voice mail press 2.

• To delete voice mail press 3.

Transfer to Voice mail

This feature allows you to transfer someone (either a caller or a called person) to leave a voice mail to a

specific extension.

• To transfer to specific extension to leave voice mail: Press ‘Xfer’soft-key button, then dial *6<ext.

number>, and after that immediately press the ‘Xfer’soft-key button again.

• To leave a voice mail to a specific extension: Dial *6<ext. number>.

Call Forward

Activating Call Forwarding: Activate Call Forwarding feature whenever you want your calls to be

forwarded to another phone. Once activated, all incoming calls will be forwarded to the number you

specified.

• Dial *41 + Number + # - To forward incoming calls to a specific telephone number for any reason.

• Dial *42 + Number + # - To forward incoming calls to a specific telephone number when unreachable.

• Dial *43 + Number + # - To forward incoming calls to a specific telephone number after Ring-Timeout.

Deactivating Call Forwarding:

• Dial *44# - To cancel call Forwarding .

How to Install gTalk PBX Mobile App

With every Extension gTalk PBX offers a feature rich App compatible with Android and iPhone sets.

To install gTalk PBX App for Android sets, download the App on your smart phone by browsing

the Google Play Store. Search for gTalk PBX, and then press Install. Once installed enter user ID

and password to login gTalk PBX App.

To install gTalk PBX App for iPhone sets download the App on your smart phone by visiting the

Apple Store, search for gTalk PBX, and then press Install. Once installed enter user ID and

password to login gTalk PBX App.

Use of gTalk PBX Mobile App

Use of the gTalk mobile App is user friendly and intuitive.

Most of the functions of your gTalk IP Phone sets may be

performed by using gTalk Mobile App. Some of the

important functions are: Make or receive calls, check

voice mail or missed calls, set call receive preferences,

line preference, see extension directory and make direct

calls, make call using speed dial etc.
