QUICK INSTALLATION GUIDE

Wireless-N Ethernet Bridge

with Dual-Band

Model: WET610N

Package Contents

Wireless-N Ethernet Bridge with Dual-Band•

Setup Software and User Guide on CD-ROM•

Quick Installation Guide•

Network Cable•

Power Adapter•

InstallationWET610N

3Wireless-N Ethernet Bridge with Dual-Band

Installation

A. Insert the Setup Wizard CD into

your CD-ROM drive.

NOTE: Windows or other

personal firewalls may

ask for permission to run

the software. To continue,

allow the software to run.

B. The Welcome screen appears.

Click Next.

C. Read the License Agreement.

To accept the terms in the

License Agreement, select I

accept this agreement.

Click Next.

D. For configuration, you will

temporarily connect the

Bridge to your router. (After

configuration, you will connect

the Bridge to the device

that you want to equip with

wireless.)

Click Next.

Insert the CD-ROM

Installation WET610N

4 Wireless-N Ethernet Bridge with Dual-Band

E. Connect one end of the

included network cable to the

Ethernet port of the Bridge.

Click Next.

F. Connect the other end of

the cable to one of the local

network ports on your router.

Click Next.

G. Connect the included power

adapter to the Power port of the

Bridge.

Click Next.

H. Plug the power cord into an

electrical outlet.

Click Next.

InstallationWET610N

5Wireless-N Ethernet Bridge with Dual-Band

I. Wait until the Power and

Ethernet LEDs are solidly lit.

Click Next.

J. Enter a password to protect

access to the Bridge.

Click Next.

K. The wireless setup is next.

Click Next.

L. The Setup Wizard displays

the Network Name of the

wireless network with the

strongest signal. To connect to

this network, click Next. Then

proceed to step P.

To connect to a different

network, select I don’t want to

connect to this network, and

click Next.

Installation WET610N

6 Wireless-N Ethernet Bridge with Dual-Band

M. The available networks are

listed in the table. Select your

network, and then click Next.

(If your router supports Wi-Fi

Protected Setup, which is

indicated by the icon next

to the network name, then

proceed to the section, “Wi-Fi

Protected Setup”.)

If your network is not listed, select My network is not in this list, and

click Next. Proceed to step O.

N. If your network does not use

wireless security, proceed to

step P.

If your network uses wireless

security, enter the security key

of your wireless network. Click

Next. Then proceed to step P.

O. Configure the following:

Wireless Network Name

(SSID) Enter the name of your

wireless network.

Authentication Type Select

the authentication used by your

wireless network.

Encryption Type Select

the encryption used by your

wireless network.

Security Key Enter the security key of your wireless network.

Click Next.

NOTE: If you are connecting to your own wireless network, you

may want to configure wireless security on your router if you

have not already done so.

InstallationWET610N

7Wireless-N Ethernet Bridge with Dual-Band

Please wait while the Setup Wizard connects the Bridge to your wirelessP.

network. Warnings from your firewall or security application may

appear. If necessary, click Always allow or Allow this time only to

allow the wireless connection.

Q. You will connect the Bridge

to the device that you want to

equip with wireless.

Click Next.

R. The Bridge is connected to your

router with a network cable.

Disconnect this network cable

from your router.

If you need to move the device

that you want to equip with

wireless, then do so now. Click

Next.

S. Connect the free end of the

network cable to the device that

you want to equip with wireless.

If you need to move the Bridge,

then make sure you take the

power adapter and network

cable with you.

Click Next.

Installation WET610N

8 Wireless-N Ethernet Bridge with Dual-Band

T. Wait until the Power and

Ethernet LEDs are solidly lit, and

the Wireless LED is flashing.

Click Next.

U. The wireless settings are

displayed.

To save the settings in a text

file on your desktop, keep the

default, Save these settings in

a text file on my desktop.

Click Next.

V. The Bridge is installed. You can

move the Bridge anywhere

within your wireless network’s

range, as long as you plug its

power cord into an electrical

outlet.

Refer to the User Guide on the

CD-ROM for information about

advanced settings.

Congratulations! Setup is complete.

Wi-Fi Protected SetupWET610N

9Wireless-N Ethernet Bridge with Dual-Band

Wi-Fi Protected Setup

A. Use Wi-Fi Protected Setup to

create a wireless connection

between the Bridge and your

router. On your router, press the

button that looks like one of the

icons in the picture. You may

have to hold down this button

until an LED flashes.

Within two minutes, click

Connect on the Quickly Connect

Using Push Button screen.

Please wait while the Setup Wizard connects the Bridge to your wirelessB.

network. Warnings from your firewall or security application may

appear. If necessary, click Always allow or Allow this time only to

allow the wireless connection.

C. You will connect the Bridge

to the device that you want to

equip with wireless.

Click Next.

D. The Bridge is connected to your

router with a network cable.

Disconnect this network cable

from your router.

If you need to move the device

that you want to equip with

wireless, then do so now. Click

Next.

Wi-Fi Protected Setup Button on Router

Wi-Fi Protected Setup WET610N

10 Wireless-N Ethernet Bridge with Dual-Band

E. Connect the free end of the

network cable to the device that

you want to equip with wireless.

If you need to move the Bridge,

then make sure you take the

power adapter and network

cable with you.

Click Next.

F. Wait until the Power and

Ethernet LEDs are solidly lit, and

the Wireless LED is flashing.

Click Next.

G. The wireless settings are

displayed.

To save the settings in a text

file on your desktop, keep the

default, Save these settings in

a text file on my desktop.

Click Next.

H. The Bridge is installed. You can

move the Bridge anywhere

within your wireless network’s

range, as long as you plug its

power cord into an electrical

outlet.

Refer to the User Guide on the

CD-ROM for information about

advanced settings.

Congratulations! Setup is complete.
