Cisco PTZ Manuale utente

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

Cisco Video Surveillance PTZ IP Camera

Installation Guide

Text Part Number: OL-28954-01

NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED

WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.

THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT

SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE

OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.

The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public

NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH

ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT

LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF

DEALING, USAGE, OR TRADE PRACTICE.

IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING,

WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO

OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be found at

www.cisco.com/go/trademarks. Third party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership

relationship between Cisco and any other company. (1005R)

Cisco Video Surveillance PTZ IP Camera Installation Guide

iii

Cisco Video Surveillance PTZ IP Camera Installation Guide

OL-28954-01

CONTENTS

Preface v

Overview v

Organization v

Obtaining Documentation, Obtaining Support, and Security Guidelines v

CHAPTER

1Overview 1-1

Introduction 1-1

Package Contents 1-2

PTZ IP Camera Physical Details 1-3

Status LEDs 1-4

CHAPTER

2Installing the Camera 2-1

Installation Guidelines 2-1

Warnings Before Installation 2-2

Installing the PTZ IP Camera 2-3

Cabling Through Waterproof Connectors 2-4

Connecting the Cables 2-5

Preparing the Camera 2-6

Mounting to the Wall 2-7

Connecting to the Mount Bracket 2-7

Mounting the PTZ Camera 2-8

Mounting to the Ceiling 2-9

Connecting to the Pendant Pipe 2-9

Connecting to the Network 2-12

CHAPTER

3Performing the Initial Setup of the IP Camera 3-1

CHAPTER

4Managing the Camera 4-1

Understanding the PTZ IP Camera User Interface 4-1

PTZ IP Camera Window Links 4-1

PTZ IP Camera Windows 4-2

Powering the PTZ IP Camera On or Off 4-3

Resetting the PTZ IP Camera 4-3

Contents

Cisco Video Surveillance PTZ IP Camera Installation Guide

OL-28954-01

Viewing Live Video 4-4

Camera Settings 4-6

Motion Detection Settings 4-9

Pan/Tilt/Zoom Settings 4-10

Privacy Zone 4-12

NDEX

Cisco Video Surveillance PTZ IP Camera Installation Guide

OL-28954-01

Preface

Overview

This document, Cisco Video Surveillance PTZ IP Camera Installation Guide, provides information

about installing and deploying the following Cisco Video Surveillance PTZ IP cameras:

• Cisco Video Surveillance SD Outdoor 2830 PTZ IP Camera, NTSC

• Cisco Video Surveillance SD Outdoor 2835 PTZ IP Camera, PAL

• Cisco Video Surveillance HD Outdoor 6930 PTZ IP Camera

Organization

This manual is organized as follows:

Obtaining Documentation, Obtaining Support, and Security

Guidelines

For information about obtaining documentation, submitting a service request, and gathering additional

information, see the monthly What’s New in Cisco Product Documentation, which also lists all new and

revised Cisco technical documentation, at:

http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html

Subscribe to the What’s New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed

and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free

service and Cisco currently supports RSS version 2.0.

Chapter 1, “Overview” Provides an overview of the IP camera and its features.

Chapter 2, “Installing the Camera” Provides instructions for physically installing the IP camera.

Chapter 3, “Performing the Initial

Setup of the IP Camera”

Provides instructions for performing the initial network setup of

the IP camera.

Chapter 4, “Managing the Camera” Provides instructions for accessing and understanding the

IP camera user interface, adjusting its focus and, powering the IP

camera on and off, and resetting the IP camera.

Cisco Video Surveillance PTZ IP Camera Installation Guide

OL-28954-01

Preface

CHAPTER

1-1

Cisco Video Surveillance PTZ IP Camera Installation Guide

OL-28954-01

Overview

This chapter describes the Cisco Video Surveillance pan, tilt, and zoom (PTZ) IP cameras, and includes

the following topics:

• Introduction, page 1-1

• Package Contents, page 1-2

• PTZ IP Camera Physical Details, page 1-3

Introduction

The Cisco Video Surveillance PTZ IP cameras are primarily used for monitoring wide open outdoor

areas such as building entrances, airports, highways, and parking lots.

The dome cover protects the camera body against rain and dust. The wide temperature range allows the

camera to operate under extreme weather conditions.

The following PTZ IP cameras are available:

• Cisco Video Surveillance SD Outdoor 2830 PTZ IP Camera, NTSC

• Cisco Video Surveillance SD Outdoor 2835 PTZ IP Camera, PAL

• Cisco Video Surveillance HD Outdoor 6930 PTZ IP Camera

For installers, properly adjusting the focus of an HD IP camera can be difficult due to the image detail.

To make installation and adjustment easier, the PTZ IP camera incorporates built-in stepping motors that

the installer can use to remotely control the focal length and precisely adjust the camera focus.

For complete installation and tampering prevention, the PTZ IP camera also fits different conduits and

corrugated tubes sizes for cable installation.

1-2

Cisco Video Surveillance PTZ IP Camera Installation Guide

OL-28954-01

Chapter 1 Overview

Package Contents

The Cisco Video Surveillance PTZ IP camera package includes the following items:

• Cisco Video Surveillance PTZ IP Camera (1)

• Pendant cap (1)

• Screw driver (1)

• Ethernet cable (1)

• O-RING (1)

• Ground wire (1)

• Waterproof connector (1)

• Connector (1)

• Terminal blocks (2)

• Silica gel packets (2)

• Twin adhesives (2)

• Screws M5x8 (3)

• Screws M4x8 (3)

• Screw M3x5 (1)

• Extra set of product labels (3)

• Cisco documentation pointer card (P/N: 78-21181-01)

• Cisco RoHS document (1)

1-3

Cisco Video Surveillance PTZ IP Camera Installation Guide

OL-28954-01

Chapter 1 Overview

PTZ IP Camera Physical Details

Figure 1-1 and the table that follows describe the outer view of the PTZ IP camera.

Figure 1-1 Outer View of the PTZ IP Camera

Figure 1-2 and the table that follows describe the inner view of the PTZ IP camera.

Reset Button Recessed button that reboots the PTZ IP camera or resets it to

a default state. You can use a pin or paper clip to depress it.

Depending on how long you depress the reset button, you can

do either of the following:

• Reset—Press and release the reset button. Wait for the

PTZ IP camera to reboot.

• Restore—Press and hold the reset button for about 30

seconds. All settings are restored to the factory defaults.

Network LED Status of the network to which the camera is attached.

Status LED Status of the PTZ IP camera. For more information, see

Table 1-1.

Lens Lens that pans, tilts and zooms.

Lens

Status LED

Network LED

Reset Button

This drawing shows a camera with its dome

cover removed.

347712

1-4

Cisco Video Surveillance PTZ IP Camera Installation Guide

OL-28954-01

Chapter 1 Overview

PTZ IP Camera Physical Details

Figure 1-2 Inner View of the PTZ IP Camera

Status LEDs

Table 1-1 describes the LED indicator for each PTZ IP camera status state.

1Board-to-board Connector Board to board connector.

2SD/SDHC/SDXC Card Slot Slot for the SD, SDHC, or SDXC card.

Ta b l e 1-1 Status LEDs

LED Status

Green Camera is done booting and is available for use.

Steady Red Power on and system booting.

Red LED unlighted Power off.

Steady Red + blinking Green every 1 sec. Network works (heartbeat)

Steady Red + Green LED unlighted Network fail

Steady Red + blinking Green every 2 sec. Audio mute (heartbeat).

Blinking Red every 0.15 sec. + blinking Green

every 1 sec.

Upgrading firmware

Blinking Red every 0.15 sec. + blinking Green

every 0.15 sec.

Restore default
