Citizen Eco-Drive B612 Manuale utente

INSTRUCTION MANUAL

The following provides an explanation of those matters that should be observed

at all times to prevent injury to the wearer or other persons as well as damage to

property before they occur.

Safety Precautions: Observe at All Times

• The degree of injury or damage resulting from incorrect use while ignoring the

indicated matters is classified and explained using the following markings.

WARNING This marking indicates matters for which there is

the risk of death or serious injury.

CAUTION This marking indicates matters for which there is

the risk of injury or property damage only.

• The types of matters to be observed are classified and explained using the following

mark (the following indicates two examples of icons).

This mark indicates that caution or attention is required.

This mark indicates prohibited matters.

English

618

2040

Eco-Drive

Quick Start Function

Overcharge

Prevention Function

Insucient Charge

Warning Function

Chronograph

* e illustrations shown in this manual may dier from the

actual watch you have purchased.

This watch includes a rechargeable cell. This cell is fed electricity by a

solar cell in which light energy is converted to electrical energy.

Product Features

The watch operates by converting sunlight into electrical energy, which is stored in a rechargeable

battery. e rechargeable battery is a clean energy source that does not contain mercury or other harmful

substances. When the watch is fully charged, it will operate continuously for approximately seven months.

A watch that has stopped due to an insuciently charged cell will start operating immediately

when exposed to light.

Special hand movement to let you know when the reserve energy is getting low.

is protects the rechargeable cell from overcharging. is provides worry free enjoyment,

not matter how much light your watch is subjected to.

This feature enables elapsed time measurement (stopwatch.) You can measure time in

activities such as walking, jogging, bicycle riding, etc.

English

Contents

Troubleshooting ………………………………………………… 1

Component identication ………………………………………… 2

Recharging your watch …………………………………………… 4

Setting the Time …………………………………………………… 8

Setting the Date …………………………………………………… 10

Using the Chronograph …………………………………………… 12

Precautions ………………………………………………………… 16

Specications ……………………………………………………… 26

English

Troubleshooting

e second hand is moving at two-second intervals. P. 6

e chronograph second hand does not return to

reference position even when reset. P.14

e watch does not return to normal one-second

interval movement even when charged.

e watch does not operate even when charged.

e watch stops immediately even when charged.

e chronograph minute hand does not return to

reference position even when reset.

Submit your watch to your nearest Authorized Citizen Service Center.

618

2040

Component identication

Minute hand

Button (B)

Date indicator

Chronograph

minute hand

Hour hand

24-hour hand

Second hand

Chronograph

second hand

Crown

Button (A)

* The illustrations shown in this manual

may dier from the actual watch you have

purchased.

English

How to use the screw down crown and screw down push button

Unlock Lock

* Unlocking is not required when a standard crown and button are equipped.

Screw down

crown

Screw down

push button

Rotate the crown

counterclockwise

(le) until it releases

from the case.

Rotate the locking

screw counterclockwise

(le), and loosen until

it stops.

Rotate the crown

clockwise (right)

while pushing it in,

and tighten rmly.

Rotate the locking

screw clockwise

(right), and tighten

rmly.

Some models feature a screw down crown and/or screw down push button.

Locking the crown and/or button prevents accidental operation.

ese must be unlocked prior to using certain features of your watch such

as setting the time or date.

is watch uses a built-in rechargeable cell to store electrical energy.

Charge the watch by exposing the dial to light such as direct sunlight or

uorescent lamps.

Recharging your watch

To ensure optimal operation, be sure to perform the following.

• Charge the watch in direct sunlight (outdoors) once a month for

5 to 6 hours.

• When you take your watch off, be sure to place it in a location

where the dial can receive light. An ideal location might be a

window sill where it can receive direct sunlight.
