CITROEN 2013 DS4 Guida utente

OWNER'S HANDBOOK

ON-LINE OWNER'S HANDBOOK

Referring to the owner's handbook on-line also gives you

access to the latest information available, easily identiﬁed by

the bookmark, associated with this symbol:

If the "MyCitroën" function is not available on the CITROËN public

website for your country, you can ﬁnd your handbook at the following

address:

http://service.citroen.com

Select:

You can ﬁnd your handbook on the CITROËN website, under

"MyCitroën".

This personal and customisable space allows you to establish direct

and special contact with CITROËN.

The Vehicle documentation link in the home page (no registration is

needed),

the language,

the vehicle, its body style,

the print edition of your handbook appropriate for the date of registration

of your vehicle.

You have access to your handbook on line, together with the latest

information, identiﬁed by the symbol:

CITROËN has a presence on every continent,

a complete product range,

bringing together technology and a permanent spirit of innovation,

for a modern and creative approach to mobility.

We thank you and congratulate you on your choice.

Your vehicle is fitted with only some of the

equipment described in this document,

depending on the trim level, version and the

specifications for the country in which it is sold.

The fitting of electrical equipment or

accessories which are not recommended

by CITROËN may result in a failure of your

vehicle's electronic system. Please note this

specific warning and contact a CITROËN

dealer to be shown the recommended

equipment and accessories.

At the wheel of your new vehicle,

getting to know each system,

each control, each setting,

makes your trips, your journeys

more comfortable and more enjoyable.

Happy motoring!

We draw your attention to the following...

Familiarisation

Exterior

Parking sensors

This system measures the size of a free

parking space between two vehicles or

obstacles.

Stop & Start system

This system puts the engine temporarily into standby during

stops in the traffic (traffic lights, traffic jams, etc...). The engine

restarts automatically as soon as you want to move off. The

Stop & Start system reduces fuel consumption and exhaust

emissions, as well as noise levels when stationary.

230

218

Directional lighting

This lighting automatically provides

additional visibility when cornering.

131

Panoramic windscreen

This large glazed area provides

incomparable visibility and light in the

passenger compartment.

Cornering lighting

At low speed, this lighting comes on

automatically to improve vision when

cornering, at intersections, when parking

parking... making use of the front foglamp on

the side in question.

132

Familiarisation

Exterior

Welcome lighting

This additional exterior and interior lighting,

controlled remotely, makes your approach to

the vehicle easier when the light is poor.

Temporary puncture repair kit

This kit is a complete system, consisting of a

compressor and a sealant cartridge, for the

temporary repair of a tyre.

129

250

Under-inﬂation detection

This system continuously monitors the

pressures of the tyres and alerts you in the

event of under-inflation.

216

Blind spot sensors

In certain conditions, this system

detects the presence of a vehicle in

the blind spot. It informs you by means

of a warning lamp in the corresponding

door mirror.

222

Exterior customising

stickers

When washing your vehicle using a jet

wash, keep the end of the lance at least

30 cm from the stickers.

100

Opening

A. Folding/unfolding the key

(first press this button).

3-button remote

control

When a sensor detects a low level of light,

the remote switching on of the dipped beam

headlamps, the sidelamps and the side spotlamps

makes your approach to the vehicle easier.

Welcome lighting

Complete or selective unlocking of

the vehicle

(rapid flashing of the direction

indicators).

Opening the windows

(hold until the desired position is reached).

Selective unlocking of the boot.

Normal locking

(press once; fixed lighting of the

direction indicators).

Closing the windows

(hold until the desired position is reached).

129

In the same way, the passenger compartment

lighting, such as the courtesy lamps and the

footwell lamps, comes on.

Familiarisation

117, 120

A. Opening the fuel filler flap.

Capacity of the fuel tank: approximately 60 litres.

Fuel tank

Opening

101, 114

1. Selective unlocking of the boot.

2. Opening the boot.

Boot

Panoramic windscreen

Blind

To open it, take the blind by its central

grip A, and pull it rearwards, guiding it to

the desired position.

To close it, take the blind by its central

grip A, and pull it forwards, guiding it to the

desired position.

The sun visor should be in the folded position

before moving the blind.

This includes a panoramic area in tinted glass to increase lighting and vision in the passenger compartment.

Fitted with a blind on each side to improve temperature control and a sun visor to avoid dazzle.

Sun visor

Fitted with a courtesy mirror and a ticket holder.

To avoid dazzle from the front, lower the

sun visor.

To avoid dazzle from the side, disengage

the sun visor from its central fixing and turn

it towards the side window.

Do not attach to or suspend heavy

objects from the blind and its guide

rails.

Familiarisation

Interior

Electronic gearbox

This system offers driving combining a fully

automatic mode and a manual mode.

Interior mood lighting

This dimmed lighting of the passenger

compartment improves visibility inside the

vehicle when the light is poor.

Audio and communication

systems

These systems benefit from the following

technologies: radio, CD player, USB player,

Bluetooth system, satellite navigation system

with colour screen, auxiliary sockets.

Radio

206

139

357

303

Electric parking brake

It combines the functions of automatic

application on switching off the engine and

automatic release when moving off.

Manual application and release remains

possible.

196

eMyWay satellite navigation system

Massage function

This system gives a lumbar massage for a

period of 60 minutes. The massage is done in

6 cycles of 10 minutes each.
