PRESENTATION

THIS HANDBOOK summarises the specifications, adjustments, checks and special features of the CITROEN C3.

The handbook is divided into the following sections representing the main functions :

GENERA - ENGINE - INJECTION - IGNITION - C UTCH - GEARBOX - DRIVESHAFTS - AX ES - SUSPENSION - STEERING - BRAKES -

HYDRAU ICS - E ECTRICA - AIR CONDITIONING.

GENERAL

IDENTIFICATION OF VEHICLES

E1AP09HD

A: Chassis stamp

(cold stamp on bodywork).

B : Manufacturer’s data plate.

(on the LH centre pillar)

C : A S / RP No. and RP paint code

(label on front pillar close to driver’s door).

D : Inflation pressures and tyre references.

(label on front pillar close to driver’s door)

E : Serial no. on bodywork.

F : Gearbox reference – Factory serial no.

G : Engine legislation type – Factory serial no.

GENERAL

Emission standard L IFL5 L /INF K’

Type code FC HFXB/T FR HFXB FN HFXB FC HFXB FN HFXC FC HFXC FC HFXB FC HFX5

/IF /IF /D

Engine type HFX

Cubic capacity (cc) 1124

Fiscal rating (hp) 4

Gearbox type MA/5N

Gearbox ident. plate 20 CF 14

IDENTIFICATION OF VEHICLES

PETROL

1.1i

X-SX X

GENERAL

IDENTIFICATION OF VEHICLES

(*) = Export.

PETROL

1. i

SX – Exclusive

Auto.

Auto. Auto.

Emission standard L IFL5

Type code FC KFVE FN KFVB FN KFVE FC KFVC/IF FC KFVF/IF FN KFVC/IF

Engine type KFV

Cubic capacity (cc) 1360

Fiscal rating (hp) 5

Gearbox type AL4 MA/5N AL4 MA/5N AL4 MA/5N

Gearbox ident. plate 20 TP 75 20 CF 15 20 TP 75 20 CF 15 20 TP 75 20 CF 15

20 CF 16 (*) 20 CF 16 (*) 20 CF 16 (*)

GENERAL

IDENTIFICATION OF VEHICLES

(*) = Export.

PETROL

1.6i 16V

1. i

SX – Exclusive

Auto.

Emission standard IFL5 L L /INF L

Type code FN KFVF/IF FC KFVB FC KFVB/D FC KFVE/D FN NFUB FC NFUB

Engine type KFV NFU

Cubic capacity (cc) 1360 1587

Fiscal rating (hp) 56

Gearbox type AL4 MA/5N MA/5S

Gearbox ident. plate 20 TP 75 20 CF 15 20 CF 16 (*) 20 CN 40

GENERAL

(*) = Export.

IDENTIFICATION OF VEHICLES

DIESEL

1. HDi

X - SX

Emission standard L

Type code FC 8HBXB/T FN 8HXB FC 8HXB FC 8HXB/MOD FC 8HXK FR 8HXB

Engine type 8HX

Cubic capacity (cc) 1398

Fiscal rating (hp) 4

Gearbox type MA/5O

Gearbox ident. plate 20 CN 33 20 CN 36 (*)

GENERAL

Emission standard L

Type code FN 8HWK FC 8HWB FN 8HVB FC 8HVB

Engine type 8HW 8HV

Cubic capacity (cc) 1398

Fiscal rating (hp) 45

Gearbox type MA/50 BE4/5

Gearbox ident. plate 20 CN 33 20 CN 36 (*) 20 DM 25 20 DM 26

IDENTIFICATION OF VEHICLES

DIESEL

1. HDi 1. HDi 16V

S - SX SX - Exclusive

TED

(*) = Export.

GENERAL

IDENTIFICATION OF VEHICLES

DIESEL

TED

1. HDi 16V

SX - Exclusive SX SX - Exclusive

Emission standard L

Type code FN 8HYB FC 8HYC FC 8HYB/MOD FC 8HYB/T FC 8HYK FR 8HYB

Engine type 8HY

Cubic capacity (cc) 1398

Fiscal rating (hp) 5

Gearbox type BE4/5

Gearbox ident. plate 20 DM 25 20 DM 26

GENERAL

IDENTIFICATION OF VEHICLES

Manufacturer’s plate.

E1AP09JC

The manufacturer’s plate carries the following information :

(a) Type approval number (*).

(b) Type serial number.

(d) Gross vehicle weight (*).

(e) Maximum weight on front axle (*).

(f) Maximum weight on rear axle (*).

(g) Manufacturer identification.

(*) = According to marketing country.
