Clarity C35 Manuale utente
User Guide
E
S
P
A
Ñ
O
L
F
R
A
N
Ç
A
I
S
E
N
G
L
I
S
H
Amplified Telephone
C35™
TABLE OF CONTENTS
Introduction........................................................................................ 3
Parts Checklist .................................................................................. 4
Quick Reference Guide .................................................................. 5
Connecting the phone ................................................................. 7
Introduction to Clarity Power.................................................... 8
Clarity Power Boost..................................................................... 8
Getting Started
Installing backup batteries ...........................................................9
Desktop and Wall Mount Installations ...................................10
Placing and receiving calls..........................................................13
Features
Memory Storage..........................................................................13
Adding a memory location........................................................13
Notification Options .....................................................................15
Troubleshooting..............................................................................17
Technical Specifications .............................................................19
Safety Instructions.........................................................................20
FCC Requirements and Regulations.......................................22
Warranty and Service ..................................................................25
Thank you for purchasing the Clarity C35 AmplifiedTelephone.
Operating Instructions and the associated Quick Reference
Guide will provide you with the information you need to
use your C35 effectively, easily and safely. Read this manual
thoroughly before using your telephone.
Keep the manual near the telephone for easy reference.
INTRODUCTION
4
CONTENTS & PARTS CHECKLIST
Mounting bracket
Telephone line cord
Handset coil cord
Handset Base unit
BOOST
VOLUME
User guide
4 AA batteries
5
C35 Quick Reference Guide
FEATURES
1Phone Number Directory
2Memory Button
3Redial Button
4Flash Button
5Volume Slider
6Low Battery Indicator
7Visual Ringer
8Boost Button
9BOOST Indicator
10 Hold Indicator
11 Program Button
12 Hold Button
1
BOOST
VOLUME
3
2
6
7910 45
8
1112
6
DIAL
PT
Off Lo
C35 Quick Reference Guide
FEATURES
1RingerVolume Switch
2Pulse/Tone Switch
3Phone Line Connection
1
LINE
SIDE VIEW
BACK VIEW
2
3
7
HOW TO CONNECT THE C35 PHONE FOR DESKTOP USE
C35 Quick Reference Guide
1. Install the 4 AA batteries.
2. Connect one end of the telephone line cord to the “Line” jack on the
back of the C35 and the other end to the phone outlet on your wall.
3. Connect the handset cord to the telephone as shown above.
4. Lift the handset and listen for a dial tone.The phone is ready to use.
The C35 phone may also be used as a wall mounted phone.
(Please see page 12 of this guide for instructions.)
M
1
M
2
M
5
M
6
M
7
M
8
M
9
M
10
M
11
M
3
M
4
1
2
8
BOOST
VOLUME
Figure A
INTRODUCTION TO CLARITY POWER
Clarity Power™Technology
Clarity Power not only makes calls louder, but also easier to
understand. The patented Clarity Power technology amplifies and
shapes high frequencies to enhance communications for the millions
of people who experience high frequency hearing loss, the most
common type of hearing loss.
The Clarity C35 has a maximum amplification level of 40dB louder
than a regular telephone when the included batteries are inserted.
This combined with Clarity Power enhances the sounds being heard
through the telephone line, resulting in comfortable and enjoyable
conversations.
Clarity Power BOOST Button
The C35 has a BOOST button that controls the loud-
ness of the receiver. See Figure A. Once the BOOST
button is pressed, an extra level of amplification is added
over the entire range of theVolume Control. During a
call, the BOOST button can toggle the Clarity Power
function on or off according to the user’s needs.The
BOOST button will reset automatically every time the
phone is hung up for at least 5 seconds.The BOOST light
will illuminate while the BOOST function is activated.
See Page 13.
Warning: Volume may be at a high level. To protect
hearing, lower the Clarity PowerVolume Control before
using the phone.
Clarity PowerVolume Control
The Clarity PowerVolume Control adjusts the level of
volume the handset both in Boost or non-Boost modes.
The volume dial provides up to 15dB of volume before
the BOOST button is activated. Once the BOOST but-
ton is pressed, the C35 will provide up to 40dB of gain
when the batteries are inserted. See Figure B.
BOOST
VOLUME
Figure B
9
GETTING STARTED
There are four initial steps involved in setting up
your C35
1. Insert four AA alkaline batteries for maximum amplifi-
cation. See below.
2. Decide if you want the phone to sit on a desk or hang
on the wall.
3. Connect the telephone components. Pages 11-12.
4. Program up to twelve (12) telephone numbers to call
with the press of a memory button. See Page 13.
To install new batteries:
1. Slide open the battery compartment cover on the
bottom of the telephone.This opening is pointed out
with the #2 in Figure 1.To open the battery compart-
ment, use a pen or similar fine point instrument to
press into small opening below the compartment door.
2. Install four fresh batteries. Be sure to observe battery
polarity as imprinted on the base of the compartment.
The battery indicator on the top panel will light up if the
batteries are running low.
The batteries are required to reach the maximum
amplification and to fully operate certain functions on the
phone. If the low battery indicator appears, please replace
with new batteries.
2
1
Figure 1
10
M
1
M
2
M
5
M
6
M
7
M
8
M
9
M
10
M
11
M
3
M
4
1
Connecting your Telephone
1. Carefully remove your telephone from its box. If there
is any visible damage, do not attempt to operate this
equipment. Return it to the place of purchase.
2. Check to be sure that you have all items that come
with your C35 telephone.You should have a Hand-
set, Base Unit, Mounting Bracket, Handset Line Cord,
and Telephone Line Cord, User Guide and 4 AA batter-
ies.
Choosing a Location
• The C35 requires a modular phone jack
• The unit should be located in an area where it is easy
to see the lighted ringer.
• Choose a location that is out of the way of
normal activities.
• The unit can be used as a desk top phone or wall
mount phone.
Desk Mounting Instructions
Follow these instructions to place the phone on a desk or
table top using the supplied bracket.
1. Plug one end of the long flat telephone line cord into
the jack marked LINE located on the back of the
telephone. Plug the other end into the telephone wall
jack. See Figure 2
2. Plug one end of the modular coiled handset cord into
the handset. Plug the other end into the jack located
on the left side of the telephone. Place the handset in
the cradle. See Figure 3.
GETTING STARTED
Figure 2
M
1
M
2
M
5
M
6
M
7
M
8
M
9
M
10
M
11
M
3
M
4
Figure 3
