EZ-8 Drum Sander

Operation and Safety

Safety Practices:

Sanding dust is flammable!

Empty and clean dust bag

when not in use.

Always wear safety

goggles, protective

clothing, and a dust mask

while sanding.

Keep the dust bag

emptied. Dust generated

from sanding wood floors

can spontaneously ignite

or explode. Promptly

dispose of any sanding

dust in a metal container

clear of any combustibles.

Do not dispose in a fire.

Keep the work area well

ventilated.

Sanding/finishing wood

floors can create an

explosive or combustible

environment. Do not

operate this machine

around solvents, thinners,

fuels, floor finishes, or any

other flammable materials.

Keep hands, feet, and

loose clothing away from

all moving parts on the

machine.

Disconnect the power cord

before replacing the pad or

the abrasive.

Never leave the machine

unattended while it is

connected to a power

source.

www.clarkeus.com/rental

Application: Sand hardwood floors. Level uneven wood floors.

Set-up and operation

Follow the steps listed below to complete a floor sanding project safely.

Step Action

Preparation:

Step Action

1 Install handle and fasten latches.

2 Insert control link into notch and slide collar to

pin. Raise sanding drum with control level.

3 Install dust tube. Tie dust bag over bell opening

of dust tube.

4 Connect the handle pigtail to the motor cord.

Install abrasive (expandable drum, continuous

sleeve sandpaper OR standard drum flat

notched sandpaper).

Operational Instructions:

Step Action

Set exposed nails with hammer and punch.

Connect machine to grounded outlet. Press

switch to start.

2 Allow switch to return to run (R) position.

PREVENT DAMAGE TO THE SURFACE; MACHINE

IS ALWAYS MOVING WHEN DRUM CONTACTS

FLOOR.

Slowly lower drum to floor with control handle.

Do not force handle down to floor. Allow to

float on floor.

Operational Techniques:

Work from right to left. For each forward pass, move the

machine 4” over the pass just finished. Retrace the reverse

path without overlapping. Keep sander in motion while drum

is engaged. Move the machine in the direction of the wood

grain. Sand at a constant pace. Feather-cut termination

point of pass by easing control lever up. Stagger

termination points.

More on reverse . . .

EZ-8 Drum Sander

Step Action

Safety Tips: READ AND FOLLOW DIRECTIONS IN

OWNERS MANUAL

Step Action

1 Press selector switch to off (O) position and

disconnect power supply when changing

abrasive.

2 Empty dust bag when it is 1/3 full. Sanding dust

can spontaneously ignite and cause fire or

explosion.

3 Inspect power cable for abrasion and replace

when needed.

Care and Maintenance:

Step Action

1 Periodically blow out dust from sanding

chamber.

2 Periodically remove debris from truck and caster

wheels.

3 Remove dust bag from machine and shake

thoroughly to remove sanding dust.

4 Turn bag inside out and machine wash in cold

water to maintain dust recovery.

5 Periodically check drive belts for fraying and

broken cogs. Realign affected belt.

6 Periodically check bearings for wear and

lubricate according to the owners manual.

Questions or Problems?

Contact Clarke

Technical Service at

800-356-7274.

Need more

information?

The instructions on this

sheet are abbreviated

instructions only and are

provided solely as a

customer service. They

are not meant to replace

the tool’s operation

manual. If you are

unsure of the tool’s safe

and proper operation,

please request an

operator’s manual from

one of our sales

associates.
