Clarke CBB75 Manuale di istruzioni

OPERATION & MAINTENANCE

INSTRUCTIONS

ORIGINAL INSTRUCTIONS GC1118 - ISS 3

BORE HOLE PUMP

MODEL NO: CBB75 & CBB100

PART NO: 7150710 & 7150715

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

INTRODUCTION

Thank you for purchasing this CLARKE Bore Hole Pump, which is designed for

use in a domestic environment only.

Please read this manual thoroughly, before attempting to operate this

product, and carefully follow all instructions given.

It is vitally important that ALL precautions are taken, as specified, which will not

only provide protection for yourself and that of others around you, but will also

ensure that the Battery Charger will give you long and satisfactory service.

GUARANTEE

This CLARKE product is guaranteed against faulty manufacture for a period of

12 months from the date of purchase. Please keep your receipt as proof of

purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission.

This guarantee does not effect your statutory rights.

ENVIRONMENTAL RECYCLING POLICY

Through purchase of this product, the customer is taking on the

obligation to deal with the WEEE in accordance with the WEEE

regulations in relation to the treatment, recycling & recovery and

environmentally sound disposal of the WEEE.

In effect, this means that this product must not be disposed of with general

household waste. It must be disposed of according to the laws governing

Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal

facility.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

SAFETY PRECAUTIONS

ALWAYS learn the pump’s applications, limitations and specific potential

hazards peculiar to it. Read and become familiar with the entire operating

manual.

ALWAYS ensure that the local supply voltage corresponds with the supply

information on the pump’s data plate.

ALWAYS check the pump for damage before use. Any damaged part should

be checked to ensure that it will operate properly and perform it’s intended

function. Check for alignment of moving parts, breakage of parts, mountings,

and any other condition which may effect the machine’s operation. Any

damage should be properly repaired or the part replaced. If in any doubt DO

NOT use the pump. Consult your local CLARKE dealer.

ALWAYS keep children away. All visitors should be kept at a safe distance from

the work area, especially whilst operating the pump.

ALWAYS maintain the pump in top condition and keep it clean for best

performance. Follow any maintenance instructions.

ALWAYS handle with care, do not carry the pump by it’s electrical cable, or

yank the cable to disconnect it from the power supply.

ALWAYS concentrate on the job at hand, no matter how trivial it may seem. Be

aware that accidents are caused by carelessness due to familiarity.

ALWAYS remove the plug from the electrical supply when adjusting or

changing parts.

ALWAYS use recommended accessories, the use of improper accessories

could be hazardous.

ALWAYS guard against electric shock. Safety can be further be improved by

using a residual current device (RCD).

ALWAYS ensure that the power supply used to power the pump is connected

to an efficient grounding system.

ALWAYS store the pump out of the reach of children, DO NOT allow children to

operate the pump.

WARNING: AS WITH ALL MACHINERY, THERE ARE CERTAIN HAZARDS

INVOLVED WITH THEIR OPERATION AND USE. EXERCISING RESPECT AND

CAUTION WILL CONSIDERABLY LESSEN THE RISK OF PERSONAL INJURY.

HOWEVER, IF NORMAL SAFETY PRECAUTIONS ARE OVERLOOKED OR

IGNORED, PERSONAL INJURY TO THE OPERATOR OR DAMAGE TO

PROPERTY, MAY RESULT

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

NEVER operate the pump when under the influence of drugs, alcohol or any

medication.

NEVER leave the pump running unattended. Turn power OFF. Do not leave the

pump until it comes to a complete stop.

DO NOT use the pump if the electrical cable, plug or motor is in poor

condition.

SAFETY PRECAUTIONS FOR BORE HOLE PUMPS

ONLY use the pump for its intended applications (refer to setup & operation).

ALWAYS protect the power supply plug from getting wet. The plug must be

accessible when the pump is running.

ALWAYS ensure that nobody is in contact with the water in which the pump

submerged.

ALWAYS protect the pump and pipe from frost, drain the pump and pipe and

store in a protected location.

ALWAYS ensure that the weight of the pump is borne by the rope and not the

supply cable or the delivery pipe.

DO NOT carry the bore hole pump by the supply cable.

DO NOT make any modifications to the pump or tamper with it in any way.

NEVER operate the pump with the delivery port closed or obstructed.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ELECTRICAL CONNECTIONS

Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply

through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch.

If the plug has to be changed because it is not suitable for your socket, or

because of damage, it must be removed and a replacement fitted, following

the wiring instructions shown below. The old plug must be discarded safely, as

insertion into a power socket could cause an electrical hazard.

If the colours of the wires in the power cable do not agree with the markings

on the plug.

• The BLUE wire must be

connected to the

terminal which is

marked N or coloured

black.

• The BROWN wire must

be connected to the

terminal which is

marked L or coloured

red.

• The YELLOW AND

GREEN wire must be

connected to the terminal which is marked E or or coloured green.

AN APPROVED RESIDUAL CURRENT DEVICE (RCD) WHICH HAS A TRIPPING

CURRENT OF LESS THAN 30 mA MUST BE USED.

If you are not sure, consult a qualified electrician. DO NOT try to do any

repairs.

WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS

THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE

MAINS SUPPLY.

WARNING: THE WIRES IN THE POWER CABLE OF THIS PRODUCT ARE

COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:

BLUE = NEUTRAL BROWN = LIVE YELLOW AND GREEN = EARTH

Plug must be BS1363/A approved.

Always fit

Ensure that the outer sheath of

Neutral

(Blue)

Live

(Brown)

Earth

(Green and

a 13 Amp

the cable is firmly held by the clamp

fuse.

Yellow)

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

SETUP AND OPERATION

This bore hole pump is designed to pump soft water from bore holes, wells,

underground springs or storage tanks to supply single sprinkler or irrigation

systems. The pump is watertight and must be submerged in water (max depth

15m).

Suitable pumping liquids are:

• Clear water

•Rainwater

The pump must NOT be used to pump:

• Salt water

• Liquid foods

• Corrosive or chemical substances

• Flammable, explosive or volatile liquids

• Sandy or abrasive liquids

• Sewerage

• Liquids containing textile materials or paper fragments

SETUP

Attach the delivery pipe to the delivery port.

NOTE: DO NOT install a non-return valve on the pump delivery side as one is

already built into the pump. The non-return valve prevents the pump from

draining when stopped.

Secure the supply cable to the delivery pipe.

Secure the rope and lower the pump into the bore hole.

NOTE: The rope should bare the weight of the pump, NOT the delivery pipe or

the supply cable.

The pump must be positioned at least one metre above the bottom of the

bore hole. Sand and other material found in pumped liquid will cause rapid

deterioration of the pump and reduce its efficiency.

Before starting the pump, make sure that the delivery pipe is unobstructed

and the delivery port is open.

To start the pump insert the plug into the mains supply:- to stop the pump

remove the plug from the supply.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

The pump is equipped with a thermal-amperometric motor protector. In case

of overload, the motor protector shuts down the pump automatically. When

the motor has cooled the pump starts up again automatically. If the motor

protector steps in, it is absolutely necessary to locate and eliminate the cause

of the malfunction. (refer to troubleshooting on page 8).

NOTE: The water being pumped will be polluted if this pump becomes

damaged and lubricant within the pump escapes.

CARE & MAINTANENCE

This pump does not require any particular maintenance and all repairs must be

carried out by an authorised service centre only.

After removing the pump from the water, drain and rinse with clean water.

To clean the suction filter, use a jet of clean water.

If the pump’s turbines need replacement, take the pump to an authorised

service centre.

If the power supply cable is damaged it MUST be replaced by the manufacturer

or an authorised service centre.

WARNING: ELECTRIC SHOCK HAZARD! BEFORE CARRYING OUT ANY

MAINTENANCE OR CLEANING OPERATIONS, DISCONNECT THE PUMP

FROM THE POWER SUPPLY.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

TROUBLESHOOTING

PROBLEM: The pumps motor does not start or stops suddenly after a few

seconds.

Cause Solution

No power supply.

The thermal-amperometric motor

protector has deactivated the pump

due to overload.

Solid particles have obstructed the

suction filter.

Check the electrical connections.

Unplug the pump and clean it. Check

the water temperature (max 35°C).

Unplug the pump and clean it.

PROBLEM: The pump is running but no water is being delivered.

Cause Solution

The pump is not sufficiently

submerged.

Clogged suction filter.

There is no outflow of air because the

delivery pipe is obstructed.

Lower the pump deeper in the water.

Unplug the pump and clean it.

Remove obstructions from the delivery

pipe.

PROBLEM: The flow rate is insufficient.

Cause Solution

Clogged suction filter.

Diameter of external pipe is too small.

Too high head.

Unplug the pump and clean it.

Use a larger diameter pipe.

Reduce the head.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

SPECIFICATIONS

NOTE: Please Note that details and specifications herein, are correct of time

of going to print. However CLARKE International reserve the right to

change specifications at any time without prior notice. Copyright

Model Number CBB75 CBB100

Input voltage / Current 230V, 50Hz 230V, 50Hz

Input Wattage: 750W 1000W

Mains Supply Cable Length: 15M 15M

Flow Rate: 60 litres/min 80 litres/min

Max. Immersion Depth: 15M 15M

Max Head 55M 60M

Max. Temperature: 35°C35°C

Max. Sand Content: 90g/m390g/m3

Max. Size of Suspended Particles 2mm dia 2mm dia

Number of Impellers: 7 8

Delivery Diameter: 1 inch 1 inch

Pump Diameter: 98mm 98mm

Rope Length: 15M 15M

Weight 10.3 kg

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

DECLARATION OF CONFORMITY

Altri manuali per CBB75

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Clarke Pompa dell'acqua

Clarke

Clarke SPE800 Manuale di installazione e funzionamento

Clarke

Clarke BPT600 Manuale di installazione e funzionamento

Clarke

Clarke BIP1000 Manuale di istruzioni

Clarke

Clarke PSV3A Manuale di installazione e funzionamento

Clarke

Clarke EBP1100 Manuale di istruzioni

Clarke

Clarke LEP1A 7260060 Manuale di istruzioni

Clarke

Clarke CSP1530 Manuale di istruzioni

Clarke

Clarke PSV6A Manuale di istruzioni

Clarke

Clarke BIP1500 Manuale di istruzioni

Clarke

Clarke CBM250SS Manuale di istruzioni

Clarke

Clarke CHHDP830 Manuale di istruzioni

Clarke

Clarke HSEC651A Manuale di istruzioni

Clarke

Clarke CBM240E Manuale di istruzioni

Clarke

Clarke CPRP560 Manuale di istruzioni

Clarke

Clarke HSE120 Manuale di installazione e funzionamento

Clarke

Clarke PF75 Manuale di istruzioni

Clarke

Clarke HSE Series Manuale di installazione e funzionamento

Clarke

Clarke CPCDP500 Manuale di istruzioni

Clarke

Clarke HIPPO 2 Manuale di istruzioni

Clarke

Clarke PSP195 Manuale di istruzioni

Clarke

Clarke CPE Series Manuale di istruzioni

Clarke

Clarke ECP20A1 Manuale di istruzioni

Clarke

Clarke PW50 Manuale di istruzioni

Clarke

Clarke CU150 Manuale di installazione e funzionamento

Manuali Pompa dell'acqua popolari di altre marche

Neptun

Neptun NPHW 5500 Manuale utente

Sensidyne

Sensidyne Gilian BDX-II Istruzioni per l'installazione e il funzionamento

Draper

Draper 47808 Manuale utente

Trolla

Trolla 12820 Manuale utente

Sunfab

Sunfab SVH Series Manuale utente

WilTec

WilTec 50740 Manuale utente

Fieldmann

Fieldmann FVC 5015 EK Manuale utente

Everbilt

Everbilt EFSUB5-122HD Manuale utente

Graco

Graco Husky 3300e Manuale utente

esotec

esotec 101018 Manuale utente

moyno

moyno 2000 CC Manuale utente

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manuale utente

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guida alla risoluzione dei problemi

DUROMAX

DUROMAX XP WX Series Manuale utente

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manuale utente

Franklin Electric

Franklin Electric IPS Manuale utente

Xylem

Xylem e-1532 Series Manuale utente

Milton Roy

Milton Roy PRIMEROYAL Manuale utente
