Clas Ohlson EM3211 Manuale utente
EnglishSvenskaSuomiDeutsch
Projection Alarm
Clock Radio
Klockradio med projektor
Kelloradio, jossa projektori
Projektions-Radiowecker
Art.no. Model
36-7726 EM3211 Ver. 20190731
32
3
English
2
Projection Alarm Clock Radio
Art.no 36-7726 Model EM3211
Please read theentire instruction manual before using
theproduct and then save it for future reference. We
reserve theright for any errors in text or images and any
necessary changes made to technical data. In theevent
of technical problems or other queries, please contact our
Customer Services (see address details on theback).
Safety
• Never subject theproduct to high temperatures, dust,
heavy vibration, impacts, humidity or moisture.
• Do not place theproduct where it could fall into water
or other liquid.
• Do not cover theproduct.
• The power supply to theproduct should be disconnected
by unplugging theUSB connector from thepower
socket. If amains adapter is used, themains adapter
should also be unplugged from thepower socket.
Make sure that theUSB socket (and mains power
socket if anadapter is used) is easily accessible.
• Protect your hearing. Listening on high volume for
prolonged periods can lead to permanent hearing loss.
• Never try to open theproduct, repair, dismantle or
modify it in any way. Repairs must only be carried
out by authorised service personnel and only using
genuine spare parts.
• This product contains abutton cell battery. If
thebattery is swallowed, within just two hours it can
lead to severe internal burns and even be fatal.
• Never put batteries in your mouth and always handle
them with care. Swallowing a battery could result in
aserious injury.
• If you suspect that abattery has been swallowed or
has entered thebody in another way, seek medical
assistance immediately.
4 5
English
1 2 3 4 5 6 7
10 11 12 13 149
8
15 16 17
This product is intended for indoor use only.
• Keep new and used batteries out of thereach of children.
• The product should never be used if thebattery
compartment cover is in any way damaged or
malfunctioning.
Buttons and functions
4 5
English
1. [▼] Reduce thevalue/volume, search for theprevious
radio channel
2. [VOL] Set thevolume
3. [RADIO/SLEEP] Switch theradio on
4. [ ] Switch theradio off, snooze-function,
change thedisplay brightness
5. [SET] Press to view set alarm times, advance through
saved radio channels. Hold in to set thetime
6. [AL1∙2] Activate thealarm, set thetime of alarms 1 and 2
7. [▲/Project] Increase thevalue/volume, search for
thenext radio channel, activate theprojector
8. Projector
9. Display
10. :Alarm 1 is activated
11. :Alarm 2 is activated
12. : Snooze
13. Radio: The radio is switched on
14. SLEEP: The sleep timer has been activated
15.Battery cover
16.Speaker
17.DC 5V: Power input socket
Installation
1. Remove thebattery cover on theback of theclock
radio and insert 1 × CR2032 battery (sold separately).
Make sure that thepositive terminal of thebattery is
facing upwards. The battery is just aback-up. If there
is apower cut theback-up battery will save thetime
and alarm settings until thepower comes back on.
Note: The alarm function of theclock radio will not
work if thepower supply has been disconnected (such
as in thecase of apower cut), theback-up battery
only provides enough power to save thesettings in
thememory.
2. Connect theUSB cable to theDC power in socket (17)
on theclock radio and to anavailable USB power
supply/charger.
6 7
English
Setting thetime
1. Hold in [SET] for approx. 3 seconds. The hour setting
will start to flash.
2. Press [▲] or [▼] to change thevalue.
3. Confirm each stage with [SET].
4. Set thefollowing in sequential order:
- Hours
- Minutes
- 24-hour or 12-hour time format
Setting thealarm
• Two separate alarms are available, alarm 1 (AL1) and
alarm 2 (AL2).
• There is achoice of either theradio or abuzzer as
analarm signal.
1. Hold in [AL1∙2] until “Hours” and start to flash.
2. Press or hold in [▲] or [▼] to change thevalue.
3. Confirm each stage with [AL1∙2].
- Set thefollowing in sequential order:
- Hours
- Minutes
- Radio: Selection options:
- “OFF” The buzzer sounds for thealarm
- “ON” The radio sounds for thealarm
- “L + anumber”: Set thevolume of thealarm
radio. The volume can be adjusted manually when
theradio is playing. Refer to theRadio section.
- Snooze: Set thesnooze time. When “OFF”
is shown on thedisplay, thesnooze function is
deactivated.
4. “Hours” and will flash. Alarm 1 is now set, set
alarm 2 or wait 15 seconds to return to normal time
display mode.
6 7
English
Activating thealarm
Press [AL1∙2] repeatedly to browse theselection options:
• Alarm 1 is activated.
• Alarm 2 is activated.
• Alarm 1 and 2 are activated.
• None of thealarms are active.
Activating theSnooze function
When thealarm sounds, press [ ] to start
thesnooze function. The alarm will start sounding again
after theset snooze time has elapsed.
Shutting off thealarm
When thealarm sounds, press any button except [ ]
to shut thealarm off. The alarm will sound at thesame
time thenext day, refer to theSetting thealarm section.
Radio
Press [RADIO/SLEEP]
The first time theradio is switched on, anautomatic
search for radio stations will be initiated and thestations
with thestrongest signals will be saved in thememory.
The channels will be ordered according to their frequency
and presented as “C:01, C:02, C:03” and so on.
Manual tuning
• Press [▼] or [▲] to manually search for astation frequency.
• Hold in [▼] or [▲] to automatically search for
thenext station.
Saving radio channels
1. Press [▼] or [▲] and tune into thedesired station.
2. Hold in [SET] until “C:01” appears on thedisplay.
3. Press [▼] or [▲] to select achannel from 1 to 15.
4. Press [SET] to confirm and save thechannel.
Up to 15 channels can be saved.
5. Press [SET] to browse thesaved channels.
“C:01, C:02, C:03” and so on.
8
English
Using theradio
Press [RADIO/SLEEP]. The clock radio will play
thechannel that was listened to last.
Note: The clock radio will also save thevolume settings
used last. If thevolume was set to “0”, no sound will be
heard.
• Press [VOL] and then [▼] or [▲] to change
thevolume.
• Press [ ] to switch theradio off.
Sleep timer
Set thetime for how long theclock radio is to be left on
before it automatically shuts off.
With theclock radio switched on, press [RADIO/SLEEP]
repeatedly to select between: 05, 10, 15, 30, 45, 60, 75,
90 min or off.
Display brightness
The brightness of thedisplay can be changed by repeatedly
pressing [ ]. Select one of these options:
• Medium
• Low
• Display off
• High
Note: If theradio is activated, the [ ] button
will switch theradio off first, press [ ] again to
change thebrightness.
Projector
The projector will display thecurrent time on awall or
ceiling. The projector function is most effective in adark
environment and at adistance of 1–3 m.
The [▲/Project] button has three functions:
1. Switches theprojector on
2. Reduces thebrightness
3. Switches theprojector off
8 9
English
Changing theangle
Angle theprojector up or down to thedesired position.
Press and hold in [▲/Project ] to rotate theprojector
image, theimage will rotate through 90°. Repeat to rotate
theimage 180°, 270° and back to 0°.
Care and maintenance
Clean theproduct by wiping it with adamp cloth. Use only
mild cleaning agents, never solvents or corrosive chemicals.
Troubleshooting
The clock radio will
not switch on.
• Make sure that theadapter
and mains lead are intact
and undamaged.
• Make sure that themains
adapter and its lead are
properly connected both to
awall socket and theclock
radio.
• Is thewall socket energised?
No sound from
thespeakers.
• Check thevolume.
Poor or non-existent
radio reception.
The automatic FM
scan doesn’t work.
• Move theclock radio to
another location.
The set alarm does
not sound.
• Make sure that theclock
radio is set to thecorrect
time.
• Check that theset alarm is
activated.
10
English
Responsible disposal
This symbol indicates that theproduct
should not be disposed of with general
household waste. This applies throughout
theentire EU. In order to prevent any harm to
theenvironment or health hazards caused by
incorrect waste disposal, theproduct must
be handed in for recycling so that thematerial can be
disposed of in aresponsible manner. When recycling your
product, take it to your local collection facility or contact
theplace of purchase. They will ensure that theproduct is
disposed of in anenvironmentally sound manner.
Specifications
Dimensions 50×98×183 mm
Weight 400 g
Colour Black
Mains adapter (sold separately)
Input 100–240 V AC, 50/60 Hz
Output 5 V DC, 0.5–2.4 A
Power cable USB (included)
