Cleanmate S2000 PRO MAX Manuale utente
Robot Vacuum Cleaner
Please read through this user manual before using the product and keep the manual for future use.
Cleanmate S2000 PRO MAX
User Manual
When using the product, please maintain constant vigility and follow the following instructions: please read this user manual
carefully before using the product and keep it property.
1. The problems that may occur during the cleaning of the product should be eliminated as soon as possible. Clean the power cords and small
objects on the ground to prevent the product from being blocked during the cleaning process. Fold the fringe of the carpet under the carpet,
and make sure that the hanging curtains, tablecloths, etc. do not touch the ground.
2. If there is a suspended environment such as stairs, please test the product first to see if it can detect the edge of the suspended area without
falling. Guardrails should be installed at the edge of the suspended area to prevent the product from falling. It should be assured that the
protective device will not cause personal injury such as tripping.
3. Please follow the instructions in the manual to use the product. Only use accessories recommended or sold by the manufacturer.
4. Make sure that the power supply voltage matches the voltage marked on the charging stand.
5. Before using the product, make sure that the dust box and filter material have been installed in place.
6. If the power cord is damaged, in order to avoid danger, it must be replaced by professionals from the manufacturer, its maintenance
department or similar department.
7. Please turn off the product switch before cleaning and maintaining the product.
8. The plug must be unplugged from the power socket before cleaning and maintaining the product.
9. Before disposing of the product, the old batteries must be disposed of in accord with regulations.
10. If you do not use the product for a long time, please power off the product.
11. Before disposing of the product, the battery of the product must be removed and discarded in accord with local laws and regulations.
12. Please follow local laws and regulations to dispose of old batteries.
13. The product cannot be used by children under the age of 8 or people with mental disabilities. If you need to use it, please do it under the
supervision and guidance of a guardian. Please do not let children ride on the product or play with the product as a toy.
14. Only used in indoor home environment. Do not use in outdoor, commercial and industrial places.
15. Do not use the product in the room where infants and young children sleep.
16. Do not use the product with a damaged power cord or power socket. Do not use the product when it cannot work normally due
to falling, damage, outside use, or water ingress. To avoid injury, the product should be repaired by the manufacturer or its after- sales service.
17. Please use the product in accord with the instructions in the manual. The company is not responsible for any loss and damage caused by
improper use.
Security Specifications
NOTE:
1
！
1. Only applicable to the original charging stand specially equipped by the manufacturer. It is formerly for the user to replace the
battery privately. If the battery is suspended to be damaged, please contact the manufacturer, authorized dealer or a
professional in similar departments to replace it.
2. It is formidable to use the product in an environment with open flames or fragile objects.
3. It is forbid to use the product in an extreme hot (above 40 ° C) or extreme cold (below 0 ° C) environment.
4. It is formidable for the hair, cloths, fingers and other parts of the human body to be closed to the opening and operating parts
of the product.
5. It is formidable to use the product on wet or water-filled ground.
6. It is forbidden for the product to absorb anything that may block the product, such as stones, waste paper, etc.
7. It is formidable for the product to absorb any combinable materials, such as gasoline, toner and toner for printers or copies. It
is formidable to use the product in a clean area with flammable materials.
8. It is formidable for the product to absorb any burning items, such as cigarettes, matches, ashes and other items that may
cause a fire.
9. Do not place objects at the suction port. Do not use the product when the suction port is blocked. Clean up dust, cotton wool,
hair, etc. at the suction port to ensure smooth air circulation at the suction port.
10. Use the power cord carefully to avoid damage. It is forbidden to use the power cord to drag or lift products and product
charging seats, to use the power cord as a handle, to clamp the power cord in the crack of the door, and to pull the power
cord at sharp corners and corners. Do not run the product on the power cord, and keep the power cord away from the heat
source.
11. It is forbidden to use damaged charging seats. If the charging seats are damaged, in order to avoid danger, they must be
repaired or replaced by professionals from manufacturers, authorized distributors or similar departments.
12. Even if the product has been seriously damaged, it is forbidden to burn the product, and the battery of the product may
cause explosion.
Warnings:
2
1. If you want to discard the batteryin this machine, please do not discard them along with domestic garbage, but hand
them over to the nearest waste battery recycling station or after-sales service center for centralized treatment.
2. The following instructions are not for ordinary users, but for the disposal instructions of the final battery disposer.
3. The chemical substances contained in the built-in battery of this machine will pollute the environment. Please be sure to
take out the battery in the body before disposing of the robot. The battery should be taken out and handed over to a
professional battery recycling point for centralized treatment.
1. Leakage and exudation from batteries can cause human injury.
2. If there is any leakage or exudation from the battery, make sure to avoid contact with eyes or skin.
3. In case of inadvertent contact, wash hands with clean water and rinse eyes immediately. If you feel uncomfortable,
please see a doctor immediately.
Description of Obsolete Batteries:
Cautious:
3
Remove Battery:
！NOTE:
The following information is only applicable when discarding this robot, not daily operation instructions!
The battery can only be removed when the battery is completely exhausted. No matter under what circumstances, the
battery cannot come into contact with metal objects.
The procedure for removing the battery is as follows:
Let the robot run until there is no electricity without touching the charging seat;
Turn off the power switch of the robot;
Remove the screw on the battery cover plate;
Remove the battery cover plate;
Pull off the connector plug of the battery and remove the battery.
5
Front of the robot 6
Underside of the robot 7
Dust collector 8-10
Preparations
Organize spaces 11
Removing protective strips 12
Install the side brushes correctly 13
Check the status of dust collector 14
Remote control and the charging station 15
Operation charging 16
Indication and pairing with WiFi 17
Cleanmate-APP download 18
Robot Operation
First Use 19
Start cleaning/ Cleaning the Floor/ Mopping the Floor 20
Start cleaning with watertank 21
22
Various States of the Dust Collector indicator
Maintenance
Component Maintenance Frequency 23
Watertank Maintenance 24
Maintenance Mopfunction 25
Cleaning the Dust Box for the watertank 26
Cleaning the Dust Box (dustcollecting) 27
Maintenance roller brush and side Brushes 28
Maintenance Lidar, fall sensors, Anti-collision Board 29
Maintenance charging Pole Piece, Driving Wheel and Front Wheel 30
Change of the dust Bag 31
Troble Shooting
Trouble Shooting Dust channel 32
Preparation for long storage 33
Troubleshooting of the robot and the dust collector 34
Trouble shooting robot 35
Trouble shooting dust collector 36
Specifications
Specifications robot 37
Specifications robot and dustcollector 38
Directory
List of contents
Product composition
4
List of Contents
Machine
The pictures in this manual are for reference only. The actual appearance shall be subject to the physical item.
Dust bag Remote control Manual
Manual
Magnetic stripe 2 pcs
Electric Water tank
Mop cloth 2 pcs Dust box assembly
(for dust collector)
Side brush 2 pair HEPA-filter Dust brushes
Dust collector
5
Charging station
Power adapter
(for charging station)
Carpet brush
Suction mount
Product Composition - Front of the robot
Front of the robot
Dust box for watertank
(under the face cover)
Lidar
Infrared cushioning
anti-collision plate
Lidar unit
Voice broadcast
loudspeaker
Centrifugal fan
Air duct
Dust box lower cover
Dust box handle High efficiency
primary filter
Dust box upper cover
HEPA-filter
Power switch
6
Top panel Start/Pause button
WiFi-indicator
Product Composition - Underside of the robot
Dust box assembly
Watertank assembly
Side brush Front wheel
Underside of the robot
Charging plates
Battery compa-
rtment cover
Sensors
Bottom cover
Rolling brush
Driving wheel
Water tank
Mop holder
Primary filter
Dust box lower cover
Dust box upper cover
Dust suction port
Dust suction outlet
filling pipe end
Water tank plug
Washable Mop
Water tank
release button
7
Product Composition- Dust collector
Front of the dust collector
Back of the dust collector
Status indicator
Bump switch
Power cord storage
Air outlet
Signal transmitter
Button for dust
collector cover
Dust suction port
Charging pole piece
8
Product Composition - Dust collector
Dustcollecting station (open cover)Dustcollecting station (Under side)
Dust bag
insertion port
Air suction
bucket
Bottom cover screw
Air duct canal
Air duct cover screw
bottom cover
9
